DX910S 3KDE175311L9100

/ 4.9
1001 reviews | Need a Specific Revision?
ABB DX910S 3KDE175311L9100 provides 8 intrinsically safe digital I/O channels, supporting dry contacts, NAMUR initiators, and low power valves while enabling direct installation in ATEX Zone 1 hazardous areas.
Get a quick price for DX910S 3KDE175311L9100
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DX910S 3KDE175311L9100

  • Manufacturer:
    ABB
  • Part Number:
    DX910S 3KDE175311L9100
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Digital Input or Output (DIO8-Ex)
  • Channel Type:
    DX
  • Number of Input Channels:
    4
  • Number of Output Channels:
    4
  • SOE:
    N/A
  • Redundancy:
    No
  • Intrinsic safety:
    Yes
  • Mechanics:
    S900
  • Hazardous Location:
    ATEX Zone 1 certified (can be directly installed in Zone 1)
  • Corrosion Protection:
    G3 advanced coating (compliant with ISA-S71.04 standard)
  • Ambient Temperature:
    -20 °C to +60 °C
  • Relative Humidity:
    93% ± 3% (maximum at 40 °C)
  • Weight:
    0.1 kg
  • Estimated shipping dimensions:
    2x10.5x11cm
  • Tariff Code:
    2942000000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Protection Use Cases Environment

Features:

  • Flexible mixed I/O configuration with 4 inputs and 4 outputs in a single intrinsically safe module
  • Direct installation in Zone 1 hazardous areas reduces wiring and infrastructure costs
  • Advanced diagnostics and hot swap capability improve system availability and maintenance efficiency
ABB DX910S 3KDE175311L9100 provides a practical solution for digital signal handling in hazardous industrial environments. Within process industries such as oil and gas or chemical production, reliable input and output communication is essential for monitoring and control. ABB DX910S 3KDE175311L9100 integrates both functions into one compact module, reducing system complexity. The ability to install directly in Zone 1 further enhances flexibility in plant design. As part of the S900 I/O system, ABB DX910S 3KDE175311L9100 supports efficient and safe field-level integration.

Functionality of ABB DX910S 3KDE175311L9100 extends beyond simple signal transmission. Support for NAMUR sensors and dry contacts ensures compatibility with a wide range of field devices. Output channels provide control of low power intrinsically safe valves, enabling direct actuation in hazardous areas. Combined with PROFIBUS DP communication, ABB DX910S 3KDE175311L9100 maintains reliable data exchange with control systems. Diagnostic capabilities and configurable I/O behavior further enhance operational flexibility.

ABB DX910S 3KDE175311L9100 is widely applied in environments requiring durability and long service life. Corrosion-resistant coating and wide temperature tolerance allow use in offshore platforms and chemical plants. Maintenance efficiency is improved through hot swap functionality and automatic diagnostics, minimizing downtime. The module supports modern automation strategies by reducing wiring and simplifying system layout. ABB DX910S 3KDE175311L9100 therefore represents a robust and efficient choice for hazardous area digital I/O applications.

The DX910S 3KDE175311L9100 ABB Digital Input or Output (DIO8-Ex) may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB DX910S 3KDE175311L9100 Digital Input or Output (DIO8-Ex) Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB DX910S 3KDE175311L9100 Digital Input or Output (DIO8-Ex) Specs

