    Apter Power supplies brand new Bently Nevada 330910-00-08-50-01-05 proximity sensors to ensure accurate axial and radial vibration feedback for high-speed, compact rotating machinery.

330910-00-08-50-01-05

/ 4.9
1001 reviews | Need a Specific Revision?
The 330910-00-08-50-01-05 has a total housing length of 80 mm, providing sufficient housing depth to accommodate internal sensing electronics while ensuring adequate thread engagement for a robust mechanical mount.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 330910-00-08-50-01-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330910-00-08-50-01-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330910-00-08-50-01-05
  • Product Family:
    NSV Probe
  • Product Type:
    Proximity Probe
  • Stock:
    1
  • Unthreaded Length:
    0 mm
  • Overall Case Length:
    80 mm
  • Total Length:
    5.0 meters (16.4 feet)
  • Connector -Type:
    Miniature coaxial ClickLoc connector with connector protector
  • Cable-Type:
    standard cable
  • Available Probe Cable Lengths:
    0.5 m, 1 m, 5 m, 7 m
  • Operating Temperature:
    -52°C to +177°C (-62°F to +351°F)
  • Storage Temperature:
    -52°C to +177°C (-62°F to +351°F)
  • Weight:
    0.14 kg
  • Estimated shipping dimensions:
    109x2x1.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Certifications Compatibility

Features:

  • With a compact 0.8 meter (31.5 inches) length, this extension cable adds just enough reach to connect a probe to its Proximitor® sensor without creating excessive cable slack or requiring complex bundling.
  • The “01” connector is a traditional standard coaxial design without armor and without the ClickLoc™ locking mechanism, suitable for protected raceway installations where mechanical abrasion is not a concern.
  • The “01” connector is a traditional standard coaxial design without armor and without the ClickLoc™ locking mechanism, suitable for protected raceway installations where mechanical abrasion is not a concern.
The 330910-00-08-50-01-05 provides a compact 0.8 meter (31.5 inch) extension between a 3300 XL 8mm probe and its Proximitor® sensor. In many machinery monitoring installations, the probe’s integral cable (typically 0.5m to 1.0m) may be only slightly too short to reach the intended Proximitor® mounting location. Adding a full 4.5m or 8.0m extension cable would create excessive slack, requiring bundling, routing complications, and potential signal degradation from coiling. This short 0.8m cable solves that problem by providing just enough additional length to reach the Proximitor® while keeping the installation neat and serviceable.

The “01” connector on 330910-00-08-50-01-05 is a traditional standard coaxial design without armor protection and without the ClickLoc™ positive locking feature. This connector relies on a simple screw‑on coupling nut to maintain connection. The absence of armor makes this cable lighter, more flexible, and easier to route in tight spaces. It is suitable for installations where the cable will be routed through protected raceways, cable trays, or conduits with smooth interiors and no sharp edges that could damage the cable jacket. However, because the connector lacks a positive lock, it should be inspected periodically to ensure it has not loosened due to machine vibration.

The “05” suffix on 330910-00-08-50-01-05 indicates multiple hazardous area approvals, including ATEX (Europe), CSA (Canada), and IECEx (international). These certifications allow this short extension cable to be installed in classified areas where flammable gases or vapors may be present – Zone 1, Zone 2, Class I Division 1, or Class I Division 2 locations. For plant operators in the oil and gas, petrochemical, and refining industries, using approved components is mandatory for regulatory compliance. Non‑approved cables in hazardous areas risk ignition and violate safety codes.

The 330910-00-08-50-01-05 Bently Nevada Proximity Probe may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL)by the manufacturer (OEM).
Bently Nevada 330910-00-08-50-01-05 Proximity Probe Manuals, Datasheets,Drivers,Link Important Notice:Other accessories,manuals,cables,calibration data,software,etc.are not included with this equipment unless listed in the above stock item description.All prices are shown in USD.
Bently Nevada 330910-00-08-50-01-05 Proximity Probe Specs

