2711P-T10C4D1

/ 4.9
1001 reviews | Need a Specific Revision?
The 2711P-T10C4D1 is a PanelView Plus and PanelView Plus CE 1000 color operator interface terminal, suitable for monitoring machine status, process data, and operator interaction in manufacturing and process applications.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for 2711P-T10C4D1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2711P-T10C4D1

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2711P-T10C4D1
  • Product Family:
    Panelview Plus
  • Product Type:
    PanelView Plus 1000 Industrial HMI Terminal
  • Stock:
    1
  • Product Series:
    PanelView Plus and PanelView Plus CE
  • Screen Size:
    10.4-inch
  • Display Type:
    1000 Color
  • Input Voltage:
    24 VDC nominal (18...32 VDC range)
  • Power Supply:
    DC Input
  • Memory Configuration:
    64 MB Flash/RAM
  • Input Power:
    18 to 32 VDC
  • Communication Cable:
    1761-NET-ENI
  • Series:
    Ser A, B, C, D, and F
  • Enclosure Rating:
    NEMA 12, 13, 4X, IP54, IP66
  • Communication Ports:
    Ethernet (10/100Base-T), RS-232, 2 x USB Host
  • Display Resolution:
    640 x 480 VGA (18-bit color graphics)
  • Operator Input:
    Analog Resistive Touchscreen
  • Weight:
    2.64 kg
  • Estimated shipping dimensions:
    33x25x7.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Configuration & Programming Installation & Integration Certifications

Features:

  • Connection between operator and industrial control system
  • Combines color visualization and standard communication support
  • Compatible with PanelView Plus and PanelView Plus CE series
The 2711P-T10C4D1 operates as the 1000 Color Terminal in a PanelView Plus system, providing reliable HMI functionality for industrial automation applications. It continuously processes incoming data through Standard Communication (Ethernet and RS-232) and displays critical process information on its 10.4-inch color screen to support steady state operation of connected controllers and devices. Seamless communication transfer is standard with the 2711P-T10C4D1, however using an optional network configuration will allow seamless switchover to a backup connection in the event of a primary communication failure. The 2711P-T10C4D1 has made improvements in several areas over previous terminal designs in addition to incorporating universal communication capability within the PanelView Plus rack.

The 2711P-T10C4D1 provides essential visualization functions common to the entire system, and is a critical component of the control path, directly affecting the proper, normal operation of the overall monitoring system. One 2711P-T10C4D1 terminal is required per operator station depending on the desired interface level. The 2711P-T10C4D1 occupies a compact panel-mount footprint and is always located at the operator position (front panel installation, the dedicated HMI slot).

For Dual Communication applications, the PanelView Plus System requires a second communication interface configured within the 2711P-T10C4D1 terminal. In addition to standard single communication operation, the redundant configuration also performs automatic switchover. The 2711P-T10C4D1 dual communication configuration executes failover using the internal circuitry specified in the communication options. Using this method, the redundant communication system continually monitors the health of both connections. If the system detects that the primary communication is no longer providing stable data transfer (outside configured tolerance levels), it will automatically transfer the load to the secondary connection and place an event in the System Event List.

The 2711P-T10C4D1 PanelView Plus and PanelView Plus CE 1000 Color Terminal with DC Input and 64 MB Flash/RAM may still be available for purchase and support from authorized distributors beyond End-Of-Life (EOL) by the manufacturer (OEM).

Allen-Bradley 2711P-T10C4D1 PanelView Plus Manuals, Datasheets, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Allen-Bradley 2711P-T10C4D1 PanelView Plus

General

  • Manufacturer Allen-Bradley
  • Model 2711P-T10C4D1
  • Condition New Original ready stock
  • Product Family 2711P-T10C4D2,2711P-K10C4D1,2711P-B10C4D1
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Utilizes FactoryTalk View Studio for Machine Edition software to author and compile HMI application files.
  • Executes compiled runtime (.MER) files via the pre-installed FactoryTalk View ME runtime engine.
  • Supports desktop transfer, network download, or removable USB/SD card loading for runtime project deployment.
  • Mounts into enclosure cutouts using perimeter mounting levers to secure a uniform NEMA/IP front seal.
  • Connects directly to Logix control systems via EtherNet/IP protocol over standard CAT5/6 cabling.
  • Features modular architecture allowing separate field replacement of the display module or logic module.
  • Certified for Class I Div 2, Groups A, B, C, D, and Class II Div 2 hazardous location operations.
  • Meets c-UL-us listed, CE marked, and C-Tick compliance standards for global industrial deployment.
  • Front bezel rated NEMA Type 12, 13, 4X (indoor use), IP54, and IP66 for ingress protection.
Description
2711P-T10C4D1 is a PanelView Plus and PanelView Plus CE 1000 Color operator interface terminal designed for reliable visualization and control in industrial automation systems. This model provides a 10-inch class color display environment suitable for monitoring machine status, process data, and operator interaction in manufacturing and process applications.

The 2711P-T10C4D1 supports standard communication via Ethernet and RS-232, enabling flexible integration with PLCs, controllers, and plant networks. Its communication capability allows efficient data exchange, remote access, and system diagnostics within distributed control architectures.

In terms of hardware configuration, the unit operates on DC input power and is equipped with 64 MB Flash and 64 MB RAM, providing sufficient memory resources for runtime applications, graphics, and data handling. This combination makes the 2711P-T10C4D1 well suited for typical HMI tasks in industrial environments where dependable performance and straightforward connectivity are required.
Revisions

Revision Part #

Also known as

2711P-T10C4D1 Ser A
2711P-T10C4D1/A, Series A, Rev A
2711P-T10C4D1 Ser B
2711P-T10C4D1/B, Series B, Rev B
2711P-T10C4D1 Ser C
2711P-T10C4D1/C, Series C, Rev C
2711P-T10C4D1 Ser D
2711P-T10C4D1/D, Series D, Rev D
2711P-T10C4D1 Ser E
2711P-T10C4D1/E, Series E, Rev E
2711P-T10C4D1X
2711P-T10C4D1/X, Series X, Rev X
Alternative Names
2711P-T10C4D1 2711PT10C4D1 2711P T10C4D1 2711P-T10C4D2 Allen Bradley 2711P-T10C4D1 AB 2711P-T10C4D1 PanelView 2711P-T10C4D1 PanelView Plus 1000 2711P-T10C4D1
Technical notes
The Allen-Bradley 2711P-T10C4D1 module, the ground wire must be properly connected to prevent electrostatic interference; the application project file must be compiled and transferred using FactoryTalk View Studio.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which communication protocols and physical interfaces are supported by the Allen-Bradley 2711P-T10C4D1?
The Allen-Bradley 2711P-T10C4D1 features a 10/100Base-T Ethernet port for EtherNet/IP communications, an RS-232 serial port for direct controller links, and dual USB ports for peripheral devices and firmware management.
Does this operator support DH+ communication?
Yes. DH+ is supported with the addition of DH+ communication module.
Does this operator terminal come with a replaceable logic module?
Yes. The logic module of the 2711P-T10C4D1 has a replaceable logic module.
What is the screen resolution of the 2711P-T10C4D1?
The 2711P-T10C4D1 has resolution of 640 x 400 pixels.
Which HMI software is used to design and run applications on the Allen-Bradley 2711P-T10C4D1?
Applications for the Allen-Bradley 2711P-T10C4D1 are configured using FactoryTalk View Studio for Machine Edition (ME) and executed on the terminal's pre-installed FactoryTalk View ME Runtime software.
