Emerson 5X00226G04 is the IOIC card paired with 5X00481G04 in an Ovation OCR1100 controller.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 5X00226G04
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 5X00226G04

  • Manufacturer:
    Emerson
  • Part Number:
    5X00226G04
  • Product Family:
    Ovation
  • Product Type:
    Ovation Controller IOIC Card
  • Stock:
    1
  • Card Function:
    Controller IOIC Card
  • Companion CPU Card:
    5X00481G04
  • Controller Assembly:
    OCR1100 — 5X00481G04 / 5X00226G04
  • Local I/O Support:
    Ovation I/O and WDPF I/O
  • Remote I/O Support:
    Ovation I/O and WDPF I/O
  • Virtual I/O:
    Ethernet
  • Sequence-of-Events Resolution:
    1 ms
  • Controller Capacity:
    Up to 32,000 points
  • Tariff Code:
    9032900090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Pairing Interfaces Events Application
  • IOIC card in the documented Emerson Ovation OCR1100 controller assembly
  • Pairs with 5X00481G04, the corresponding OCR1100 controller CPU card
  • Interfaces the controller with local, remote, digital-bus, and Ethernet virtual I/O

5X00226G04 is an Emerson Ovation Controller IOIC Card designed for the OCR1100 controller platform.

Its documented role is the controller-side I/O interface, linking the companion CPU card to Ovation or WDPF I/O and supported virtual-I/O paths.

Before installation or replacement, verify the paired CPU card, controller redundancy, I/O architecture, bus connections, virtual-I/O configuration, and saved controller database.

Availability, condition, price, and shipping time for 5X00226G04 are confirmed during quotation.

Emerson 5X00226G04 Ovation OCR1100 Controller IOIC Card Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • 5X00226G04 is the IOIC card in the OCR1100 controller pair
  • The documented companion CPU card is 5X00481G04
  • Both card identifiers must be matched when servicing the complete controller
  • The controller interfaces local and remote Ovation I/O
  • Local and remote WDPF I/O are also supported in the documented architecture
  • Virtual I/O can be exchanged through Ethernet
  • The OCR1100 architecture supports 1 ms sequence-of-events processing
  • The controller supports data-acquisition and sequence-of-events functions
  • Cold-junction compensation is included among the documented controller functions
  • Ovation process control for power-generation systems
  • OCR1100 controller I/O integration in water and wastewater systems
  • Distributed control applications using local, remote, or virtual Ovation I/O
Description
5X00226G04 is an Emerson Ovation Controller IOIC Card for the documented OCR1100 controller assembly.

The card is paired with CPU card 5X00481G04 and provides the OCR1100 interface to local or remote Ovation and WDPF I/O, digital buses, and virtual I/O over Ethernet.

Before installation or replacement, confirm both card identifiers, controller redundancy, local and remote I/O architecture, bus configuration, Ethernet virtual-I/O mapping, and the saved controller database.
Alternative Names
Emerson 5X00226G04 Emerson Ovation 5X00226G04 Ovation 5X00226G04 Ovation OCR1100 5X00226G04 5X00226 G04 5X00226G04 IOIC Card OCR1100 IOIC Card 5X00226G04
Technical notes
Emerson 5X00226G04 must be serviced as the documented OCR1100 IOIC card and matched to CPU card 5X00481G04, the installed I/O architecture, and the saved controller database.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which CPU card is paired with Emerson 5X00226G04?
Emerson documents 5X00481G04 as the CPU card paired with the 5X00226G04 IOIC card in the OCR1100 controller assembly.
Can Emerson 5X00226G04 interface with legacy WDPF I/O?
Yes. Emerson documents the OCR1100 architecture for local and remote WDPF I/O as well as Ovation I/O.
What sequence-of-events resolution is associated with Emerson 5X00226G04 in the OCR1100 architecture?
The official OCR1100 data sheet documents 1 ms sequence-of-events resolution for the controller architecture.
Does Emerson 5X00226G04 support virtual I/O over Ethernet?
The OCR1100 controller documentation includes virtual I/O over Ethernet among its supported I/O interface functions.
Can Emerson 5X00226G04 be selected from CPU speed or memory specifications alone?
No. It is the IOIC card, not the CPU card. Selection must match the complete OCR1100 assembly, including companion CPU card 5X00481G04 and the installed I/O architecture.
What controller database checks matter when replacing Emerson 5X00226G04?
Confirm local and remote I/O assignments, digital-bus interfaces, virtual-I/O mapping, redundancy configuration, and the saved OCR1100 controller database before replacement.
How should buyers identify a complete OCR1100 controller containing Emerson 5X00226G04?
Match both official card numbers: CPU card 5X00481G04 and IOIC card 5X00226G04. Do not treat either card number alone as the complete controller assembly.
