The PR6423/010-100-CN CON021 is a precision eddy current signal converter with 0-20,000 Hz bandwidth, <15 μs rise time, -30 to 100°C operating range, and ATEX/IECEx/CSA hazardous area approvals for critical turbomachinery monitoring.
Get a quick price for PR6423/010-100-CN CON021
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PR6423/010-100-CN CON021

  • Manufacturer:
    Emerson
  • Part Number:
    PR6423/010-100-CN CON021
  • Product Family:
    Epro
  • Product Type:
    Eddy Current Signal Converter
  • Frequency Range (-3 dB):
    0 to 20000 Hz
  • Rise Time:
    <15 μs
  • Operating Temperature:
    -30 to 100°C
  • Shock and Vibration:
    5g @ 60 Hz @ 25°C
  • Protection Class:
    IP20
  • Supply Voltage:
    -23V to -32V (output -4V to -20V); -21V to -32V (output -2V to -18V)
  • Mounting:
    4 × M5 screws (included)
  • Key Benefit:
    Captures both static shaft position and high-frequency vibration with 20 kHz bandwidth and <15 μs rise time, enabling early fault detection in turbomachinery while meeting global hazardous area requirements.
  • Weight:
    0.4 kg
  • Estimated shipping dimensions:
    20x20x4cm
  • Tariff Code:
    8483409090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Performance and Efficiency Application Scenarios

Features:

  • Wide frequency response from DC to 20,000 Hz with <15 μs rise time captures both static shaft position and high-frequency vibration transients on turbines, compressors, and fans.
  • Multiple hazardous area approvals including ATEX Ex ia IIC T4, IECEx, and CSA Class I Division 1/2 enable deployment in explosive environments across North America, Europe, and international markets.
  • Robust environmental design with -30 to 100°C operating range, 5g vibration resistance, and IP20 protection ensures reliable performance in demanding industrial conditions.
The PR6423/010-100-CN CON021 delivers a frequency range from DC to 20,000 Hz with a rise time under 15 microseconds—performance that captures fleeting vibration events often missed by slower converters. In high-speed turbomachinery, where shaft speeds can exceed 10,000 RPM, this rapid response means that transient rubs, sudden imbalances, or momentary instabilities are recorded before they escalate.

The PR6423/010-100-CN CON021 carries intrinsic safety approvals for Zone 0, 1, and Division 1 locations—ATEX II 2 G Ex ia IIC T4 Gb, IECEx Ex ia IIC T4 Gb, and CSA Class I Division 1—when used with safety barriers. For less stringent environments, non-sparking (nA) approvals cover Zone 2 and Division 2 applications.

The PR6423/010-100-CN CON021 is built for field reliability with an LMgSi 0.5 F22 aluminum housing that weighs just 120 grams yet withstands 5g vibration at 60 Hz. Installation requires no specialized tools: the probe connects via a self-locking Lemo plug, supply and output wires terminate in screw terminals accepting up to 1.5 mm² conductors, and the unit mounts with four included M5 screws.

The PR6423/010-100-CN CON021 Emerson Epro Eddy Current Signal Converter may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Emerson Epro PR6423/010-100-CN CON021 Eddy Current Signal Converter Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Emerson Epro PR6423/010-100-CN CON021 Eddy Current Signal Converter Specs

General

  • Manufacturer Emerson Epro
  • Model PR6423/010-100-CN CON021
  • Condition New Original ready stock
  • Product Family PR6423/004-120-CN CON021,PR6423/000-000-CN CON021,PR6422/000-000-CN CON021
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Power Industry: Large steam turbines, gas turbines, and hydroelectric generator sets.
  • Petroleum and Chemical Industry: Large centrifugal/axial flow compressors, multistage pumps, and gearboxes.
  • Metallurgy and Mining: Large fans, blowers, and monitoring of key rotating bearings.
  • High-Precision Measurement: Features excellent linear response with a standard sensitivity of 4 V/mm (for a 4mm range), capturing even the slightest signs of mechanical wear.
  • Superior Frequency Response: Supports a bandwidth from 0 Hz (static displacement) to up to 10,000 Hz (dynamic vibration), ensuring no high-frequency mechanical faults are missed.
  • Reduced Downtime: Real-time data monitoring enables Condition-Based Maintenance (CBM), providing early warning before substantial equipment damage occurs, significantly improving factory operating efficiency.
  • Axial Displacement Monitoring (Thrust Measurement): Installed near the thrust bearing, it monitors the axial position of the rotor relative to the stator, preventing collisions between the rotor and stationary components due to excessive load.
  • Radial Vibration Monitoring (Radial Vibration): A pair of probes (X-Y monitoring) are mounted vertically at 90 degrees on the bearing housing to plot the shaft trajectory, diagnosing imbalance, misalignment, or bearing wear.
  • Speed ​​and Keyway Monitoring (Tacho/Phase): Monitors the keyways or protrusions on the shaft, providing speed signals and serving as a phase reference for vibration analysis.
Description
The PR6423/010-100-CN CON021 converts signals from eddy current probes into precise voltage outputs proportional to shaft displacement, velocity, and position. With a frequency response extending from DC to 20 kHz and rise time under 15 microseconds, it captures both static gaps and high-frequency vibration events on turbines, compressors, and fans.

Designed for harsh industrial environments, the PR6423/010-100-CN CON021 operates reliably from -30 to 100°C and withstands 5g vibration at 60 Hz. Its IP20-rated housing weighs just 120 grams and mounts with four M5 screws.

The PR6423/010-100-CN CON021 carries multiple hazardous area certifications. For intrinsic safety, it meets ATEX II 2 G Ex ia IIC T4 Gb, IECEx Ex ia IIC T4 Gb, and CSA Class I Division 1 requirements when used with safety barriers. For non-sparking applications, CSA Class I Division 2 approvals cover Zone 2 environments.

This converter solves the challenge of obtaining reliable, high-bandwidth shaft monitoring data in explosive environments. The PR6423/010-100-CN CON021 pairs with PR6422 through PR6426 probes, with extended range versions available for PR6425 applications.
Alternative Names
PR6423/004-120-CN CON021 PR6423/000-000-CN CON021 PR6422/000-000-CN CON021 PR6424/000-000-CN CON021
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which probes work with the PR6423/010-100-CN CON021?
It is compatible with PR6422, PR6423, PR6424, PR6425, PR6426, and PR6453 probes. PR6425 requires the extended range version (CON021/91x-xxx).
What temperature range does this converter handle?
It operates from -30 to 100°C. For intrinsic safety applications, the temperature range is -20 to 80°C when used with a safety barrier.
How fast is the response of the PR6423/010-100-CN CON021?
Rise time is less than 15 microseconds, capturing transient events that slower converters miss—critical for high-speed turbomachinery diagnostics.
What approvals does it carry for hazardous areas?
ATEX II 2 G Ex ia IIC T4 Gb, IECEx Ex ia IIC T4 Gb, CSA Class I Division 1 (ia), and CSA Class I Division 2 (nA) for non-sparking applications.
