IC693APU300

/ 4.9
1001 reviews | Need a Specific Revision?
IC693APU300 is a GE Fanuc Series 90-30 high-speed counter module for rapid pulse measurement and control.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for IC693APU300
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC693APU300

  • Manufacturer:
    General Electric
  • Part Number:
    IC693APU300
  • Product Family:
    GE 90-30 Series PLC
  • Product Type:
    Series 90-30 high-speed counter module
  • Stock:
    1
  • Module function:
    High Speed Counter
  • Maximum input frequency:
    80 kHz
  • Counter arrangements:
    1, 2, or 4
  • Count modes:
    Up, down, or difference
  • Input levels:
    5 VDC, 12 VDC, or 24 VDC
  • Input points:
    12
  • Output points:
    4
  • Processing:
    Dedicated hardware independent of the CPU scan
  • Mounting:
    Any Series 90-30 baseplate
  • Configuration:
    Hand-Held Programmer, Logicmaster, or VersaPro
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Counting Modes Signal Handling Configuration Applications

Features:

  • Dedicated pulse processing at frequencies up to 80 kHz
  • Configurable as one, two, or four counters
  • Supports up, down, and difference counting arrangements
IC693APU300 is the Series 90-30 specialty module for events too fast to rely on ordinary input scanning.

Hardware counters continue acquiring pulses while the CPU reads results and writes comparison or control parameters.

Its mode selection adapts one module to several encoder, flow, and production-counting patterns.

The General Electric IC693APU300 Series 90-30 high-speed counter module may remain available for quotation and installed-system support from Apter Power.
General Electric IC693APU300 Series 90-30 high-speed counter module Manuals, Datasheets, LinksImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Hardware counter functions

  • Counter quantity: The configuration can allocate one, two, or four counters.
  • Direction modes: Inputs support up-counting, down-counting, and difference relationships.
  • Frequency: Supported modes can accept pulse rates as high as 80 kHz.
  • Scan independence: Pulse acquisition proceeds in dedicated hardware rather than waiting for each PLC sweep.

Fast input integration

  • Source matching: Input wiring and threshold characteristics must match the encoder or pulse device.
  • Counter control: The PLC project starts, resets, presets, and reads the configured counters.
  • Comparison events: Configured count relationships support high-speed decisions and application responses.
  • Noise control: Shielding, grounding, and pulse quality are important at elevated input frequencies.

Application setup

  • Mode selection: The chosen counter mode determines terminal use and available functions.
  • Parameter transfer: Preset, limit, and control information is exchanged through assigned Series 90-30 references.
  • Timing plan: Output or program response is designed around the hardware event and PLC scan relationship.
  • Replacement record: Mode, terminal assignment, and configured values should be captured before changing the module.

Supported high-speed uses

  • Meter proving: Pulse totals can support proving calculations for turbine flowmeters.
  • Velocity measurement: Encoder frequency can be converted into machine speed information.
  • Material handling: Rapid product counts and position events can track conveyors and transfer equipment.
  • Motion and process control: High-speed comparison events can coordinate indexing, cut-to-length, or batch operations.
Description
IC693APU300 is a high-speed counter module that processes pulse inputs independently of the normal PLC scan, allowing rapid events to be counted, compared, and acted upon between sweeps.

During commissioning of IC693APU300, the module supports one, two, or four counters and counting arrangements that include up, down, and difference operation. Input frequencies can reach 80 kHz in the supported mode and wiring configuration.

With a system based on IC693APU300, counter values and control data are exchanged with the Series 90-30 application while the dedicated hardware performs the time-critical acquisition. This division suits speed, position, flow, and material-tracking tasks that exceed standard discrete-input timing.
Revisions

Revision Part #

Also known as

IC693APU300D
IC693APU300-D, Series D, Rev D
IC693APU300E
IC693APU300-E, Series E, Rev E
IC693APU300F
IC693APU300-F, Series F, Rev F
IC693APU300G
IC693APU300-G, Series G, Rev G
IC693APU300H
IC693APU300-H, Series H, Rev H
IC693APU300J
IC693APU300-J, Series J, Rev J
Alternative Names
IC 693 APU300 IC693-APU300 GE IC693APU300 GE Fanuc IC693APU300 Series 90-30 IC693APU300 APU300 IC693 APU300 IC693APU3OO
Technical notes
IC693APU300 terminal assignments change with counter mode; copying only PLC reference addresses is insufficient unless the physical pulse wiring matches that mode.
