ABB ICSK20F1 FPR3327101R1202 is a 24 VDC CS31 I/O module with 12 non-isolated inputs and 8 relay outputs rated up to 250 VAC at 2 A.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for ICSK20F1 FPR3327101R1202
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for ICSK20F1 FPR3327101R1202

  • Manufacturer:
    ABB
  • Part Number:
    ICSK20F1 FPR3327101R1202
  • Product Family:
    ABB Procontic
  • Product Type:
    CS31 Relay I/O Module
  • Stock:
    1
  • Weight:
    0.25 kg
  • Estimated shipping dimensions:
    12.2x9.2x6.3cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals I/O Configuration CS31 Integration Service Checks Product Applications

Features:

  • Mixed-I/O role: non-isolated field inputs and relay switching share one CS31 station module.
  • Protection boundary: relay contacts depend on correctly selected external circuit protection.
  • Response behavior: the fixed input delay must be accepted as part of the controller timing design.
The module bridges field-contact monitoring and relay-based switching, making both input commons and output loads part of the same service record.

Because the relay contacts are not internally short-circuit protected, cabinet protection and load suitability define whether reconnection is acceptable.

The full FPR identity, CS31 address, controller mapping, and terminal schedule must agree before the station returns to service.

Apter Power provides exact-model document review, quotation, and procurement support for the ABB ICSK20F1 FPR3327101R1202 CS31 Relay I/O Module.
ABB ICSK20F1 FPR3327101R1202 CS31 Relay I/O Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Inputs: 12 non-isolated 24 VDC points.
  • Outputs: 8 relay contacts.
  • Input delay: fixed at 5 ms.
  • Contact protection: no module-level short-circuit protection is provided.
  • Station address: preserve the installed CS31 setting.
  • Input commons: document the non-isolated field reference.
  • Relay circuits: map contact terminals, external supply, load, and protection.
  • Controller program: reconcile every I/O point before energization.
  • Pre-removal: label all conductors and record relay load voltages.
  • Protection check: inspect fuses or protective devices before reconnecting loads.
  • Contact test: verify commanded switching without exceeding documented limits.
  • Acceptance: prove each input and output through the controller and field circuit.
  • CS31 mixed I/O: 24 VDC input monitoring with relay-based field switching.
  • Isolated-load switching: circuits designed around the documented relay contacts and external protection.
  • Exact-order service: replacement where FPR3327101R1202 is specified.
Description
ICSK20F1 FPR3327101R1202 is an ABB Procontic CS31 I/O module with 12 non-isolated 24 VDC digital inputs and 8 relay outputs. ABB documents a fixed 5 ms input delay for the module.

The relay outputs of ICSK20F1 FPR3327101R1202 are documented for loads up to 250 VAC at 2 A, subject to the manual’s contact limits. ABB also states that the relay outputs are not short-circuit protected, so external circuit protection and load assessment are required.

Before replacing ICSK20F1 FPR3327101R1202, record the CS31 address, input commons, relay-contact wiring, load voltage, and protective devices. Confirm the complete FPR code and prove each input and output through the approved commissioning plan before returning the station to service.
Alternative Names
ICSK20F1 FPR3327101R1202 FPR 332 7101 R1202
Technical notes
ABB documents no module-level short-circuit protection for the relay contacts on ICSK20F1 FPR3327101R1202. A mismatched load or missing external protective device can damage the switching path even when the controller command is correct. Reconnect only after the load and protection record matches the documented contact boundary.
