330130-080-03-00

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330130-080-03-00 is an 8.0 m armored extension cable with connector protector for a 3300 XL 8 mm proximity transducer system.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330130-080-03-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330130-080-03-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330130-080-03-00
  • Product Type:
    3300 XL 8 mm Extension Cable
  • Stock:
    1
  • Cable Length:
    8.0 m (26.2 ft)
  • Cable and Protector Option:
    Armored cable with connector protector
  • Agency Approval:
    None selected (code 00)
  • Maximum Connector Torque:
    0.565 N·m (5 in·lbf)
  • Compatible System:
    3300 XL 8 mm proximity transducer system
  • Weight:
    0.84 kg
  • Estimated shipping dimensions:
    30x30x3cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Ordering Code System Matching Handling and Connection Product Applications

Features:

  • Defined length: Ordering code 080 specifies an 8.0 m extension cable.
  • Mechanical protection: Option 03 adds armor and a connector protector for the cable assembly.
  • System role: The cable links a compatible 3300 XL 8 mm probe lead to the selected Proximitor sensor.
330130-080-03-00 is an extension-cable configuration in the Bently Nevada 3300 XL 8 mm proximity transducer system.

Its suffix identifies the cable length, protective construction, and approval selection rather than a probe or Proximitor model.

Replacement review should preserve the total electrical system length and connector condition, not only the visible cable route.

Apter Power supports 330130-080-03-00 enquiries with ordering-code review, sourcing assistance, technical documents, and system-length checks.
Bently Nevada 330130-080-03-00 3300 XL 8 mm Extension Cable Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • 330130 family: Extension cable for the 3300 XL 8 mm proximity transducer system.
  • 080 option: 8.0 m (26.2 ft) cable length.
  • 03 option: Flexible stainless-steel armor with a connector protector.
  • 00 option: No agency approval selection.
  • Component set: Use the extension cable within a 3300 XL 8 mm probe, extension-cable, and Proximitor Sensor system.
  • System length: Match the probe lead plus extension cable to the total length configured for the Proximitor Sensor.
  • Performance boundary: Published XL performance applies to a system assembled from matching 3300 XL 8 mm components.
  • Configuration record: Retain the probe, cable, Proximitor, target material, and monitor-channel identities together.
  • ClickLoc connection: Assemble the gold-plated connector finger-tight until the locking action clicks.
  • Torque limit: Do not exceed 0.565 N·m (5 in·lbf) at the connector.
  • Bend control: Maintain at least the published 25.4 mm (1.0 in) cable bend radius.
  • Environmental protection: Keep the installed connector protector clean, dry, and correctly seated around the joint.
  • Vibration and position loops: Extends the probe connection in matching 3300 XL 8 mm machinery-monitoring systems.
  • Reference measurements: Supports Keyphasor and speed applications when the complete transducer system is engineered for that duty.
  • Installed-loop maintenance: Restores an 8.0 m armored cable path while retaining the original system-length selection.
  • Spare identification: The complete 330130-080-03-00 code distinguishes this assembly from other length, armor, and approval variants.
Description
330130-080-03-00 is a Bently Nevada 3300 XL 8 mm extension cable. The 080 length code specifies 8.0 m (26.2 ft), option 03 adds armored cable with a connector protector, and approval code 00 indicates that no agency approval is selected.

Within the transducer system, 330130-080-03-00 extends the electrical connection between the probe cable and the matching Proximitor sensor. It is not a probe or signal conditioner, so the installed probe, extension cable length, and Proximitor system-length option must be reviewed together.

Before fitting 330130-080-03-00, inspect both connectors, keep the dielectric surfaces clean and dry, and preserve the installed routing and bend control. The published maximum connector torque is 0.565 N·m (5 in·lbf); overtightening can damage the connection.
Alternative Names
3301300800300 330130 080 03 00 Bently Nevada 330130-080-03-00 330130-080-03-00 Extension Cable
Technical notes
The 080 code fixes the extension-cable length at 8.0 m, while option 03 specifies armor and a connector protector. For reliable system response, confirm the probe cable plus extension cable matches the connected Proximitor system length, and limit connector torque to 0.565 N·m during replacement planning.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What records should be compared before ordering 330130-080-03-00 for an installed loop?
Compare the probe, extension-cable, Proximitor Sensor, total system length, connector-protector, armor, and approval records.
Why can 330130-080-03-00 produce unexpected response after installation even when the connectors fit?
A physical connection does not prove the configured system length or component family matches the installed Proximitor Sensor.
When should the connector protector on 330130-080-03-00 be retained?
Retain it wherever the installed design requires protection from oil, contamination, moisture, or mechanical exposure.
How should an intermittent signal be investigated after fitting 330130-080-03-00?
Inspect connector seating, contamination, routing, bend radius, armor damage, and the complete probe-to-Proximitor path before changing calibration.
What confirms that 330130-080-03-00 matches the intended system length?
The probe lead plus the 8.0 m extension cable must agree with the total-length option of the connected Proximitor Sensor.
What should be documented after replacing 330130-080-03-00?
Record the full part number, connector condition, route, measured loop response, and associated probe and Proximitor identities.
