    Apter Power coordinates condition review, documentation, quotation, and pre-shipment identity checks for this legacy Ethernet interface.

1785-ENET

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1785-ENET is a PLC-5 Ethernet interface module that adds TCP/IP messaging and web-based diagnostics to a controller installed in a 1771 chassis.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1785-ENET
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1785-ENET

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1785-ENET
  • Product Family:
    PLC-5
  • Product Type:
    Ethernet Interface Module
  • Stock:
    1
  • Backplane Current:
    1.0 A at 5 V DC
  • Power Dissipation:
    5 W
  • Communication:
    Ethernet TCP/IP via 8-pin RJ45
  • Isolation Voltage:
    50 V basic insulation
  • Ethernet Wiring:
    IEEE 802.3 compliant twisted pair
  • Documented Revision:
    Series C, Revision B
  • Weight:
    0.77 kg
  • Estimated shipping dimensions:
    27.305 × 3.175 × 14.605 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Chassis & Port IP Commissioning Module Diagnostics Product Applications

Features:

  • PLC-5 controller Ethernet access through a 1771 chassis
  • TCP/IP messaging through an 8-pin RJ45 port
  • Web-accessible connection and application diagnostics
Allen-Bradley 1785-ENET places Ethernet communication beside the PLC-5 controller rather than replacing the controller architecture.

Its diagnostic pages help maintenance teams review connection use, protocol activity, and module fault conditions without reducing the interface to a simple network adapter.

Commissioning depends on the documented chassis, IP-address method, controller message paths, and module Series; these records should be captured before a field exchange.

Apter Power can align 1785-ENET sourcing with the installed PLC-5 chassis, module Series, and available network records.
1785-ENET Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Use a properly installed 1771 I/O chassis
  • Reserve 1.0 A from the 5 V DC backplane
  • Connect Ethernet through the shielded RJ45 port
  • Prepare the BOOTP entry before chassis power-up
  • Cycle chassis power after the address record is ready
  • Document the assigned IP address and PLC-5 message path
  • Interpret the status LED before opening deeper diagnostics
  • Review Ethernet statistics for link and packet activity
  • Use application statistics to inspect CSP and CIP connections
  • Correlate transfer fault codes with the controller program
  • Connect PLC-5 controllers to documented TCP/IP communication paths
  • Support legacy controller messaging within 1771-based systems
  • Expose interface diagnostics during maintenance of installed PLC-5 networks
Description
The Allen-Bradley 1785-ENET is a PLC-5 Ethernet interface module for a 1771 I/O chassis. Rockwell Automation publication 1785-IN019 identifies the Series C, Revision B configuration and its 8-pin RJ45 TCP/IP connection.

Through the Allen-Bradley 1785-ENET, a PLC-5 controller can exchange message instructions with Ethernet PLC-5 controllers and other supported TCP/IP destinations. Its built-in diagnostic pages expose communication statistics, connection activity, and module status for legacy network maintenance.

When planning a chassis installation, treat the Allen-Bradley 1785-ENET as a controller-side interface rather than a standalone Ethernet switch. The 1771 chassis, available backplane current, IP-address method, RSLogix 5 project, and installed module Series must agree with the documented configuration.
Revisions

Revision Part #

Also known as

1785-ENET Ser A
1785-ENET/A, Series A, Rev A
1785-ENET Ser B
1785-ENET/B, Series B, Rev B
1785-ENET Ser C
1785-ENET/C, Series C, Rev C
Alternative Names
Allen-Bradley 1785-ENET module 1785 ENET 1785ENET PLC-5 Ethernet Interface AB PLC-5 Ethernet module
Technical notes
Allen-Bradley 1785-ENET requires a properly installed 1771 chassis and adequate 5 V backplane capacity before addressing begins. For Series C Revision B, establish the IP method before controller messaging, then use the module status LED and diagnostic pages to separate network faults from controller-to-module transfer faults.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does 1785-ENET obtain an IP address during commissioning?
Rockwell documents BOOTP-based configuration and a power cycle after the server entry is prepared. Record the assigned address before testing PLC-5 message instructions.
What should 1785-ENET diagnostics be used to investigate first?
Begin with the status LED state, then review Ethernet and application-level statistics to distinguish link, connection, or controller-transfer problems.
Can 1785-ENET be treated as a general plant-network switch?
No. It is a PLC-5 chassis interface for controller communications; network switching and plant segmentation require separate infrastructure.
Which chassis checks matter before 1785-ENET is installed?
Confirm a correctly installed 1771 chassis, sufficient 5 V backplane current, the module slot, and clearance for the RJ45 cable.
How should 1785-ENET message routing be reviewed in an existing project?
Check every MSG destination, IP address or symbolic entry, and the PLC-5 controller path against the documented network design before download.
What evidence should accompany a request for 1785-ENET replacement support?
Provide the module Series, controller catalog, chassis slot, current IP method, RSLogix 5 version, and a description of the observed LED or diagnostic condition.
