SB510

/ 4.9
1001 reviews | Need a Specific Revision?
The SB510 is an ABB backup power supply for Advant Master systems, accepting 110-230V AC/DC, designed to charge a 12V, 4 Ah NiCd battery.
Get a quick price for SB510
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SB510

  • Manufacturer:
    ABB
  • Part Number:
    SB510
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Power Supply Module
  • Input Voltage (AC):
    110-230V AC, 47-60 Hz
  • Input Voltage (DC):
    110-230V DC
  • Battery Type:
    NiCd (Nickel-Cadmium)
  • Battery Voltage:
    12V
  • Battery Capacity:
    4 Ah
  • Weight:
    0.96 kg
  • Estimated shipping dimensions:
    6x33.5x14.8cm
  • Tariff Code:
    8517795000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Operating Environment Control Functions

Features:

  • Operates on global AC mains or DC supplies; no configuration switches required.
  • Specifically designed to maintain backup battery for Advant Master controller memory and real-time clock.
  • Legal spare part for ABB Advant Master Process Control Systems placed on the market before RoHS restrictions.
The SB510 is designed for global deployment in ABB Advant Master systems. It accepts AC input from 110 to 230V at 47-60 Hz, covering all standard mains voltages (120V US, 230V Europe, etc.) without jumper changes. This eliminates the risk of connecting to the wrong voltage and reduces spare part inventory – one power supply serves facilities worldwide. Additionally, the SB510 accepts DC input from 110 to 230V, allowing it to be powered from battery banks, DC distribution systems, or photovoltaic arrays. This flexibility is particularly valuable in substations, offshore platforms, or remote facilities where DC power is more reliable than AC. For engineers maintaining legacy Advant Master systems, the universal input simplifies replacement ordering – no need to specify voltage when purchasing.

The SB510 is specifically engineered to charge a 12V, 4 Ah Nickel-Cadmium (NiCd) backup battery. In ABB Advant Master systems, this battery powers the controller’s volatile memory (program, data, and configuration) and the real-time clock during mains power interruptions. Without a functioning battery charger, the battery would deplete, and a power outage could cause complete loss of controller programming – requiring manual reloading of software and reconfiguration of setpoints. The SB510 provides the correct constant-current charging profile required by NiCd cells, preventing overcharging or undercharging. It also maintains the battery at full capacity, ready for immediate use.

The SB510 is explicitly exempt from the EU Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU under Article 2(4)(c), (e), (f), and (j). This exemption applies to spare parts for ABB Advant Master Process Control Systems that were placed on the market before RoHS restrictions took effect. As a result, the SB510 may contain restricted substances such as lead (Pb) in solder, cadmium (Cd) in the battery charging circuit components, or other materials no longer allowed in new electronic products.

The SB510 ABB Power Supply Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL)by the manufacturer (OEM).

ABB SB510 Power Supply Module Manuals, Datasheets,Drivers,Link Important Notice:Other accessories,manuals,cables,calibration data,software,etc.are not included with this equipment unless listed in the above stock item description.All prices are shown in USD.
ABB SB510 Power Supply Module Specs

General

  • Manufacturer ABB
  • Model SB510
  • Condition New Original ready stock
  • Product Family SB511,SB512,SB500
Important Notice:Other accessories,manuals,cables,calibration data,software,etc.are not included with this equipment unless listed in the above stock item description.All prices are shown in USD.
  • Process Control Systems: Serves as a core power backup component for Advant OCS (Open Control System) and the AC460 controller.
  • Critical Infrastructure: Used in oil and gas, fine chemical, power dispatching, and large production lines for precise control of mechanical movements (such as robotic arms and conveyor belts) and to prevent production interruptions due to power outages.
  • Generator Protection: Equipped with a Power System Stabilizer (PSS) function to help suppress low-frequency oscillations and improve the unit's maximum output capacity.
  • Interference Resistance and Protection: Possesses strong electromagnetic compatibility (EMC) and interference resistance. Some versions (such as those with coated modules) can withstand harsh environments with high humidity or some corrosiveness.
  • Compact Design: Facilitates installation in control panels with limited space.
  • Battery Management: Designed specifically for 12V, 4Ah NiCd (nickel-cadmium) batteries, featuring automatic charging and maintenance functions, and always ready to switch to standby mode.
  • Status Indicators: The panel features LED indicators that provide real-time feedback on power input, battery status, and module faults.
  • System Integration: Fully integrated into the ABB programming environment, enabling data exchange with the controller without the need for third-party drivers.
Description
The SB510 is a backup power supply for ABB Advant Master Process Control Systems. It accepts universal input: 110-230V AC (47-60 Hz) or 110-230V DC. The SB510 is specifically designed to charge a 12V, 4 Ah NiCd battery, ensuring that critical control system memory and real-time clocks retain data during mains power loss. The product is manufactured by ABB and carries the ABB type designation SB510.

When using the SB510, engineers can provide battery-backed power to Advant Master controllers, preventing data loss and system downtime during power interruptions. It is listed with HS Code 850440 (static converters) and customs tariff number 85044083. The SB510 is categorized as a power supply product type.

The SB510 is exempt from the EU RoHS Directive 2011/65/EU under Article 2(4)(c), (e), (f), and (j). This exemption applies to spare parts for ABB Advant Master Process Control Systems. The declaration of conformity reference is 3BSE088609. The product ID is 3BSE000860R1. For engineers maintaining legacy Advant Master systems, the SB510 is a critical spare part to keep backup power operational.

For legacy ABB system expansions or repairs, the SB510 provides a direct replacement backup power supply. It is compatible with Advant Master controllers that require a 12V, 4 Ah NiCd battery backup. The unit is designed to operate on global AC mains voltages (110-230V) as well as DC sources, offering flexibility in different plant installations. Always verify battery compatibility before connection.
Alternative Names
SB511 SB512 SB500
Technical notes
The SB510 is a linear (or ferroresonant) charger specifically designed for NiCd batteries. NiCd batteries require a constant current charging profile with temperature compensation. Using an incorrect charger can overheat or damage the battery.The SB510 measures 291 mm deep/long and 150 mm high. These dimensions are critical for fitting into Advant Master cabinets.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does the SB510 keep controller memory alive during power loss?
Yes. The SB510 charges a 12V, 4 Ah NiCd backup battery. When mains power fails, the battery automatically supplies power to the Advant Master controller’s memory and real-time clock, preventing data loss and maintaining time/date. This ensures a smooth restart without reprogramming.
What input voltages does the SB510 accept?
The SB510 accepts 110-230V AC (47-60 Hz) or 110-230V DC. This universal input allows use worldwide without configuration changes and also supports DC-powered installations, such as battery-backed substations or DC grid systems.
Is the SB510 RoHS compliant?
No. The SB510 is exempt from EU Directive 2011/65/EU (RoHS) under Article 2(4)(c),(e),(f),(j) for ABB Advant Master Process Control Systems spare parts. It may contain lead or other restricted substances but is legally available for legacy system maintenance.
What battery does the SB510 charge?
The SB510 is specifically designed to charge a 12V, 4 Ah NiCd (Nickel-Cadmium) battery. Always use the recommended battery type to ensure correct charging characteristics and backup duration. Do not substitute with other chemistries (e.g., lead-acid or Li-ion) without verification.
