A6500-CC

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson A6500-CC is a one-slot AMS 6500 ATG communication card providing Modbus TCP/IP, Modbus RTU and OPC UA access to protection-module data.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for A6500-CC
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for A6500-CC

  • Manufacturer:
    Emerson
  • Part Number:
    A6500-CC
  • Product Family:
    Epro
  • Product Type:
    AMS A6500 System Communication Card
  • Stock:
    1
  • Rack Format:
    3U, 1 slot
  • Ethernet:
    RJ45, 10/100 Mbit/s
  • Ethernet Protocol:
    Modbus TCP/IP
  • Serial Protocol:
    Modbus RTU
  • OPC Interface:
    OPC UA
  • Serial Physical Layer:
    RS-485
  • Serial Bus Lines:
    6
  • Maximum Serial Rate:
    512 kbit/s
  • USB:
    Type B, 12 Mbit/s
  • Time Synchronization:
    SNTP
  • Address Space:
    2000 Modbus registers
  • Configuration Storage:
    SD card
  • Maintenance:
    Hot-swappable
  • Protection Standard:
    API 670 system architecture
  • Diagnostics:
    Hardware, power and temperature self-check
  • Tariff Code:
    8537101190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Communication Configuration Diagnostics

Features:

  • Reads parameters from installed AMS A6500 ATG protection modules.
  • Provides Modbus TCP/IP, Modbus RTU and OPC UA interfaces.
  • Supports hot replacement with configuration storage on an SD card.
The current ordering configuration is A6500-CC, the AMS A6500 System Communication Card documented for AMS 6500 ATG.

In the intended system role, the card supports Ethernet Modbus TCP/IP, serial Modbus RTU and OPC UA. It also provides time synchronization, local USB service and configuration storage on an SD card.

For selection and commissioning, confirm rack addressing, serial line settings, Ethernet topology, protocol mapping and cybersecurity controls before replacement. Save the active configuration before removing a running card.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Emerson A6500-CC:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Transfers machinery-protection values to a plant historian or supervisory host, for its documented operating duty.
  • Publishes rack measurements through OPC UA for condition-monitoring integration, through the intended receiving-system interface.
  • Connects serial monitoring clients to the ATG rack through configured Modbus RTU lines, in the configured and commissioned installation.
  • Two plant protocols are available through Ethernet and serial interfaces, within the configured host communication path.
  • The OPC UA server exposes configured monitoring information to compatible clients, using the documented wiring and interface conditions.
  • SNTP keeps communication timestamps aligned with the plant time source, before live data exchange is enabled.
  • Protocol maps, addresses and network parameters are stored on the removable SD card, within the controlled engineering configuration.
  • Password protection restricts changes to communication settings, preventing uncontrolled changes to the approved setup.
  • USB service access supports local setup of the communication interface, so replacement work retains the approved settings.
  • Built-in checks supervise hardware, supply condition and card temperature, during commissioning and fault isolation.
  • Network status helps distinguish link loss from missing module data, during normal monitoring and fault analysis.
  • A configuration backup supports controlled recovery after card replacement, as part of a controlled service-recovery process.
Description
A6500-CC is the AMS 6500 ATG system communication card for collecting protection-module parameters and presenting them to plant networks. It occupies one slot in a 3U rack.

The card supports Ethernet Modbus TCP/IP, serial Modbus RTU and OPC UA. It also provides time synchronization, local USB service and configuration storage on an SD card.

Confirm rack addressing, serial line settings, Ethernet topology, protocol mapping and cybersecurity controls before replacement. Save the active configuration before removing a running card.
Alternative Names
A6500-CC Emerson A6500-CC A6500 CC A6500CC Emerson AMS A6500 System Communication Card Emerson AMS 6500 ATG A6500-CC A6500-CC AMS A6500 System Communication Card Emerson A6500-CC module
Technical notes
Back up protocol maps and network settings before exchange; an unconfigured communication card can interrupt monitoring data even while protection modules remain active.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which plant protocols are native to A6500-CC?
The official card supports Modbus TCP/IP, Modbus RTU and OPC UA, with SNTP for time synchronization.
How many serial bus lines can A6500-CC manage?
The specification provides six RS-485 bus lines for configured Modbus RTU communication.
Where does A6500-CC fit in an AMS 6500 ATG rack?
It is a 3U, one-slot system communication card used to aggregate and publish protection-module data.
What configuration evidence should be supplied with an A6500-CC quote request?
Include the rack type, Ethernet addressing, serial settings, protocol map and required spare condition.
Can an unconfigured A6500-CC restore an existing network automatically?
Do not assume so; preserve and validate the SD-card configuration and network identity before cutover.
Which document defines the interfaces of A6500-CC?
Use Emerson's A6500-CC System Communication Card product data sheet and the applicable ATG rack manual.
