EZ1900-003-ADAP-1

/ 4.9
1001 reviews | Need a Specific Revision?
Emerson EZ1900-003-ADAP-1 is a 0.35 m adapter for connecting specified PR642x probes to an AMS EZ 1000 converter.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for EZ1900-003-ADAP-1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for EZ1900-003-ADAP-1

  • Manufacturer:
    Emerson
  • Part Number:
    EZ1900-003-ADAP-1
  • Product Family:
    Epro
  • Product Type:
    0.35 m PR642x-to-AMS EZ 1000 Sensor Adapter
  • Stock:
    1
  • Compatible converter:
    AMS EZ 1000 converter
  • Compatible sensor groups:
    PR6424/0xx-xx0; PR6425/010-1x0; PR6426/0x0-xx0
  • Adapter construction:
    No armor; approximately 0.35 m cable
  • Official total adapter length:
    Approximately 365 mm
  • Converter-side connection:
    AMS EZ 1000 sensor socket
  • Probe-side connection:
    Connector for the documented PR642x groups
  • Shrink temperature:
    Approximately 200°C
  • Electrical capacitance:
    +39 pF
  • Calibration handling:
    Automatically considered when PR6424, PR6425 or PR6426 is selected
  • Tariff Code:
    9031900090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Compatibility Installation Commissioning Application
  • Use only with the exact PR642x groups documented by Emerson
  • Allow cabinet depth for the adapter and both connector bodies
  • Field-calibrate the complete probe, adapter and converter chain

Emerson EZ1900-003-ADAP-1 is the required adapter for connecting specified PR6424, PR6425 and PR6426 sensors to an AMS EZ 1000 converter.

The unarmored adapter is approximately 0.35 m long, with the official installation manual showing an overall adapter length of about 365 mm.

Before ordering or fitting it, confirm the complete PR642x suffix, connector condition, converter socket, available cabinet depth, cable strain relief and the planned field calibration.

Availability, condition, price, and shipping time for EZ1900-003-ADAP-1 are confirmed during quotation.

Emerson EZ1900-003-ADAP-1 Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Confirm the complete PR6424, PR6425 or PR6426 suffix
  • Do not substitute the BN 33010x adapter
  • Verify the AMS EZ 1000 converter socket and configuration
  • Provide connector clearance and strain relief
  • Keep the unarmored cable away from sharp edges and switching conductors
  • Lock both connectors without twisting the cable
  • Configure the exact probe family in the converter
  • Perform field calibration against the actual target
  • Verify bias, scale, direction and monitor alarms
  • Radial and axial shaft dynamic-displacement measurement with a compatible PR642x probe and AMS EZ 1000
  • Shaft position and eccentricity measurement on compatible turbomachinery probe chains
  • Speed and key measurement using a supported PR642x probe with an AMS EZ 1000 converter
Description
EZ1900-003-ADAP-1 is the dedicated adapter for PR6424/0xx-xx0, PR6425/010-1x0 and PR6426/0x0-xx0 probes; Bently Nevada 33010x probes require ADAP-2.

Allow approximately 365 mm adapter length plus connector clearance without stressing the cable.

Configure the exact probe family and field-calibrate the complete chain before returning it to service.
Alternative Names
EZ1900-003-ADAP-1 EZ1900 003 ADAP 1 EZ 1900-003-ADAP-1 Emerson EZ1900-003-ADAP-1 Emerson EZ 1900-003-ADAP-1 AMS EZ 1000 EZ1900-003-ADAP-1 Emerson AMS EZ 1000 EZ1900-003-ADAP-1 EPRO EZ1900-003-ADAP-1 Emerson EPRO EZ1900-003-ADAP-1
Technical notes
EZ1900-003-ADAP-1 is not a general extension cable and is not the adapter for Bently Nevada 33010x probes. Use only with the exact PR642x groups documented by Emerson.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which probes can Emerson EZ1900-003-ADAP-1 connect?
Emerson documents PR6424/0xx-xx0, PR6425/010-1x0 and PR6426/0x0-xx0 sensor groups. The complete suffix must match before ordering.
Can Emerson EZ1900-003-ADAP-1 be used for Bently Nevada 33010x probes?
No. Emerson specifies the separate EZ1900-003-ADAP-2 for 33010x probes; connector appearance is not proof of electrical compatibility.
Is Emerson EZ1900-003-ADAP-1 an extension cable?
No. It adapts the documented PR642x connector to the AMS EZ 1000 converter and should not be used merely to add arbitrary cable length.
What cabinet clearance is needed for Emerson EZ1900-003-ADAP-1?
Allow for the approximately 365 mm adapter, connector bodies, safe bend radius and strain relief without forcing the converter socket or probe connector.
Can the adapter cable be shortened in the field?
No field modification should be assumed. Cutting, splicing or changing connectors can alter integrity and invalidates the documented adapter arrangement.
Why might the converter not recognize a probe after installing the adapter?
Check the complete probe suffix, connector locking, contamination, bent contacts, converter configuration, cable damage and whether the measuring chain has been calibrated.
What should be verified before returning the adapted chain to service?
Inspect both connections and strain relief, configure the exact probe family, perform field calibration against the installed target, and verify bias, scale, direction and alarms.
