EI813F 3BDH000022R1

/ 4.9
1001 reviews | Need a Specific Revision?
The EI813F 3BDH000022R1 supports 10BaseT Ethernet connectivity, enabling reliable data transmission between the control system and network infrastructure.
Get a quick price for EI813F 3BDH000022R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for EI813F 3BDH000022R1

  • Manufacturer:
    ABB
  • Part Number:
    EI813F 3BDH000022R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Ethernet Module
  • Network Standard:
    10BaseT
  • Data Rate:
    10 Mbps
  • Connector Type:
    RJ45
  • Controller Family:
    AC 800F
  • Redundancy Support:
    Yes
  • Weight:
    0.14 kg
  • Estimated shipping dimensions:
    2.7x12.8x15.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Configuration & Programming Monitoring & Control Key Applications

Features:

  • Interface Between Industrial Ethernet Networks and AC 800F Controller Backplane
  • Combines Capability of 10BaseT Ethernet Communication with Network Redundancy Support
  • Operates in Conjunction with the AC 800F Controller Family and Standard Industrial Automation Systems
The EI813F 3BDH000022R1 operates as the Ethernet Communication Module in an AC 800F rack, providing reliable network connectivity to all modules within the system. It continuously facilitates data transmission over 10BaseT Ethernet networks (10 Mbps, RJ45 connector) and distributes this communication capability through the rack backplane to support real-time data exchange between controllers, operator stations, and field devices. Seamless network communication is standard with the EI813F 3BDH000022R1, however using an optional Redundant Network Configuration will allow seamless switchover to a backup network path in the event of a primary communication failure. The EI813F 3BDH000022R1 has made improvements in several areas over previous communication module designs in addition to incorporating standard Ethernet connectivity capability within the AC 800F rack.

The EI813F 3BDH000022R1 provides essential network communication functions common to the entire rack, and is a critical component of the control system data path, directly affecting the proper, normal operation of the overall monitoring and control system. One or two EI813F 3BDH000022R1 modules are required per rack depending on the desired network redundancy level. The EI813F 3BDH000022R1 occupies a dedicated slot in the rack and is strategically positioned for optimal network integration within the AC 800F controller architecture.

For Dual Redundant Network applications, the AC 800F System requires a second EI813F 3BDH000022R1 Ethernet module installed in the redundant slot. In addition to standard single module operation, the redundant configuration also performs automatic switchover. The EI813F 3BDH000022R1 dual network configuration executes failover using the internal circuitry specified in the module options. Using this method, the redundant network system continually monitors the health of both communication paths. If the system detects that the primary EI813F 3BDH000022R1 module is no longer providing stable network connectivity (outside configured communication tolerance levels), it will automatically transfer the network load to the secondary EI813F 3BDH000022R1 module and generate a system event notification.

The EI813F 3BDH000022R1 ABB Ethernet Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB EI813F 3BDH000022R1 Ethernet Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB EI813F 3BDH000022R1 Ethernet Module Specs

General

  • Manufacturer ABB
  • Model EI813F 3BDH000022R1
  • Condition New Original ready stock
  • Product Family EI 813F,PM 802F,PM 803F,EI 811F
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Software Requirements: Use of Freelance V7.1SP2a or higher is mandatory for this module.
  • Hardware Setup: The module is a plug-in component that typically attaches directly to the PM 802F or PM 803F CPU backplane.
  • Engineering Tool: Users can perform all hardware and software configuration offline.
  • Networking: The control network connection is established via Ethernet through this module.
  • Operator Interface: Communicates with Freelance Operations (DigiVis) to provide HMI functionality, including faceplates, trend displays, and alarm lists.
  • Diagnostics: The Freelance system provides built-in module diagnostics and extended troubleshooting capabilities for communication modules like the EI813F.
  • Redundancy: The AC 800F supports Ethernet communication redundancy as a standard feature, allowing for high system availability.
  • Remote Monitoring: Enables seamless communication between controllers, sensors, and remote I/O units across the control network.
  • Data Exchange: Facilitates fast data transfer for both process data (real-time control) and diagnostic data from up to four fieldbus gateways.
  • System Migration: Often used in modernization projects where existing Freelance 2000 systems are integrated into newer AC 800F architectures.
Description
The EI813F 3BDH000022R1 is a high-performance Ethernet communication module manufactured by ABB, specifically designed for industrial automation networks. The EI813F 3BDH000022R1 supports 10BaseT Ethernet connectivity, enabling reliable data transmission between control systems and network infrastructure. The EI813F 3BDH000022R1 serves as a critical interface component within ABB's AC 800F controller family, facilitating seamless integration of field devices into distributed control systems.

This EI813F 3BDH000022R1 Ethernet module is engineered to provide robust network communication capabilities in demanding industrial environments. The EI813F 3BDH000022R1 features standard RJ45 connectivity for 10 Mbps Ethernet networks, ensuring compatibility with existing network architectures. The EI813F 3BDH000022R1 is designed with industrial-grade specifications to withstand harsh conditions including temperature variations, electrical noise, and mechanical vibrations commonly encountered in manufacturing facilities.

The EI813F 3BDH000022R1 is specifically designed for process control and automation applications where reliable Ethernet communication is essential. The EI813F 3BDH000022R1 enables real-time data exchange between controllers, operator stations, and field devices, supporting critical monitoring and control functions. The EI813F 3BDH000022R1 addresses the challenge of integrating legacy systems with modern network infrastructure, providing a bridge between traditional industrial protocols and standard Ethernet networks. The EI813F 3BDH000022R1 solves communication bottlenecks by establishing dedicated network pathways that ensure deterministic data transmission for time-sensitive control operations.

The EI813F 3BDH000022R1 finds extensive application in industries such as oil and gas, chemical processing, power generation, and water treatment facilities. The EI813F 3BDH000022R1 is particularly suited for distributed control system (DCS) architectures where multiple controllers require coordinated network access. The EI813F 3BDH000022R1 supports redundant network configurations, enhancing system availability and fault tolerance in critical process applications. The EI813F 3BDH000022R1 enables remote diagnostics and maintenance capabilities, reducing downtime and operational costs in large-scale industrial installations.