General

  • Manufacturer ABB
  • Model DX910S 3KDE175311L9100
  • Condition New Original ready stock
  • Product Family DX910N 3KDE175313L9100,DX910B 3KDE175312L9100
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Open Circuit Detection: Real-time monitoring of DI/DO loop resistance; immediate system alarm triggered upon open circuit detection.
  • Short Circuit Protection: Limits channel output current to prevent external cable short circuits from burning out internal components.
  • Electrical Isolation: High-voltage isolation barriers are installed between the channel and the internal bus to block surge voltages in hazardous areas.
  • Polarization Protection: Field-side signal lines have reverse connection protection to prevent damage to the module from accidental wiring.
  • Valve Status Monitoring: Receives signals from Zone 1 field double-open/closed switches, enabling full-open/full-close valve feedback.
  • Solenoid Valve Drive Control: Directly outputs intrinsically safe, low-power voltage for safe control of shut-off valves in hazardous areas.
  • NAMUR Signal Acquisition: Seamlessly integrates with standard NAMUR proximity switches and intrinsically safe sensors in petrochemical tank farms.
  • Flexible Channel Utilization: Allows for flexible definition of the DI/DO ratio via software, reducing redundancy and optimizing cabinet space.
  • Wide Temperature Range Operation: Meets industrial-grade fanless cooling requirements from -20°C to +60°C.
  • Chemical Corrosion Resistance: Standard G3 coating provides high-strength resistance to corrosive gases such as hydrogen sulfide.
  • High Humidity Tolerance: Supports environments with up to 93% relative humidity; internal circuitry is moisture-proof and condensation-proof.
  • Industrial Interference Immunity: Excellent electromagnetic compatibility (EMC) and resistance to high-frequency radiation and pulse group interference.
Description
ABB DX910S 3KDE175311L9100 belongs to the S900 remote I/O family and combines digital input and output functionality within a single module. The unit offers 4 input channels and 4 output channels, allowing flexible configuration depending on application requirements. Inputs support dry contacts or NAMUR initiators, while outputs are suitable for low power intrinsically safe valves. This mixed I/O capability simplifies system design and reduces the number of modules required in field installations.

Built for hazardous environments, ABB DX910S 3KDE175311L9100 is certified for ATEX Zone 1 and can also be deployed in Zone 2 or Zone 0 when connecting intrinsically safe devices. The module integrates intrinsic safety protection and electrical isolation between input, bus, and power circuits. This ensures safe signal handling even in explosive atmospheres, making it suitable for critical industries such as oil and gas, chemical processing, and pharmaceuticals.

ABB DX910S 3KDE175311L9100 is designed for direct field installation as part of the S900 I/O system, which communicates with higher-level control systems via PROFIBUS DP. By placing I/O closer to field devices, wiring and marshalling costs are significantly reduced. The system architecture also improves signal reliability and simplifies plant layout, contributing to overall operational efficiency.

Durability and environmental resistance are key strengths of ABB DX910S 3KDE175311L9100. The module operates within a temperature range of -20 °C to +60 °C and supports high humidity up to 93%. G3 advanced coating protects against corrosive gases such as hydrogen sulfide and chlorine, ensuring long service life in aggressive environments. Mechanical robustness and stable operation support continuous industrial use without performance degradation.

Maintenance and system availability are enhanced through features such as hot swap and hot configuration in run. ABB DX910S 3KDE175311L9100 allows module replacement without interrupting the primary voltage, reducing downtime during servicing. Extended diagnostics, short and break detection, and FDT/DTM-based configuration tools further simplify troubleshooting and system management, ensuring efficient long-term operation.
Alternative Names
DX91OS 3KDE175311L91OO DX9IS 3KDEI753IIL9I00 DX910S 3KDE175311L9100 DX910N 3KDE175313L9100 DX910B 3KDE175312L9100 DO910S 3KDE175321L9100 DP910S 3KDE175361L9100
Technical notes
Serving as a highly adaptable remote I/O solution, the legacy ABB DX910S (3KDE175311L9100) integrates 8 configurable channels for Zone 1 hazards, requiring a minimum 2mA load in output mode to suppress false line-fault diagnostics.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What type of signals can ABB DX910S 3KDE175311L9100 handle?
ABB DX910S 3KDE175311L9100 supports inputs from dry contacts and NAMUR proximity switches, while outputs drive low power intrinsically safe valves.
How many channels are available in ABB DX910S 3KDE175311L9100?
ABB DX910S 3KDE175311L9100 provides 8 channels total, including 4 inputs and 4 outputs with flexible configuration.
How does ABB DX910S 3KDE175311L9100 reduce installation cost?
Field-mounted S900 architecture enables ABB DX910S 3KDE175311L9100 to minimize wiring and marshalling requirements.
What maintenance advantages come with ABB DX910S 3KDE175311L9100?
Hot swap capability allows ABB DX910S 3KDE175311L9100 replacement during operation without shutting down the system.
