4PP220.0571-45

/ 4.9
1001 reviews | Need a Specific Revision?
B&R 4PP220.0571-45 is a 5.7-inch monochrome Power Panel PP220 controller HMI with resistive touch, one aPCI slot, Ethernet, RS232 and USB.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 4PP220.0571-45
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 4PP220.0571-45

  • Manufacturer:
    B&R
  • Part Number:
    4PP220.0571-45
  • Product Family:
    B&R Control Panels
  • Product Type:
    Power Panel PP220 5.7-inch Controller HMI
  • Stock:
    1
  • Display:
    5.7-inch monochrome LCD
  • Resolution:
    320 x 240 pixels (QVGA)
  • Gray levels:
    8
  • Touchscreen:
    Analog resistive
  • Processor:
    Geode SC2200, 266 MHz
  • Memory:
    64 MB SDRAM; 256 kB battery-backed SRAM
  • Application storage:
    CompactFlash Type I
  • Interfaces:
    Ethernet 10/100; RS232; 2 x USB
  • Expansion:
    1 x aPCI slot
  • Power:
    24 VDC ±25%; typical 12 W, maximum 17 W
  • Protection:
    IP65 front; IP20 rear with CF card
  • Dimensions:
    21.2 x 15.6 x 7.6 cm
  • Weight:
    1.7 kg
  • Tariff Code:
    8537109090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Expansion Retention Power Application
  • Uses a 5.7-inch QVGA monochrome resistive touchscreen
  • Provides one aPCI expansion slot with Ethernet, RS232 and two USB interfaces
  • Stores the application on CompactFlash and retains SRAM with a serviceable battery

4PP220.0571-45 is a Power Panel PP220 5.7-inch controller HMI for legacy machine automation.

It combines a monochrome QVGA touchscreen, Geode controller, CompactFlash storage, one aPCI slot and Ethernet, RS232 and USB connectivity.

Before installation or replacement, confirm the exact model, CompactFlash image, aPCI option, battery-backed data, project and firmware, 24 VDC supply, connector and panel cutout.

Availability, condition, price, and shipping time for 4PP220.0571-45 are confirmed during quotation.

B&R 4PP220.0571-45 Power Panel PP220 5.7-inch Controller HMI Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • One aPCI slot supports the documented B&R communication option modules
  • The installed aPCI module and its terminal blocks must be identified before replacement
  • The Automation Studio hardware tree must match the fitted aPCI option
  • The 256 kB SRAM is battery-backed for retained controller data
  • The externally accessible lithium battery has a documented service interval
  • A backup capacitor provides temporary buffering during battery service
  • The nominal supply is 24 VDC with a ±25% tolerance
  • Typical consumption is 12 W and maximum consumption is 17 W
  • The required 3-pin power connector is ordered separately when not included
  • Compact machine control with local operator visualization
  • RS232-connected machine devices with local operator control
  • aPCI-expanded industrial control panels
Description

4PP220.0571-45 is a Power Panel PP220 5.7-inch controller HMI for legacy machine automation.

It combines a monochrome QVGA touchscreen, Geode controller, CompactFlash storage, one aPCI slot and Ethernet, RS232 and USB connectivity.

Before installation or replacement, confirm the exact model, CompactFlash image, aPCI option, battery-backed data, project and firmware, 24 VDC supply, connector and panel cutout.

Alternative Names
4PP220.0571-45 4PP220057145 4PP220 0571 45 B&R 4PP220.0571-45 B and R 4PP220.0571-45 Bernecker + Rainer 4PP220.0571-45 Power Panel 200 4PP220.0571-45
Technical notes
B&R 4PP220.0571-45 must be matched to the installed rear module or controller architecture, application image, interfaces and cabinet cutout before replacement; confirm separately supplied connectors, storage and cables.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What data can be lost when replacing the battery in B&R 4PP220.0571-45?
Battery-backed SRAM and real-time-clock data can be affected if the documented service procedure and backup-capacitor timing are not followed, so save the machine project first.
Can any aPCI module be installed in B&R 4PP220.0571-45?
No. Verify the exact supported aPCI option, connectors, firmware and Automation Studio configuration used by the machine.
Which storage must be transferred to B&R 4PP220.0571-45?
The application is held on a CompactFlash Type I card; make a verified image and confirm card compatibility before transfer.
Does B&R 4PP220.0571-45 include its 24 VDC connector?
The official description requires 0TB103.9 or 0TB103.91 to be ordered separately, so confirm whether the quoted stock includes it.
How should a dim display on B&R 4PP220.0571-45 be assessed?
Check the CCFL backlight condition, brightness, viewing angle, supply stability and front overlay before deciding whether the complete panel requires replacement.
What must match before loading a project into B&R 4PP220.0571-45?
Match the full material number, Automation Runtime and hardware support, aPCI module, CompactFlash image, node switches and retained-variable handling.
What acceptance checks are appropriate after installing B&R 4PP220.0571-45?
Verify boot, touch calibration, Ethernet and RS232 communication, USB ports, aPCI communication, retained values and controlled machine operation.
