          Product manuals, quotations, and EX2100e matching for IS230SNAIH2A are supported by Apter Power.

        IS230SNAIH2A

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        General Electric IS230SNAIH2A is an EX2100e Mark VIe analog input module combining a PAICH1B I/O pack with an STAIH2A terminal board.
        In Stock
        Ships by Tuesday, September 29
        Fast Shipping Available
        Get a quick price for IS230SNAIH2A
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IS230SNAIH2A

        • Manufacturer:
          General Electric
        • Part Number:
          IS230SNAIH2A
        • Product Family:
          GE Excitation Control
        • Product Type:
          Mark VIe Analog Input Module
        • Stock:
          1
        • I/O Pack:
          PAICH1B
        • Terminal Board:
          STAIH2A
        • Analog Inputs:
          10 channels
        • Inputs 1–8:
          ±10 V or 0–20 mA
        • Inputs 9–10:
          Current input channels
        • Analog Outputs:
          Two 0–20 mA channels
        • Transmitter Power:
          22.8–25.2 V, 21 mA
        • Wiring Support:
          Two-, three-, four-wire, or externally powered transmitters
        • Power Supply:
          22.5–28.6 V dc, 0.49 A maximum
        • Redundancy:
          STAIH2A simplex terminal configuration
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Channel Assignment Transmitter Wiring Module Composition Power Boundaries

        Features:

        • IS230SNAIH2A pairs PAICH1B conversion with STAIH2A field termination.
        • Input assignments distinguish configurable channels from current-only channels.
        • The module supports internally and externally powered transmitter loops.
        IS230SNAIH2A keeps IONet communication in the pack and removable field wiring on the terminal board.

        Two analog outputs share the same simplex terminal assembly as the inputs.

        Electronic identification checks the terminal-board identity seen by the PAIC pack.

        The General Electric IS230SNAIH2A Mark VIe Analog Input Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        General Electric IS230SNAIH2A Mark VIe Analog Input Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Ten Analog Inputs

        • Channels 1–8: Each input can be configured for ±10 V or 0–20 mA.
        • Channels 9–10: The final pair is assigned to current-input service.
        • Output pair: Two terminal-board channels provide 0–20 mA analog outputs.
        • Signal conversion: The PAIC pack digitizes field inputs for transfer over IONet.

        Field Loop Arrangements

        • Two-wire loops: Transmitters can use the module supply and a shared signal return.
        • Three-wire devices: Separate supply and signal conductors are supported.
        • Four-wire devices: Independently powered signal sources can terminate at STAI.
        • External supply: Field-powered transmitters may bypass the onboard loop source.

        Pack and Terminal Board

        • I/O pack: PAICH1B performs conversion, diagnostics, and IONet communication.
        • Terminal board: STAIH2A provides the simplex field termination.
        • Removable blocks: High-density Euro-style connectors retain field wiring.
        • Identification: An electronic ID device reports terminal-board identity to the pack.

        Supply and Loop Limits

        • Module input: The assembly accepts 22.5–28.6 V dc.
        • Maximum draw: PAICH1B current is limited to 0.49 A.
        • Loop supply: Transmitter power remains between 22.8 and 25.2 V.
        • Source current: Each defined transmitter-power output is limited to 21 mA.
        Description
        Built from a PAICH1B I/O pack and an STAIH2A terminal board, General Electric IS230SNAIH2A is a Mark VIe analog module for the EX2100e excitation-control I/O arrangement. The pack handles conversion and network communication while the terminal board carries field wiring.

        Input channels on IS230SNAIH2A are divided between configurable voltage/current positions and current-only positions. This distinction determines where a voltage source may be landed and prevents the last two inputs from being treated as universal analog channels.

        Transmitter loops connected to IS230SNAIH2A may use two-, three-, or four-wire arrangements, including independently powered devices. The wiring choice determines whether the onboard loop source is used or bypassed; it does not change the simplex STAIH2A terminal architecture.

        One or two IONet connections can reach the PAICH1B pack in IS230SNAIH2A. Terminal-board identification is returned to the pack so the installed STAI hardware can be checked before the analog signals are placed in service.
        Alternative Names
        GE IS230SNAIH2A General Electric IS230SNAIH2A IS230-SNAI-H2A IS230 SNAI H2A SNAI H2A Analog Input Module GE SNAI H2A Assembly EX2100e SNAI Module IS230SNAI H2A
        Technical notes
        IS230SNAIH2A is the exact PAICH1B plus STAIH2A assembly; the H2A terminal board keeps the module in a simplex field-terminal configuration.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        A ±10 V source on channel 9 of IS230SNAIH2A produces the wrong reading. Is that channel voltage-capable?
        No. Only channels 1–8 on IS230SNAIH2A accept either ±10 V or 0–20 mA; channels 9 and 10 are assigned to current input.
        Why does a two-wire transmitter connected to IS230SNAIH2A remain unpowered?
        For an internally supplied loop, verify the IS230SNAIH2A transmitter-power terminals, the 22.8–25.2 V source range, and the 21 mA per-output boundary.
        An independently powered transmitter is being added to IS230SNAIH2A. Should it also use the onboard loop supply?
        No. Route the external transmitter supply independently and land only the defined signal circuit at IS230SNAIH2A; the onboard loop source is bypassed for that wiring arrangement.
        The controller sends an analog command but the field loop stays at zero on IS230SNAIH2A. Which terminal path should be checked?
        Trace the affected one of the two 0–20 mA output channels through the removable STAIH2A terminal block on IS230SNAIH2A and verify the field-loop return.
        IS230SNAIH2A reports a terminal-hardware mismatch after the I/O pack is replaced. What identifies the connected board?
        The electronic ID device on the STAIH2A terminal board reports its identity to the PAICH1B pack in IS230SNAIH2A; inspect that board and pack connection.
        Can two IONet connections make IS230SNAIH2A a TMR field-terminal assembly?
        No. The PAICH1B pack in IS230SNAIH2A can connect to one or two IONet networks, but the STAIH2A field termination remains simplex.
