    Apter Power supports configuration review, documentation, and sourcing for KJ4110X1-EA1 12P1878X032.

KJ4110X1-EA1 12P1878X032

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson KJ4110X1-EA1 12P1878X032 is a DeltaV M-series intrinsically safe system power supply that converts nominal 24 VDC input to 12 VDC for DeltaV I.S. I/O cards. It supplies up to 5 A and supports n+1 power-supply redundancy.
In Stock
Ships by Wednesday, October 28
Get a quick price for KJ4110X1-EA1 12P1878X032
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for KJ4110X1-EA1 12P1878X032

  • Manufacturer:
    Emerson
  • Part Number:
    KJ4110X1-EA1 12P1878X032
  • Product Family:
    DeltaV
  • Product Type:
    DeltaV M-series Intrinsically Safe System Power Supply
  • Stock:
    1
  • Order Number:
    12P1878X032
  • Input Voltage:
    18.5 to 36 VDC (24 VDC nominal)
  • Output Voltage:
    12 VDC ±5%
  • Output Current:
    5 A
  • Input Protection:
    Internally fused, non-replaceable
  • Input/Output Isolation:
    250 VAC rms (tested at 1,500 VAC rms)
  • Input Connection:
    2-part screw terminal, each duplicated
  • Cable Size:
    2.5 mm²
  • Overvoltage Protection:
    Output protected at 110% to 120%
  • Operating Temperature:
    0 to 55°C optimum orientation; 0 to 50°C worst-case orientation at full load
  • Storage Temperature:
    -40 to +85°C
  • Relative Humidity:
    5 to 95%, non-condensing
  • Airborne Contaminants:
    ISA-S71.04-1985 Class G3
  • Shock:
    10 g, 11 ms pulse width
  • Vibration:
    2 g at 10 to 100 Hz
  • Mounting:
    Either slot of 2-wide Power/Controller Carrier
  • LED Indicator:
    Green DC Power status
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Use Cases Environmental Ratings Diagnostics & Protection

Features:

  • Converts 18.5 to 36 VDC input to 12 VDC ±5% output.
  • Supplies up to 5 A for DeltaV M-series I.S. I/O cards.
  • Supports n+1 power-supply redundancy.
The current ordering configuration is KJ4110X1-EA1 12P1878X032, the DeltaV M-series intrinsically safe system power supply.

It converts nominal 24 VDC input to 12 VDC for DeltaV I.S. I/O cards. The number of cards powered by one supply depends on the installed I.S. card types, and an additional supply can provide n+1 redundancy.

Install the unit in either slot of a 2-wide Power/Controller Carrier. Confirm the full-load mounting orientation, duplicated screw-terminal connections, cable size, and environmental limits before commissioning.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Emerson KJ4110X1-EA1 12P1878X032: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Emerson KJ4110X1-EA1 12P1878X032 General Specifications

General

  • ManufacturerEmerson
  • ModelKJ4110X1-EA1 12P1878X032
  • ConditionNew Original ready stock
  • Product FamilyDeltaV M-series Intrinsically Safe I/O
  • Provides 12 VDC power for DeltaV M-series intrinsically safe analog and discrete I/O cards.
  • Supports I.S. I/O capacity planning according to the installed card types and their power demand.
  • Enables optional n+1 redundancy by adding one additional I.S. system power supply.
  • Operates at full load from 0 to 55°C in the optimum orientation or 0 to 50°C in the worst-case orientation.
  • Supports -40 to +85°C storage and 5 to 95% relative humidity without condensation.
  • Meets ISA-S71.04-1985 Class G3 airborne-contaminant conditions with specified shock and vibration resistance.
  • Uses internally fused, non-replaceable input protection.
  • Protects the output against overvoltage at 110% to 120% of the specified level.
  • Provides a green DC Power indicator for applied input power and internal fuse or diode status.
Description
KJ4110X1-EA1 12P1878X032 is an Emerson DeltaV M-series intrinsically safe system power supply. It accepts 18.5 to 36 VDC input and provides 12 VDC ±5% output at up to 5 A.

The power supply provides 12 VDC power for DeltaV M-series I.S. I/O cards. The supported card quantity depends on the installed I.S. card types, and n+1 power-supply redundancy is supported.

Install the unit in either slot of a 2-wide Power/Controller Carrier. Confirm the full-load mounting orientation, duplicated screw-terminal connections, cable size, and environmental limits before commissioning.
Alternative Names
KJ4110X1-EA1 12P1878X032 KJ4110X1-EA1 12P1878X032 DeltaV I.S. System Power Supply M-series I.S. I/O Power Supply Emerson DeltaV I.S. Power Supply
Technical notes
KJ4110X1-EA1 12P1878X032 accepts 18.5 to 36 VDC input and supplies 12 VDC ±5% at up to 5 A for DeltaV M-series intrinsically safe I/O.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What input voltage does KJ4110X1-EA1 12P1878X032 accept?
The specified input range is 18.5 to 36 VDC, with 24 VDC nominal.
What output does this DeltaV I.S. power supply provide?
It provides 12 VDC ±5% output at up to 5 A for DeltaV M-series intrinsically safe I/O cards.
How is the input of KJ4110X1-EA1 12P1878X032 protected?
The input uses internal non-replaceable fuses, and the output includes overvoltage protection at 110% to 120%.
Where is the I.S. system power supply installed?
It mounts in either slot of a 2-wide Power/Controller Carrier.
Can this power supply be used in a redundant arrangement?
Yes. Emerson specifies optional n+1 redundancy by adding one additional I.S. power supply.
Which environmental limits should be checked before installation?
Verify the full-load orientation limits, 5 to 95% non-condensing humidity, Class G3 airborne contaminants, shock, and vibration requirements.
