XVC772A102

/ 4.9
1001 reviews | Need a Specific Revision?
ABB XVC772A102 3BHE032285R0102 is a varnished high voltage divider board documented for the ABB ACS2000 medium voltage drive IFU filter assembly.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for XVC772A102
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for XVC772A102

  • Manufacturer:
    ABB
  • Part Number:
    XVC772A102
  • Product Family:
    ABB Drives
  • Product Type:
    Varnished High Voltage Divider Board
  • Stock:
    1
  • ABB Product ID:
    3BHE032285R0102
  • ABB Designation:
    XV C772 A102
  • Official Type:
    HVD Board, Varnished
  • Documented System:
    ABB ACS2000
  • Weight:
    0.2 kg
  • Tariff Code:
    85049090
  • Country of origin:
    China
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Identity Review Drive Matching Safety Check

Features:

  • Verified product ID: ABB identifies the board with 3BHE032285R0102.
  • Official designation: The current ABB page shows the spaced designation XV C772 A102.
  • ACS2000 application: ABB spare-parts documentation lists it in the ACS2000 IFU filter assembly.
The ABB XVC772A102 is identified by product ID 3BHE032285R0102 and official designation XV C772 A102. ABB describes it as a varnished HVD board.

The ABB XVC772A102 appears in official ACS2000 spare-parts documentation as a high voltage divider board within the IFU filter assembly. ABB current product data lists a 0.2 kg net weight.

Before ordering ABB XVC772A102, verify the complete product ID, spaced ABB designation, drive type, IFU filter assembly, board revision, connector layout, and installed label photographs.

The ABB XVC772A102 3BHE032285R0102 HVD board is available for quotation and drive-matching support from Apter Power, subject to current inventory and sourcing confirmation.
