1747-L532

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1747-L532 is an SLC 5/03 modular controller with 16K words of memory, DH-485 networking and an RS-232 serial channel.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1747-L532
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1747-L532

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1747-L532
  • Product Family:
    SLC 500
  • Product Type:
    SLC 5/03 16K Controller
  • Stock:
    1
  • User memory:
    16K words
  • Built-in communications:
    DH-485 and RS-232
  • Local chassis support:
    Up to 3 chassis; 30 local I/O slots
  • Maximum discrete I/O:
    4096 inputs and 4096 outputs
  • Typical program scan:
    1 ms per K word
  • Typical XIC execution:
    0.44 µs
  • Optional memory module:
    1747-M13 Flash EPROM for supported Series C or later OS firmware
  • Backplane current:
    500 mA at 5 VDC; 175 mA at 24 VDC
  • Clock accuracy:
    ±54 seconds/month at 25°C; ±81 seconds/month at 60°C
  • Operating temperature:
    0 to +60°C
  • Storage temperature:
    -40 to +85°C
  • Relative humidity:
    5 to 95%, non-condensing
  • Dimensions:
    3.46 × 13.9 × 13.02 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Program Memory Communications Startup Application
  • Use 1747-L532 only for the documented SLC 5/03 16K controller role
  • Preserve the RSLogix 500 project and both communication-channel configurations
  • Confirm processor series, operating system, chassis power and I/O map before replacement

Allen-Bradley 1747-L532 is a 16K-word SLC 5/03 controller for modular SLC 500 systems.

Allen-Bradley 1747-L532 is an SLC 5/03 modular controller with 16K words of memory, DH-485 networking and an RS-232 serial channel. 1747-L532 is the complete catalog number for the SLC 5/03 16K controller. Official conformity documentation identifies Series 1 hardware; the current lifecycle page lists the catalog as discontinued.

Before installation or replacement, verify the complete nameplate, compatible companion hardware, wiring or network design, saved configuration and commissioning plan.

Availability, condition, price, and shipping time for 1747-L532 are confirmed during quotation.

Allen-Bradley 1747-L532 SLC 5/03 16K Controller Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Verify the approved project fits the 16K-word controller
  • Back up program, data tables, passwords and channel configuration
  • Use a supported 1747-M13 module only when the recovery plan requires it
  • Restore the documented DH-485 node, rate and cable topology
  • Restore the RS-232 protocol, baud rate and device parameters
  • Check every HMI, programming station or ASCII device before service
  • Confirm processor series and operating-system compatibility
  • Verify all local chassis and slot definitions before entering RUN
  • Review faults, clock, battery and controlled machine response after download
  • Modular SLC 500 machine and process control with up to three local chassis
  • DH-485 networked SLC 500 control and data sharing
  • RS-232 connection to programming workstations, HMIs or supported ASCII devices
Description
1747-L532 is the 16K-word SLC 5/03 controller with built-in DH-485 and RS-232 communications for modular SLC 500 systems.

Selection must match the processor series, operating system, project size, chassis and I/O layout, communication settings and any supported 1747-M13 recovery plan.

Before replacement, preserve the RSLogix 500 project, data tables, passwords, channel configuration, node addresses, I/O map, clock and active faults.
Revisions

Revision Part #

Also known as

1747-L532 Ser A
1747-L532/A, Series A, Rev A
Alternative Names
1747-L532 1747 L532 1747L532 Allen-Bradley 1747-L532 AB 1747-L532 SLC 5/03 1747-L532 1747-L532/A 1747-L532 Series A
Technical notes
1747-L532 is the 16K SLC 5/03 controller with built-in DH-485 and RS-232 channels. Preserve the RSLogix 500 project, operating-system/series compatibility, network identities and I/O configuration before replacement.
