1756-IR6I/A

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1756-IR6I/A is a ControlLogix six-channel isolated RTD and resistance input module.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 1756-IR6I/A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1756-IR6I/A

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1756-IR6I/A
  • Product Family:
    ControlLogix
  • Product Type:
    Isolated RTD Input Module
  • Stock:
    1
  • Input Channels:
    6 individually isolated
  • Input Type:
    RTD and resistance
  • RTD Wiring:
    2-wire, 3-wire, or 4-wire
  • Resistance Ranges:
    1...487 Ω; 2...1000 Ω; 4...2000 Ω; 8...4000 Ω
  • Resolution:
    16 bit
  • Isolation:
    250 V continuous, channel-to-backplane and channel-to-channel
  • Operating Temperature:
    0...60 °C
  • Relative Humidity:
    5...95% noncondensing
  • Weight:
    0.4 kg
  • Estimated shipping dimensions:
    3.8 x 15.2 x 14.0 cm
  • Tariff Code:
    85389091
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Configuration Environment

Features:

  • Catalog number: 1756-IR6I/A, Series A.
  • Provides six individually isolated RTD and resistance inputs.
  • Supports 2-wire, 3-wire, and 4-wire RTD connections.
  • Used for temperature and resistance measurement in ControlLogix systems.
1756-IR6I/A is a ControlLogix I/O module for industrial automation applications.

Use the complete catalog or order code and documented channel, signal, wiring, and terminal requirements when planning installation or replacement.

Allen-Bradley 1756-IR6I/A Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the stock item description. All prices are shown in USD.
1756-IR6I/A Technical Specifications

Technical Specifications

  • Input Channels6 individually isolated
  • Input TypeRTD and resistance
  • RTD Wiring2-wire, 3-wire, or 4-wire
  • Resistance Ranges1...487 Ω; 2...1000 Ω; 4...2000 Ω; 8...4000 Ω
  • Resolution16 bit
  • Isolation250 V continuous, channel-to-backplane and channel-to-channel
  • Operating Temperature0...60 °C
  • Measuring temperature with compatible industrial RTDs.
  • Monitoring resistance inputs in ControlLogix systems.
  • Collecting isolated sensor signals from process equipment.
  • Integrating multi-wire RTD measurements into control projects.
  • Six individually isolated input channels.
  • Supports 2-wire, 3-wire, and 4-wire RTDs.
  • Resistance ranges: 1...487 Ω, 2...1000 Ω, 4...2000 Ω, and 8...4000 Ω.
  • Resolution: 16 bit.
  • Operating temperature: 0...60 °C.
  • Nonoperating temperature: -40...85 °C.
  • Relative humidity: 5...95% noncondensing.
  • Vibration: 2 g at 10...500 Hz.
Description
The <strong>Allen-Bradley 1756-IR6I/A</strong> is a a ControlLogix isolated RTD and resistance input module. It provides six individually isolated input channels.<br />
<br />
The module supports 2-wire, 3-wire, and 4-wire RTD connections. Resistance input ranges include 1...487 Ω, 2...1000 Ω, 4...2000 Ω, and 8...4000 Ω with 16-bit resolution.<br />
<br />
The 1756-IR6I/A is used for temperature and resistance measurement in ControlLogix systems. Sensor type, wiring, scaling, and project configuration must be verified against the applicable Rockwell Automation documentation.
Revisions

Revision Part #

Also known as

1756-IR6I Ser A
1756-IR6I/A, Series A, Rev A
Alternative Names
1756-IR6I/A 1756 IR6I A 1756IR6IA AB 1756-IR6I/A Allen-Bradley 1756-IR6I/A
Technical notes
Allen-Bradley 1756-IR6I/A is a ControlLogix RTD and resistance input module with six individually isolated channels. It supports 2-wire, 3-wire, and 4-wire RTDs.
