        S200-IE8 S200IE8

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        S200-IE8 S200IE8 is an 8-channel analog input unit with 12-bit resolution, accepting ±10V or 0-20mA signals, featuring galvanic isolation and a 100ms filter for ABB S200 I/O systems.
        Fast Shipping Available
        Get a quick price for S200-IE8 S200IE8
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for S200-IE8 S200IE8

        • Manufacturer:
          ABB
        • Part Number:
          S200-IE8 S200IE8
        • Product Family:
          ABB S200 I/O
        • Product Type:
          Analog Input Unit
        • Number of Inputs:
          8 single-ended
        • Resolution:
          12-bit
        • Voltage Ranges:
          ±10V, 0-10V, 2-10V DC
        • Current Ranges:
          0-20mA, 4-20mA
        • Voltage Input Resistance:
          200 kΩ
        • Current Input Resistance:
          238 Ω
        • Filter:
          100ms first-order low-pass (63% of FS)
        • Voltage Non-linearity:
          0.05% max
        • Current Non-linearity:
          0.10% max
        • Accuracy @ 25°C:
          ±0.2% FS (voltage & current)
        • Repeatability:
          ±0.05% FS
        • Voltage Overload:
          30V DC continuous
        • Current Overload:
          32mA continuous (one channel at a time)
        • Internal Current (bus):
          20mA max
        • Power Dissipation:
          3W max @ 31.2V
        • Operating Temp:
          0°C to +55°C
        • Storage Temp:
          -40°C to +85°C
        • Weight:
          0.1 kg
        • Estimated shipping dimensions:
          9.3x5.3x4.5cm
        • Tariff Code:
          8538900000
        • Country of origin:
          Sweden
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Application Operating Environment Monitoring & Control

        Features:

        • S200-IE8 S200IE8 provides eight single-ended 12-bit inputs accepting voltage or current via terminal base selection.
        • 100ms low-pass filter and 0.05% voltage linearity deliver stable, accurate readings in electrically noisy plants.
        • Galvanic isolation (850V DC) and hazardous location certification enable safe use in explosive atmospheres.
        The S200-IE8 S200IE8 packs eight analog input channels into a space-saving 94mm wide housing, making it ideal for high-density I/O applications where cabinet space is limited. Each channel is single-ended, meaning the signal is measured relative to a common 0V reference shared among all eight inputs. The 12-bit resolution divides the full-scale range into 4096 discrete steps, providing sufficient granularity for monitoring process variables such as pressure, temperature, flow, and level. Input type selection—voltage or current—is performed at the terminal base using jumpers and must also be configured in the programming software.

        Industrial environments are filled with electrical noise from variable frequency drives, contactors, welders, and radio transmitters, all of which can corrupt low-level analog signals. The S200-IE8 S200IE8 addresses this with a first-order low-pass filter having a 100ms time constant, meaning the output reaches 63% of a step change in 100ms. This filtering smooths out high-frequency fluctuations, producing stable readings that reflect true process values rather than electrical interference. The S200-IE8 S200IE8 achieves 0.05% non-linearity for voltage inputs and 0.10% for current inputs—exceptional linearity that minimizes measurement error across the entire range.

        The S200-IE8 S200IE8 uses optocouplers to provide galvanic isolation between the field inputs and the serial bus. Type-tested at 850V DC for one second, this isolation prevents ground loops—unwanted currents that flow when multiple devices are grounded at different points—from corrupting measurements or damaging the controller. It also protects the system backplane from voltage spikes originating in field wiring. For installations in potentially explosive atmospheres, the S200-IE8 S200IE8 carries CSA certification for Class I Division 2 Groups A, B, C, D with temperature code T6, and European Ex certification for Zone 2 Group II C.

