IC693ALG391

/ 4.9
1001 reviews | Need a Specific Revision?
IC693ALG391 is a GE Fanuc Series 90-30 two-channel analog current output module for 0–20 mA or 4–20 mA control signals.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for IC693ALG391
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC693ALG391

  • Manufacturer:
    General Electric
  • Part Number:
    IC693ALG391
  • Product Family:
    GE 90-30 Series PLC
  • Product Type:
    Series 90-30 2-channel analog current output module
  • Stock:
    1
  • Output channels:
    2
  • Current ranges:
    4 to 20 mA or 0 to 20 mA
  • Voltage ranges:
    1 to 5 V or 0 to 5 V; 2 to 10 V or 0 to 10 V with resistor
  • Converter resolution:
    12 bit
  • Both-channel update:
    Approximately 5 ms
  • External supply:
    20 to 30 VDC, 10% maximum ripple
  • Maximum compliance voltage:
    25 V
  • Current-output load:
    0 to 850 Ω
  • Isolation:
    1,500 V
  • 5 VDC backplane current:
    30 mA
  • External 24 VDC current:
    215 mA
  • Fault behavior:
    Hold last value or configurable default
  • Range selection:
    Channel jumper selectable
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Output Control Fallback State Wiring Applications

Features:

  • Two 12-bit analog current outputs
  • Jumper selection for 0–20 mA or 4–20 mA operation
  • Hold-last-state or default-state response can be selected
IC693ALG391 translates PLC output words into a pair of continuous current commands.

Hardware settings define both the output span and the behavior expected when CPU control is interrupted.

The isolated field stage can be wired with an external supply where the chosen installation arrangement calls for it.

The General Electric IC693ALG391 Series 90-30 2-channel analog current output module may remain available for quotation and installed-system support from Apter Power.
General Electric IC693ALG391 Series 90-30 2-channel analog current output module Manuals, Datasheets, LinksImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Current-command behavior

  • Channel count: Two independent analog commands are generated from the PLC output data.
  • Selectable span: Jumpers establish 0–20 mA or 4–20 mA operation.
  • Resolution: Each channel uses 12-bit digital-to-analog conversion.
  • Refresh: Outputs are updated every PLC sweep, typically in about 5 ms.

Response to control loss

  • Hold option: A jumper can retain the last commanded value when CPU service is lost.
  • Default option: The alternative setting moves the channel to its assigned default behavior.
  • Process consequence: The correct choice depends on the safe response of the connected valve, drive, or actuator.
  • Replacement check: Fallback jumpers must be copied from the installed module before exchange.

Field-side integration

  • Shielded pair: Twisted shielded cable carries each analog output to the field device.
  • External supply: The applicable wiring arrangement can use an external field source.
  • Voltage option: A jumper configuration permits the supported voltage-source use.
  • Optical barrier: The analog output section is optically separated from the logic backplane.

Supported control outputs

  • Valve positioning: Current commands can drive compatible positioners for modulating process flow.
  • Drive references: Analog speed or torque references can be sent to qualifying motor drives.
  • Actuator commands: Two loop-controlled actuators can receive independent PLC setpoints.
  • Recorder signals: A current output can retransmit a calculated process value to recording or indicating equipment.
Description
IC693ALG391 is a two-channel analog current output module that generates field-device commands from Series 90-30 output words. Hardware jumpers select 0–20 mA or 4–20 mA behavior.

With IC693ALG391, the 12-bit outputs update once per PLC scan, with a typical response of about 5 ms. A further jumper choice determines whether an output holds its last commanded state or moves to its configured default when the CPU no longer controls the module.

When integrating IC693ALG391, an optional voltage-source arrangement is available through the applicable jumper configuration. Optical isolation separates the field-output circuitry from logic, and twisted shielded cable is used to maintain signal quality.
Revisions

Revision Part #

Also known as

IC693ALG391B
IC693ALG391-B, Series B, Rev B
IC693ALG391C
IC693ALG391-C, Series C, Rev C
IC693ALG391D
IC693ALG391-D, Series D, Rev D
IC693ALG391E
IC693ALG391-E, Series E, Rev E
IC693ALG391F
IC693ALG391-F, Series F, Rev F
Alternative Names
IC 693 ALG391 IC693-ALG391 GE IC693ALG391 GE Fanuc IC693ALG391 Series 90-30 IC693ALG391 ALG391 IC693 ALG391 1C693ALG391
Technical notes
IC693ALG391 has separate jumpers for signal range and fallback response; both settings must be duplicated before a replacement is placed in service.
