NKTU01-15

/ 4.9
1001 reviews | Need a Specific Revision?
ABB NKTU01-15 is a PVC-insulated termination cable linking compatible Bailey I/O modules to termination hardware.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for NKTU01-15
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for NKTU01-15

  • Manufacturer:
    ABB
  • Part Number:
    NKTU01-15
  • Product Family:
    ABB Bailey
  • Product Type:
    Termination Cable
  • Stock:
    1
  • Model:
    NKTU01-15
  • Cable family:
    NKTU01
  • Insulation:
    PVC
  • Documented role:
    I/O module to termination unit
  • Connector arrangement:
    Hooded module end and socket termination end
  • Weight:
    1.12 kg
  • Estimated shipping dimensions:
    36x10x35cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Connector Layout I/O Path Fault Isolation Product Applications

Features:

  • Termination path: connects compatible I/O modules to termination units.
  • Directional connectors: hooded module end and socket termination end.
  • PVC family: distinguishes NKTU01 from non-PVC NKTU11 or NKST cable.
NKTU01-15 is an ABB Bailey termination cable identified by its exact manufacturer label.

Connector style and endpoint pairing control whether it belongs in the installed I/O path.

Post-installation channel tests confirm that the cable has restored the intended signals.

Apter Power supports exact-label review for ABB NKTU01-15.
ABB NKTU01-15 Termination Cable Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Module end: uses the documented hooded connector for the compatible I/O module.
  • Termination end: the socket mates with the installed termination unit.
  • Direction: endpoint orientation must match the cabinet record before insertion.
  • Condition: pins, socket contacts, latch and strain relief are evaluated as one assembly.
  • Module identity: the cable is selected against the installed ABB I/O card.
  • Termination identity: the opposite endpoint remains tied to the recorded termination unit.
  • Channel consequence: crossed or displaced conductors can affect one point or an entire I/O group.
  • Family boundary: NKTU01 PVC construction is not interchangeable with NKST11 identity.
  • Movement fault: a changing signal near the connector points to conductor, pin or strain-relief damage.
  • Continuity limit: a static pass does not prove correct endpoint mapping or loaded channel operation.
  • Group loss: inspect seating, common references and the saved map before condemning the module.
  • Functional proof: test every affected input or output from field termination through the host.
  • Bailey I/O termination: carries documented signals between an installed module and termination unit.
  • Input-channel service: restores a known field-input path during planned cabinet maintenance.
  • Output-channel service: reconnects a documented command path with endpoint direction preserved.
  • Intermittent-I/O diagnosis: isolates connector and cable faults before a module replacement decision.
Description
NKTU01-15 is an ABB termination cable with a hooded connector for the I/O-module end and a socket for the termination-unit end. That directional connector arrangement is more important to selection than cable color or apparent length.

In an installed I/O path, NKTU01-15 must preserve the module-to-termination-unit relationship and the original channel assignment. Reversing the assumed endpoints or accepting a differently keyed assembly can leave one channel, a group or the complete interface unavailable.

If movement near a connector changes an NKTU01-15 signal, isolate the affected circuit and examine conductor continuity, pin retention and strain relief before replacing the I/O module. Return the cable to service only after every affected input or output responds correctly through the host system.
Alternative Names
NKTU0115 NKTU01 15 ABB NKTU01-15 Bailey NKTU01-15 NKTU-01-15 NKTU01/15 ABB Bailey NKTU01-15 NKTU01 termination cable 15
Technical notes
NKTU01-15 can pass a static continuity test yet fail when flex or connector strain opens an individual conductor. Inspect the bend nearest each termination, support the connector bodies, and keep the affected I/O group out of service if a channel changes while the cable is gently positioned under the approved test procedure.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
An NKTU01-15 channel changes when the cable is moved near a connector. Should the I/O module be replaced first?
No. Hold the circuit out of service and test continuity, pin retention and strain relief while reproducing the movement under an approved procedure.
Can the two ends of NKTU01-15 be reversed?
No. The hooded module end and termination-unit socket must follow the documented installed direction and endpoint record.
A spare has an NKTU01-15 label but different hood or socket geometry. Can receiving accept it?
No. Hold the assembly until both connector ends and their keying match the installed module-to-termination-unit path.
NKTU01-15 passes continuity, but one I/O channel remains unavailable. Should the cable be accepted?
Not yet. Trace that conductor through both connector ends and prove the channel from field termination to the host indication or output.
All channels in one NKTU01-15 group disappear after reconnection. Where should diagnosis start?
Start with connector seating, common references and the saved channel map before replacing the I/O module or termination unit.
Which condition details matter when ordering NKTU01-15?
State the complete label, both connector types, strain-relief condition, assembly completeness and any endpoint-specific damage.
