S200-TBNF S200TBNF

/ 4.9
1001 reviews | Need a Specific Revision?
S200-TBNF S200TBNF is a fused terminal base for ABB S200 I/O units, featuring 2 rows of 10 screw terminals, 8 fuses, 10A capacity, and 264V AC rating.
Fast Shipping Available
Get a quick price for S200-TBNF S200TBNF
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for S200-TBNF S200TBNF

  • Manufacturer:
    ABB
  • Part Number:
    S200-TBNF S200TBNF
  • Product Family:
    ABB S200 I/O
  • Product Type:
    I/O Unit
  • Terminal Rows:
    2 rows of 10
  • Current Capacity:
    10 A max
  • Voltage Rating:
    264 V AC max (rms)
  • Fuses:
    8 (5x20 mm)
  • Fuse Function:
    Series protection for upper row channels
  • Upper Row Terminals:
    10 (16,33 = 0V DC; even = signals)
  • Lower Row Terminals:
    10 (34,51 = +24V DC; odd = signals)
  • Wire Size (Solid/Stranded):
    0.5-2.5 mm² (AWG 20-12)
  • Operating Temperature:
    0°C to +55°C
  • Non-operating Temperature:
    -40°C to +85°C
  • Humidity:
    5-95% non-condensing
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    9.7x9.5x5.7cm
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Compatibility Certifications

Features:

  • S200-TBNF S200TBNF provides eight 5x20mm fuses protecting upper row output channels from overcurrent faults.
  • Two rows of 10 screw terminals support 24V DC and 230V AC with 10A current and 264V rating.
  • CSA certified with wide operating temperature 0-55°C and storage from -40°C to +85°C.
The S200-TBNF S200TBNF distinguishes itself from standard terminal bases by incorporating eight 5x20mm fuse holders directly on the board, connected in series with the eight channels on the upper terminal row. Each fuse protects an individual output signal path from overcurrent conditions such as short circuits or excessive load currents. When a fault occurs, only the affected channel's fuse opens, leaving other channels operational and simplifying troubleshooting. The fuses are field-replaceable without removing the terminal base or I/O unit, minimizing downtime.

The S200-TBNF S200TBNF supports both 24V DC and 230V AC field connections, offering exceptional flexibility for mixed-voltage I/O systems. The screw terminals are well insulated to handle higher voltages safely, with a maximum rating of 264V AC (rms) and 10A current capacity. This allows the same terminal base to interface with low-voltage DC sensors and actuators as well as high-voltage AC devices such as contactors, motor starters, and pilot lights.

The S200-TBNF S200TBNF measures just 97mm wide × 94mm high × 48mm deep (72mm with an I/O unit inserted), making it suitable for high-density control cabinets where space is at a premium. Despite its compact size, it accepts solid or stranded copper wire from 0.5 to 2.5 mm² (AWG 20-12), providing secure connections for a wide range of field wiring gauges.

The S200-TBNF S200TBNF ABB  I/O Unit may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

ABB S200-TBNF S200TBNF I/O Unit Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB S200-TBNF S200TBNF I/O Unit Specs

General

  • Manufacturer ABB
  • Model S200-TBNF S200TBNF
  • Condition New Original ready stock
  • Product Family S200-PS13 S200PS13,S200-TB3S S200TB3S,S200-IE8 S200IE8
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Hazardous & High-Risk Infrastructure: Deployed extensively in petrochemical, oil and gas, and chemical processing plants where field instrumentation wiring is susceptible to faults or overcurrent.
  • Critical Load Isolation: Used to connect high-risk field actuators, heavy-duty solenoids, and field switches, ensuring that an electrical fault on a single device is contained locally.
  • Distributed Industrial Automation: Complements ABB’s legacy control architectures (SattLine, SattCon 200, AC250) in environments that mandate strict physical fusing between the control room and field wiring.
  • Module Compatibility: Fully compatible with standard ABB S200 and S200C digital input/output modules (such as 24V DC or 120V AC digital units). Electronic modules slide on top and mate directly via its integrated plug-in interface.
  • Interlocking DIN-Rail Backplane: Snapping the S200-TBNF next to other S200 series bases (like the TB2 or TB3) instantly bridges the internal serial communication and power distribution buses, eliminating complex backplane wiring harness configurations.
  • Network Interoperability: Relies on standard S200 network adapters to seamlessly bridge field signals to enterprise automation networks including PROFIBUS DP, DeviceNet, or ControlNet.
  • Global Electrical Safety: Certified under UL (Underwriters Laboratories) and CSA (Canadian Standards Association) for industrial control equipment, validating its electrical fire prevention and flame-retardant casing.
  • European Market Compliance: Carries the CE mark, meeting both the Low Voltage Directive and the Electromagnetic Compatibility (EMC) Directive.
  • Marine & Heavy Industrial Compliance: Certified by major marine classification societies (such as DNV, GL, or Lloyd's Register depending on system assembly), making it robust enough to handle the thermal cycles, continuous vibrations, and shocks found on offshore platforms and maritime vessels.
Description
The S200-TBNF S200TBNF provides a fused interface between ABB S200 I/O units and field devices, supporting both 24V DC and 230V AC connections. This terminal base features two rows of 10 screw terminals with excellent insulation for high-voltage applications.

On the S200-TBNF S200TBNF, the upper row has 10 screw terminals where terminals 16 and 33 are dedicated to 0V DC, and even-numbered terminals carry input/output signals. This row is secured by fuses. The lower row consists of 10 screw terminals where terminals 34 and 51 provide +24V DC connection, and odd-numbered terminals carry input/output signals.

The S200-TBNF S200TBNF accepts solid or stranded copper wire from 0.5 to 2.5 mm² (AWG 20-12) with a current capacity of 10A maximum and voltage rating of 264V AC max (rms).

The S200-TBNF S200TBNF carries CSA certification and includes a backplane code key determined by the inserted I/O unit. Isolation voltage is channel-to-channel as determined by the specific I/O unit installed.
Alternative Names
S2OO-TBNF S2OOTBNF S200-TBNF S200TBNF S200-TB3 S200TB3 S200-TB2 S200TB2 S200-IE8 S200IE8 S200-TB3S S200TB3S S200-PS13 S200PS13
Technical notes
The S200-TBNF S200TBNF is a fused terminal base with two rows of 10 screw terminals. Rated 10A, 264V AC. Includes eight 5x20mm fuses protecting upper row channels. Accepts AWG 20-12 wire.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the purpose of fuses on S200-TBNF S200TBNF?
S200-TBNF S200TBNF includes eight 5x20mm fuses in series with upper row channels, protecting each output signal path from overcurrent damage.
What voltage levels can S200-TBNF S200TBNF handle?
S200-TBNF S200TBNF supports both 24V DC and 230V AC connections with excellent insulation, rated at 264V AC max.
How many terminals does S200-TBNF S200TBNF provide?
S200-TBNF S200TBNF provides two rows of 10 screw terminals, with dedicated 0V and +24V connections plus signal terminals.
Is S200-TBNF S200TBNF compatible with 200-OW8?
Yes, S200-TBNF S200TBNF can be used with the 200-OW8 unit, but refer to specific installation instructions for that configuration.
