Bently Nevada 330881-28-00-265-00-02 is a metric PROXPAC XL assembly with an approved 3300 XL 8 mm probe, no standoff, 265 mm penetration, no fittings, and a 3/4-14 NPT mount.
In Stock
Ships by Sunday, November 1
Fast Shipping Available
Get a quick price for 330881-28-00-265-00-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330881-28-00-265-00-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330881-28-00-265-00-02
  • Product Family:
    PROXPAC XL Proximity Transducer Assembly
  • Product Type:
    metric PROXPAC XL proximity transducer assembly
  • Stock:
    1
  • Probe:
    3300 XL 8 mm with multiple approvals
  • Standoff adapter:
    None
  • Probe penetration:
    265 mm
  • Fittings:
    None; two plugs and two washers
  • Mounting thread:
    3/4-14 NPT
  • Power without barriers:
    -17.5 to -26 Vdc at 12 mA maximum
  • Linear range:
    2 mm
  • Recommended gap:
    1.27 mm
  • Scale factor:
    7.87 V/mm ±5%
  • Frequency response:
    0 to 10 kHz
  • Field wiring:
    0.2 to 1.5 mm²
  • Maximum field wiring length:
    305 m
  • Housing rating:
    IP66 / Type 4X
  • Probe operating temperature:
    -52°C to +177°C
  • Housing and Proximitor operating temperature:
    -52°C to +100°C
  • Weight:
    3.175 lbs (1.44 kg)
  • Tariff Code:
    9031809090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Electronics Sleeve Geometry Output Signal Conduit

Features:

  • Integrated 8 mm probe and Proximitor sensor
  • 265 mm direct-mounted penetration sleeve
  • IP66/Type 4X protected housing
Bently Nevada 330881-28-00-265-00-02 places the proximity probe and conditioning electronics in one self-contained metric PROXPAC XL assembly.

Without a standoff, the 265 mm sleeve of 330881-28-00-265-00-02 sets the main reach from the mounting interface to the monitored target.

Field wiring enters 330881-28-00-265-00-02 directly, so the installer must complete conduit hardware and sealing for the selected wiring method.

The Bently Nevada 330881-28-00-265-00-02 metric PROXPAC XL proximity transducer assembly may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330881-28-00-265-00-02 metric PROXPAC XL proximity transducer assembly Manuals,Datasheets,LinkImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Internal Probe and Signal Conditioning

  • Internal sensor: The Proximitor sensor is installed inside the protected housing.
  • Direct wiring: Shielded field conductors connect the internal sensor to the monitor.
  • Extension cable: No separate probe-to-Proximitor extension cable is used.
  • Signal path: Probe gap is converted into the conditioned voltage delivered to the monitor input.

Penetration and Mounting Interface

  • Standoff: No standoff adapter is included.
  • Penetration: The sleeve provides 265 mm of coded probe penetration.
  • Mounting thread: The assembly anchors through a 3/4-14 NPT outer-sleeve interface.
  • Adjustment: The threaded sleeve retains final probe-position adjustment after mounting.

Gap and Dynamic Response

  • Linear range: The calibrated measurement span is 2 mm.
  • Nominal gap: The recommended center setting is 1.27 mm.
  • Scale factor: The configured system uses a 7.87 V/mm scale factor within the stated tolerance.
  • Frequency response: The specified response extends from 0 to 10 kHz.

Field Entry and Sealing

  • Supplied items: The no-fitting option includes two plugs and two washers.
  • Fitting choice: Conduit hardware must be selected for the installed wiring method.
  • Wire size: Field terminals accept conductors from 0.2 to 1.5 mm².
  • Sealing: Entry hardware must preserve the IP66/Type 4X enclosure rating.
Description
Bently Nevada 330881-28-00-265-00-02 is a metric PROXPAC XL assembly that places an approved 3300 XL 8 mm probe and its Proximitor sensor inside one IP66 housing. The self-contained structure sends the conditioned proximity signal to the monitor without a separate probe-to-Proximitor extension cable.

With no standoff adapter, 330881-28-00-265-00-02 uses a 265 mm penetration sleeve to establish the distance from its mounting interface to the target. The 3/4-14 NPT outer-sleeve thread anchors the assembly, while the threaded sleeve retains final probe-position adjustment.

The fittings option on 330881-28-00-265-00-02 supplies no conduit fittings and instead includes two plugs and two washers. Field wiring enters the housing and connects to the internal Proximitor sensor, so conduit selection and sealing must be completed for the installed wiring method.
Alternative Names
33088128002650002 330881 28 00 265 00 02 330881-28 00-265 00-02 Bently Nevada 330881-28-00-265-00-02 330881-28-00-265-00-02 PROXPAC XL 33O881-28-OO-265-OO-O2 33088I-28-00-265-00-02 330881 28-00 265-00 02
Technical notes
Bently Nevada 330881-28-00-265-00-02 is a metric self-contained PROXPAC XL assembly. Its 265 mm sleeve uses direct 3/4-14 NPT mounting without a standoff.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why is 330881-28-00-265-00-02 described as metric even though it uses a 3/4-14 NPT thread?
The 330881 base and 265 option use metric penetration coding, while suffix 02 explicitly selects a 3/4-14 NPT mounting thread for 330881-28-00-265-00-02.
What must be added when flexible conduit is connected to 330881-28-00-265-00-02?
Because 330881-28-00-265-00-02 option 00 supplies no fittings, the installer must select the correct conduit hardware and seal the housing entry; only plugs and washers are included.
How does the absence of a standoff change installation of 330881-28-00-265-00-02?
The 330881-28-00-265-00-02 sleeve mounts directly through its 3/4-14 NPT interface, so the 265 mm penetration code—not a separate standoff—sets the main reach.
Which wire run limit should be considered for 330881-28-00-265-00-02?
The internal Proximitor sensor in 330881-28-00-265-00-02 allows up to 305 m of shielded field wiring, with high-frequency roll-off considered for longer runs.
What should be verified if 330881-28-00-265-00-02 output does not track the shaft gap?
Check the 1.27 mm nominal gap, target material and size, shielded wiring, supply voltage, and monitor input assigned to 330881-28-00-265-00-02 before disturbing the sleeve position.
