Bently Nevada 135489-03 is a 4-channel Velomitor I/O module with internal barriers and terminations, compatible with 3500/42M and 3500/70M monitor modules for reliable vibration and velocity monitoring in hazardous areas.
Get a quick price for 135489-03
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 135489-03

  • Manufacturer:
    Bently Nevada
  • Part Number:
    135489-03
  • Product Family:
    3500 System
  • Product Type:
    I/O Module with Internal Barrier
  • Number of channels:
    4
  • Bandwidth:
    Up to 30 kHz
  • Amplitude accuracy:
    Typical ±1%
  • Sensor type:
    Specifically designed for Velomitor (piezoelectric velocity sensor).
  • Operating Temperature:
    -30°C to +65°C (-22°F to +149°F).
  • Storage Temperature:
    -40°C to +85°C (-40°F to +185°F).
  • Humidity:
    95%, noncondensing.
  • Weight:
    0.96 kg
  • Estimated shipping dimensions:
    2.5x18.5x14cm
  • Tariff Code:
    8537109090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Programming Updates Application Scenarios

Features:

  • Four Dedicated Velomitor Channels Provide Reliable And Accurate Velocity Monitoring
  • Internal Barriers And Terminations Enhance Safety And Simplify Installation
  • Fully Compatible With Multiple 3500 Series Monitor Modules
The Bently Nevada 135489-03 I/O Module is engineered for seamless integration with 3500 series monitoring systems. It is optimized to collect precise velocity data from Velomitor sensors, ensuring dependable operation in industrial environments.

This module stands out with its internal barriers and terminations, which reduce wiring complexity and provide enhanced protection in hazardous areas. Unlike other I/O modules, it allows consistent performance across different 3500 series monitors, including both 3500/42M and 3500/70M.

Operators benefit from the module’s flexibility and interchangeability. By supporting multiple monitor configurations, the 135489-03 simplifies system upgrades, reduces inventory needs, and delivers reliable vibration and velocity monitoring without compromising accuracy or safety.

The 135489-03 Bently Nevada I/O Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 135489-03 I/O Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 135489-03 I/O Module Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 135489-03
  • Condition New Original ready stock
  • Product Family 135473-01,143489-01,176449-02
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Sensor Selection: In the software's "Sensor" tab, the Velomitor type must be selected. Since the 135489-03 integrates safety barriers, the software will automatically match the corresponding electrical compensation parameters.
  • Channel Pairing: This module supports 4 independent channels. During configuration, you can define them as radial vibration, axial displacement (application-specific), or reciprocating machine impact monitoring.
  • Alarm Settings: Alert and Danger thresholds, as well as delay times, are set via software. These logics are then sent to the corresponding upstream monitoring modules.
  • Hardware Switch: Check the write protection switch on the back of the 3500 frame. It must be set to the "On" state for successful configuration.
  • Passive Attribute: The 135489-03 is a physical interface board and does not contain independently updatable firmware.
  • Related Updates: The so-called "firmware update" actually refers to updating the firmware of its paired 3500/42M or 3500/70M master module.
  • Operation Method: Connect the 3500/22M (TDI) module to the PC. Use the Firmware Upgrade Utility in the configuration software. Select the corresponding Slot to update.
  • Note: Updating the firmware will temporarily disable the monitoring channel to which the module belongs. It is recommended to perform this update while the equipment is powered off.
  • Hazardous Areas: Due to its integrated internal safety barrier, it allows direct connection of Velomitor sensors located in Zone 0, Zone 1, or Zone 2 (Class I, Div 1/2) without the need for an external safety barrier cabinet.
  • Large Rotating Machinery: Commonly used for monitoring the casing vibration of steam turbines, centrifugal compressors, pumps, and fans (using Velomitor to measure velocity values ​​and convert them to displacement).
  • Reciprocating compressors: When used with the 3500/70M module, it monitors crosshead impact or compressor vibration to identify loose connecting rods or valve malfunctions.
  • Space-constrained installation: For control cabinets without space to install external isolation barriers, this integrated I/O module is the preferred solution.
Description
The Bently Nevada 135489-03 I/O module is a specialized component designed for the 3500 series system, offering four dedicated Velomitor velocity sensor channels with typical amplitude accuracy of ±1% and a bandwidth up to 30 kHz. Unlike other modules such as 135489-01 or 135489-02, which may offer mixed or fewer channels, 135489-03 provides full 4-channel capability, ensuring comprehensive monitoring for both 3500/42M and 3500/70M applications.

Equipped with internal barriers and terminations, 135489-03 enhances safety and simplifies wiring in hazardous areas. Its operating temperature range of -30°C to +65°C and storage range of -40°C to +85°C, along with 95% non-condensing humidity tolerance, ensures reliable operation even in extreme industrial environments. In comparison, modules like 135489-01 and 135489-02 may have more limited environmental specifications, making 135489-03 more robust for demanding installations.

The module is fully compatible with 3500/42M Proximitor/Seismic Monitors and 3500/70M Recip Impulse/Velocity Monitors, providing flexibility for system upgrades or expansions. While the core hardware of 135489-03 is identical across both monitor types, the specific measurement function—whether radial vibration for 3500/42M or reciprocating compressor impulse/velocity for 3500/70M—is determined by the main monitor module and system configuration software, giving operators precise control over monitoring objectives.

Compared to other I/O modules in the 3500 series, 135489-03 stands out for its pure Velomitor support, full 4-channel design, and built-in safety features. This makes it ideal for installations where consistent signal fidelity, simplified integration, and hazardous-area compliance are critical. Its interchangeability between 3500/42M and 3500/70M modules ensures long-term flexibility and reduces inventory complexity for operators managing multiple 3500 series systems.

In summary, Bently Nevada 135489-03 is the go-to I/O module for advanced 3500 system installations that require high-accuracy Velomitor inputs, safe internal wiring, and compatibility across multiple monitor types, outperforming similar modules like 135489-01 and 135489-02 in channel capacity, environmental tolerance, and flexibility.
Alternative Names
135489-01 135489-02 135489-04 138708-01
Technical notes
Bently Nevada 135489-03 I/O Module with Internal Barrier provides 4 channels with bandwidth up to 30 kHz and amplitude accuracy of typical ±1%, while supporting sensor type specifically designed for Velomitor (piezoelectric velocity sensor). The 135489-03 operates within an operating temperature range of -30°C to +65°C (-22°F to +149°F) and storage temperature from -40°C to +85°C (-40°F to +185°F), with humidity tolerance of 95% non-condensing. Bently Nevada 135489-03 is structured as a 4-channel I/O module with defined electrical and environmental parameters for stable signal handling.