General

  • Manufacturer GE /Bently Nevada
  • Model 330910-00-08-50-01-05
  • Condition New Original ready stock
  • Product Family 330910-00-08-50-02-05,330910-00-08-50-12-05,330910-00-08-50-01-00
Important Notice:Other accessories,manuals,cables,calibration data,software,etc.are not included with this equipment unless listed in the above stock item description.All prices are shown in USD.
  • Narrow Space Monitoring: Due to its small probe outer diameter (M8 thread), it is widely used in small high-speed centrifugal compressors, pumps, aircraft engine auxiliary power units (APUs), and gearboxes.
  • Non-Magnetic Material Monitoring: The NSv series offers superior linear response and standard scaling factor compared to the standard 3300 XL series for non-ferromagnetic materials such as stainless steel (e.g., the 300 series) and aluminum.
  • Key Displacement and Vibration Measurement: Used to measure radial vibration, axial displacement, or rotational speed (keyphasor), it is a key sensor for acquiring front-end data in the 3500 monitoring system.
  • Intrinsically Safe: When installed with a compatible preamplifier and safety gate, it complies with ATEX, IECEx, CSA, and other standards, allowing operation in Zones 0, 1, and 2 (explosive hazardous areas).
  • Electromagnetic Compatibility (EMC): Complies with European CE directives, providing strong resistance to electromagnetic interference and ensuring a clean signal.
  • Environmental Protection: The housing and cable connections feature a fluid-sealed design, meeting IP68 or relevant industrial-grade dust and water protection standards, resisting lubricants, moisture, and various chemical solvents.
  • Preamplifier Requirements: Must be used with the 3300 NSv Proximitor. It is incompatible with the standard 3300 XL preamplifier; forcing a connection will result in significant signal distortion.
  • System Length Matching: -50 in the model number indicates a total length of 5.0 meters. During configuration, the preamplifier option must also be set to a 5.0-meter system; otherwise, calibration accuracy will be compromised.
  • Interoperability: Its output analog voltage signal (typically 7.87 V/mm) is fully interoperable with the Bently Nevada 3500 series and Orbit 60 monitoring systems.
Description
The 330910-00-08-50-01-05 is a 3300 NSv Proximity Probe designed with an M10×1 threaded probe body and armored construction, providing enhanced mechanical protection for demanding industrial environments.

The 330910-00-08-50-01-05 has an unthreaded length of 0 mm and an overall case length of 80 mm, offering a compact and robust sensing solution. The total cable length is 5.0 meters (16.4 feet), allowing extended installation distance between the probe and the monitoring system.

It is equipped with a miniature coaxial ClickLoc connector with a connector protector and a standard cable type, ensuring secure connection and reliable signal transmission even in harsh operating conditions.

The 330910-00-08-50-01-05 carries multiple agency approvals, indicating compliance with applicable industry standards and suitability for use in a wide range of certified installations.
Alternative Names
330910 00 08 50 01 05 330910-00-08-50-01-00 330910-00-08-50-01-CN 330910-00-08-50-11-05 330910-00-08-70-01-05 330910-05-10-02-00 330910-03-09-05-02-05 330910-00-05-50-02-00
Technical notes
The 330910-00-08-50-01-05 is a 3300 XL 8mm Extension Cable designed to connect a 3300 XL 8mm probe to a Proximitor® sensor.The total system length (probe cable + extension cable) must not exceed 9.0 meters for 3300 XL systems. The “01” connector is a standard coaxial design without armor – suitable for installations where the cable is not subject to mechanical abrasion or pulling through sharp‑edged conduit.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the 330910-00-08-50-01-05 tip material?
The probe tip is made of Polyphenylene Sulfide (PPS), a durable material suitable for industrial environments.
What are the primary electrical output characteristics of the Bently Nevada 330910-00-08-50-01-05?
The Bently Nevada 330910-00-08-50-01-05 provides an Average Scale Factor of 7.87 V/mm (200 mV/mil), which is the industry standard for eddy current transducers. Its linear range is 1.5 mm (60 mils), specifically extending from approximately 0.25 mm to 1.75 mm (10 to 70 mils).
How should the Bently Nevada 330910-00-08-50-01-05 be integrated into field wiring?
The Bently Nevada 330910-00-08-50-01-05 should be connected using a three-conductor shielded triad cable, with a maximum length of 305 meters (1,000 feet) between the associated Proximitor Sensor and the monitor. Users should be aware of signal rolloff at high frequencies when using longer field wiring lengths.
What diagnostic precautions are needed when handling the Bently Nevada 330910-00-08-50-01-05?
While the terminals and connector on the associated Proximitor Sensor are protected against electrostatic discharge (ESD), users must take reasonable precautions to avoid ESD during the handling of the Bently Nevada 330910-00-08-50-01-05.
Are there specific cross-talk considerations for the Bently Nevada 330910-00-08-50-01-05?
Yes. To prevent electromagnetic field interaction (cross-talk) when mounting multiple Bently Nevada 330910-00-08-50-01-05 units, maintain a minimum separation of 25 mm (1.0 in) for axial position measurements or 23 mm (0.9 in) for radial vibration measurements.
