5069-L306ERS2

/ 4.9
1001 reviews | Need a Specific Revision?
Sized for compact SIL 2 machines, Allen-Bradley 5069-L306ERS2 separates 0.6 MB standard and 0.3 MB safety memory within an eight-module, sixteen-node architecture.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 5069-L306ERS2
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 5069-L306ERS2

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    5069-L306ERS2
  • Product Family:
    CompactLogix 5069
  • Product Type:
    Compact GuardLogix 5380 SIL 2 Controller
  • Stock:
    1
  • Standard user memory:
    0.6 MB
  • Safety user memory:
    0.3 MB
  • Local Compact 5000 I/O:
    8 modules max
  • EtherNet/IP nodes:
    16 max with Logix Designer v31 or later
  • Controller tasks:
    31 standard tasks and 1 safety task
  • Embedded ports:
    2 Ethernet ports and 1 USB 2.0 Type B port
  • Ethernet modes:
    Dual-IP or Linear/DLR
  • MOD power:
    18...32 V DC SELV/PELV
  • Power dissipation:
    9 W max
  • Mounting:
    Horizontal DIN rail
  • Operating temperature:
    0...60 °C
  • Relative humidity:
    5...95% noncondensing
  • Weight:
    0.768 kg
  • Estimated shipping dimensions:
    14.397 x 9.81 x 13.681 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Multiple
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Safety Memory Local I/O Validation Product Applications

Features:

  • Entry safety controller: standard execution plus one SIL 2 safety task
  • Split resources: 0.6 MB standard and 0.3 MB safety memory
  • Compact architecture: embedded Ethernet with a small local I/O bank
5069-L306ERS2 is intended for machines whose standard and safety scope is deliberately compact.

The controller rewards an early, fixed I/O and network plan because its resource envelope is intentionally small.

Commissioning evidence should bind the exact Series, firmware, project, safety signature, proof test, and local I/O inventory.

Apter Power can coordinate official-document review, quotation, and sourcing support for 5069-L306ERS2.
Allen-Bradley 5069-L306ERS2 Compact GuardLogix 5380 SIL 2 Controller Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Separate Safety Memory Control

  • Independent pools: monitor standard and safety compiled use as separate limits.
  • Change reserve: retain approved capacity for diagnostics and controlled future updates.
  • Release record: link every accepted safety build to its signature and proof-test result.

Compact Local I/O Boundary

  • Local scope: keep the bank within the documented eight-module limit.
  • Remote growth: include adapters and connections in the Ethernet project plan.
  • Ownership: verify every standard and safety module after a hardware change.

Safety Validation Records

  • Controlled archive: preserve the approved project and controller definition.
  • Proof testing: exercise affected safety functions before enabling production.
  • Traceability: retain signature, fault checks, approver, and rollback evidence.

Product Applications

  • Compact safety cells: combine standard sequencing with one SIL 2 safety task.
  • Small local systems: control a limited Compact 5000 standard and safety I/O bank.
  • Documented machine networks: use embedded EtherNet/IP within a controlled topology.
Description
5069-L306ERS2 is the entry Compact GuardLogix 5380 controller for small SIL 2 machine-safety projects. It separates 0.6 MB of standard memory from 0.3 MB of safety memory and executes one safety task alongside the standard application.

The compact architecture of 5069-L306ERS2 supports a local bank of standard or safety Compact 5000 I/O and embedded EtherNet/IP networking. Its limited local and network scope makes early control of the I/O list and safety data more important than later optimization.

Use 5069-L306ERS2 only when the compiled project, safety signature, local I/O, and approved network plan fit with measured reserve. Match Series and firmware before download, then complete the full safety validation whenever logic or safety hardware changes.
Revisions

Revision Part #

Also known as

5069-L306ERS2 Series A
5069-L306ERS2/A, Series A
5069-L306ERS2 Series B
5069-L306ERS2/B, Series B
Alternative Names
Allen-Bradley 5069-L306ERS2 Rockwell Automation 5069-L306ERS2 AB 5069-L306ERS2 5069L306ERS2 5069 L306ERS2 Compact GuardLogix 5380 entry SIL 2 controller
Technical notes
Late safety additions can exhaust the separate safety-memory pool of 5069-L306ERS2 even when standard memory remains available. Track both compiled totals, protect the approved signature, and repeat the documented validation whenever safety logic, diagnostic data, or the local safety-I/O configuration changes; retain the new proof-test evidence with the released archive.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why can 5069-L306ERS2 run out of safety capacity while standard logic still compiles?
The controller maintains separate standard and safety memory pools, so growth in one does not consume unused space from the other; review both totals independently.
What indicates that a 5069-L306ERS2 project has outgrown its compact architecture?
The verified design exceeds the local I/O boundary, network scope, standard or safety memory reserve, or requires expansion that cannot be validated within the approved layout.
How should remote I/O be evaluated for 5069-L306ERS2 after the local bank is full?
Count the adapter and devices, verify safety connection paths, recalculate network capacity and timing, document power, and repeat the affected safety acceptance tests.
Why might a replacement 5069-L306ERS2 reject the stored safety signature?
A different controller Series, firmware, project build, safety configuration, or ownership state can invalidate the expected signature; compare the controlled records before downloading again.
When should Dual-IP be avoided on 5069-L306ERS2?
Avoid adding two-network complexity unless the approved cell design needs separate addressing and includes documented routing, diagnostics, access control, and recovery tests.
What should be supplied when ordering 5069-L306ERS2 for a shutdown?
Provide full nameplates, Series and firmware, compiled memory use, local and remote I/O lists, topology, RTB style, condition, quantity, destination, and outage date.
