Allen-Bradley 1786-BNC is a plug-style coaxial BNC connector for standard ControlNet trunk-cable and tap connections.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1786-BNC
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1786-BNC

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1786-BNC
  • Product Family:
    1786 Repeaters
  • Product Type:
    ControlNet Media Coaxial BNC Connector
  • Stock:
    1
  • Connector Type:
    Coaxial BNC plug
  • Network Media:
    ControlNet coax
  • Connection Method:
    Twist-lock BNC
  • Documented Use:
    Attach a coax trunk-cable section to a tap BNC connector
  • Temperature Rating:
    -20°C to +80°C
  • Characteristic Impedance:
    75 Ω
  • Cable Termination Type:
    Crimp type
  • Degree of Protection:
    IP20
  • Recommended Installation Tool:
    1786-CTK ControlNet Coax Toolkit
  • Tariff Code:
    8536909000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Cable Preparation Connector Fit Media Test Application
  • Plug-style BNC connector for ControlNet coax
  • Used at trunk-cable and tap interfaces
  • Standard twist-lock connection for appropriate environments

1786-BNC completes a ControlNet coax cable end so it can engage the matching tap connector.

Network reliability depends on the prepared center conductor and shield being held in the intended mechanical relationship inside the connector.

Media testing after assembly helps distinguish connector faults from topology, terminator, or cable-length problems.

Availability, condition, price, and shipping time for 1786-BNC are confirmed during quotation.
