Features:
- Interfaces the Universal AC power source with the 3500 rack power system
- Converts a wide range of AC input voltages for use by other 3500 modules
- Supports single-supply or redundant two-supply rack configurations
The Bently Nevada 3500/15 106M1079-01 operates as the Universal AC Power Supply Module in a 3500 rack. With the compatible Universal AC Power Input Module, it accepts 85 to 264 Vac rms in non-hazardous areas at 47 to 63 Hz and converts the input to voltages required by other 3500 modules.
The 3500/15 is a half-height module installed in a designated power-supply slot on the left side of the rack. A rack can contain one or two power supplies, and either supply can power a full rack. The installed configuration determines whether the system uses a single supply or redundant power.
With two power supplies installed, the lower module acts as the primary supply and the upper module serves as the backup. Removing or inserting either supply does not disrupt rack operation while the second supply remains installed and operating.
Installation Note: The Universal AC Power Supply and Universal AC Power Input Module are not compatible with legacy High Voltage AC or Low Voltage AC units. Confirm the installed PIM and input source before replacement.
Bently Nevada 3500/15 106M1079-01 Manuals and Resources
Documentation Note: Verify the complete part number, matching Universal AC Power Input Module, input source, rack arrangement, and redundancy configuration before installation or replacement.
Bently Nevada 3500/15 106M1079-01 Universal AC Power Supply Specifications
General
- Manufacturer Bently Nevada
- Model 3500/15 106M1079-01
- Condition New
- Product Family 3500/15 power supply modules
- 106M1079-01 is listed as the Universal AC Power Supply Module spare
- Use 106M1081-01 as the matching Universal AC Power Input Module where applicable
- Power-supply module and rear PIM are separate components
- Verify current spare and rack revision before replacement
- Install only in a designated 3500/15 power-supply slot
- Match to the compatible Universal AC PIM and facility input voltage
- A second compatible supply can provide rack redundancy
- Confirm load, rack revision and power-source separation for redundant designs
- De-energize and verify the rear power input before wiring work
- Confirm the front supply module and rear PIM are the correct pair
- Inspect connector covers, grounding and fuse requirements
- Verify the Supply OK indication and rack diagnostics after installation