        The S200-IE8 S200IE8 ABB Analog Input Unit may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

        ABB S200-IE8 S200IE8 Analog Input Unit Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        ABB S200-IE8 S200IE8 Analog Input Unit Specs

        General

        • Manufacturer ABB
        • Model S200-IE8 S200IE8
        • Condition New Original ready stock
        • Product Family S200-TB3S S200TB3S,S200-TB3,S200-TBNF
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Process Industry Monitoring: Connects to pressure transmitters, level gauges, and flowmeters in chemical, pharmaceutical, water treatment, and paper plants to capture 4–20 mA signals.
        • Factory Utilities Control: Monitors ancillary factory subsystems such as air compressor pressure, cooling water flow, and boiler water levels.
        • HVAC & Energy Management: Collects data from temperature/humidity sensors and damper position feedbacks for environmental and energy optimization.
        • Operating: 0°C to +55°C (32°F to 131°F).
        • Storage: -40°C to +70°C (-40°F to 158°F).
        • Relative Humidity: 5% to 95% RH (non-condensing).
        • Protection Rating: IP20. It provides no protection against water, moisture, or conductive dust. It must be installed inside a sealed industrial enclosure (cabinet).
        • EMC Compliance: Meets European EMC Directive (2014/30/EU), providing foundational protection against high-frequency electromagnetic interference and electrostatic discharge (ESD).
        • Signal Acquisition & Filtering: Features an input resistance of 205 Ω ± 0.2% and built-in third-order, low-pass filters on each channel to eliminate high-frequency spikes and electrical noise from field cables.
        • Galvanic Isolation: Optocouplers provide electrical isolation between the internal serial backplane and the field input channels, protecting the main PLC/DCS controllers from high-voltage surges or ground loop noise.
        • Network Adaptability: The unit sits on a dedicated terminal base and requires a communication adapter to upload data over standard networks like PROFIBUS DP, ControlNet, or DeviceNet.
        Description
        The S200-IE8 S200IE8 delivers eight single-ended analog inputs. Each channel accepts voltage (±10V, 0-10V, 2-10V) or current (0-20mA, 4-20mA) signals selected via the terminal base. The S200-IE8 S200IE8 requires an external 24V DC supply (60mA typical) since it draws no power from the backplane.

        Signal conditioning on the S200-IE8 S200IE8 includes a first-order low-pass filter with 100ms time constant, reducing noise from industrial environments. The unit achieves 12-bit resolution with voltage non-linearity of 0.05% and current non-linearity of 0.10%.

        Connections for the S200-IE8 S200IE8 vary by terminal base type. On 200-TB2 and 200-TB3 bases, signal wires connect to the upper row, 0V to the middle row, and +24V to the lower row. For 200-TBN bases, terminals 35-50 are used for signal and 34,51 for 0V. The S200-IE8 S200IE8 requires shielded twisted-pair cables for optimal noise rejection.

        Troubleshooting the S200-IE8 S200IE8 involves checking the 24V supply, verifying wiring, and confirming input type selection in the configuration software. A detected break in a 4-20mA loop or erroneous analog values prompts systematic checks of cabling, shielding, and sensor operation.

        Alternative Names
        S2OO-IE8 S2OOIE8 S200-IE8 S200IE8 S200-TB2 S200-TBNF S200-TB3 S200-TB3S S200TB3S S200-OE4 S200OE4
        Technical notes
        The S200-IE8 S200IE8 is an 8-channel analog input unit with 12-bit resolution, supporting ±10V or 0-20mA signals. Features 100ms filtering, 0.05% voltage linearity, and galvanic isolation via optocouplers. Requires external 24V DC (60mA). Certified for Class I Div 2 hazardous areas.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Does S200-IE8 S200IE8 receive power from the terminal base?
        No, the S200-IE8 S200IE8 requires an external 24V DC supply (19.2-31.2V) connected to the terminal base. Without this external power, the adapter sees the slot as empty and the unit will not operate.
        What is the input resistance for current measurements on S200-IE8 S200IE8?
        The current input presents 238Ω, which can be used with a voltmeter (≥10MΩ) to measure voltage and calculate current using I = U / 238. A Zener diode in series is recommended for loop protection.
        Can S200-IE8 S200IE8 be used in hazardous locations?
        Yes, the S200-IE8 S200IE8 carries CSA certification for Class I Division 2 Groups A,B,C,D (T6) and European Ex certification for Zone 2 Group II C, making it suitable for potentially explosive atmospheres.
        What is the purpose of the 100ms filter on S200-IE8 S200IE8?
        The first-order low-pass filter with 100ms time constant attenuates high-frequency noise from motors, drives, and other industrial equipment, providing stable readings at the cost of slower response to signal changes.
