Allen-Bradley 2711P-B10C4A9 is a 10.4-inch PanelView Plus 6 color terminal with keypad and resistive touch input.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 2711P-B10C4A9
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2711P-B10C4A9

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2711P-B10C4A9
  • Product Family:
    Panelview Plus
  • Product Type:
    PanelView Plus 6 1000 Keypad/Touch Terminal
  • Stock:
    1
  • Display:
    10.4 in color TFT
  • Resolution:
    640 × 480, 18-bit color graphics
  • Operator Input:
    Keypad and 8-wire analog resistive touchscreen
  • Communication Ports:
    10/100 Mbps Ethernet, RS-232, and two USB host ports
  • Input Power:
    100...240 V AC at 50...60 Hz
  • Power Consumption:
    160 VA maximum; 65 VA typical
  • Memory:
    512 MB RAM; 512 MB nonvolatile memory; approximately 79 MB free user memory
  • Operating System:
    Windows CE 6.0 with extended features
  • Dimensions:
    39.9 × 24.8 × 5.5 cm
  • FactoryTalk View:
    FactoryTalk View ME Station 6.0 or later
  • FactoryTalk ViewPoint:
    Version 1.2 or later
  • Front Protection:
    NEMA Type 12, 13, 4X indoor; IP54/IP65
  • Weight:
    2.8 kg
  • Tariff Code:
    8471609000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Touchscreen Storage Migration Application
  • PanelView Plus 6 1000 operator terminal with combined keypad and resistive touch input
  • Windows CE 6.0 platform with FactoryTalk View ME Station runtime support
  • Standard Ethernet and RS-232 communication with removable-storage support

2711P-B10C4A9 provides a color operator interface for a PanelView Plus 6 application that requires both physical keys and touch input.

Its application, communication configuration, optional network interface, user files, and terminal cutout must be documented before the original unit is removed.

When migrating to 2711P-B10C22A9P, review the display-resolution change, supported features, adapter-kit requirements, and FactoryTalk View ME project compatibility.

Availability, condition, price, and shipping time for 2711P-B10C4A9 are confirmed during quotation.

Allen-Bradley 2711P-B10C4A9 PanelView Plus 6 Terminal Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Eight-wire analog resistive touch technology
  • Touch actuation rating of one million presses
  • Specified operating force of 10...110 g
  • Hot-swappable SD slot supports 1784-SDx and 1784-SDHCx cards
  • High-speed USB 2.0 host ports support removable USB flash drives
  • Removable media can be used for file transfer, firmware upgrades, or data logging
  • Rockwell Automation lists 2711P-B10C22A9P as the engineering replacement
  • Adapter kit 2711P-RAAK10 supports the PanelView Plus 6 1000 migration path
  • The replacement display uses 800 × 600 resolution, requiring application review
  • Machine operator interfaces requiring color graphics and combined keypad/touch input
  • FactoryTalk View ME applications requiring Ethernet and RS-232 connectivity
  • Panel-mounted indoor systems designed for the terminal's documented enclosure ratings
Description
2711P-B10C4A9 is an Allen-Bradley PanelView Plus 6 1000 operator terminal with a 10.4-inch color TFT, 640 × 480 resolution, keypad input, and an 8-wire analog resistive touchscreen.

The terminal operates from 100...240 V AC at 50...60 Hz and provides 10/100 Mbps Ethernet, RS-232, and two USB host ports. It contains 512 MB RAM and 512 MB nonvolatile memory and runs Windows CE 6.0 with extended features.

Before replacing 2711P-B10C4A9, preserve the FactoryTalk View ME application and verify its runtime version, communication interfaces, terminal cutout, power wiring, optional network module, and the display-resolution differences of the engineering replacement.
Alternative Names
2711P-B10C4A9 2711PB10C4A9 2711P B10C4A9 Allen-Bradley 2711P-B10C4A9 Allen Bradley 2711P-B10C4A9 AB 2711P-B10C4A9 Rockwell Automation 2711P-B10C4A9 PanelView Plus 6 2711P-B10C4A9
Technical notes
For Allen-Bradley 2711P-B10C4A9, back up the FactoryTalk View ME application and confirm the terminal cutout, AC power, communication ports, optional network module, and replacement-display resolution before migration.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can an existing FactoryTalk View ME application be migrated from Allen-Bradley 2711P-B10C4A9?
Yes. Rockwell Automation identifies FactoryTalk View ME Station 6.0 or later for Allen-Bradley 2711P-B10C4A9. Back up the application, confirm its runtime version and review display scaling before moving it to the engineering replacement.
Which communication connections should be matched when replacing Allen-Bradley 2711P-B10C4A9?
Allen-Bradley 2711P-B10C4A9 provides 10/100 Mbps Ethernet, RS-232 and two USB host ports, with support for an optional network interface module. Verify every installed interface before choosing a replacement terminal.
Can Allen-Bradley 2711P-B10C4A9 use removable storage for application transfer?
Yes. The terminal supports hot-swappable 1784-SDx or 1784-SDHCx Secure Digital cards and USB flash drives for file transfer, firmware upgrades or data logging.
Is the backlight of Allen-Bradley 2711P-B10C4A9 field-replaceable?
Yes. Rockwell Automation specifies a field-replaceable CCFL backlight with a minimum rated life of 50,000 hours at 25 °C.
Will the engineering replacement for Allen-Bradley 2711P-B10C4A9 fit the existing panel cutout?
Rockwell Automation lists 2711P-B10C22A9P as the engineering replacement and identifies adapter kit 2711P-RAAK10 for the PanelView Plus 6 1000 migration path. Confirm the installed cutout and adapter requirements before ordering.
Can Allen-Bradley 2711P-B10C4A9 be used where the front of the terminal needs an industrial enclosure rating?
The terminal carries front-side ratings including NEMA Type 12, 13 and 4X for indoor use, plus IP54/IP65. Final enclosure compliance depends on correct installation and sealing.
What information should be supplied when requesting Allen-Bradley 2711P-B10C4A9?
Provide the complete catalog number, keypad/touch requirement, AC power, communication interfaces, optional network module, FactoryTalk View ME version, panel-cutout details, quantity and required condition.
