General Electric IS210JPDDG1A is a Mark VIe DC power distribution board that isolates and protects six control-power branches from one 24 VDC or 125 VDC source.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for IS210JPDDG1A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS210JPDDG1A

  • Manufacturer:
    General Electric
  • Part Number:
    IS210JPDDG1A
  • Product Family:
    GE Mark VIe Distributed I/O
  • Product Type:
    Mark VIe DC Power Distribution Board
  • Stock:
    1
  • DC Input Options:
    24 V dc or 125 V dc; not simultaneous
  • Input Rating:
    24 V dc at 30 A or 125 V dc at 15 A
  • Protected Branches:
    Six
  • Branch Isolation:
    Two-pole switch per output
  • Fuses:
    Twelve, 15 A, 250 V
  • Output Indication:
    One green lamp per branch
  • Operating Temperature:
    −30 to 65 °C
  • Board Dimensions:
    23.495×10.795 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals DC Input Selection Branch Protection Output Distribution Installation Limits

Features:

  • IS210JPDDG1A accepts one 24 V dc or 125 V dc source for six distribution branches.
  • Every output has two fuses, a two-pole switch, and a green status lamp.
  • Version G1 contains twelve installed 15 A, 250 V fuses.
IS210JPDDG1A keeps branch isolation and protection local to each two-pin DC output.

The two input voltage options on IS210JPDDG1A are mutually exclusive and must not be energized together.

IS210JPDDG1A has no configuration jumpers or electronic diagnostic reporting circuit.

The General Electric IS210JPDDG1A Mark VIe DC Power Distribution Board is listed by Apter Power with product documentation and matching support.
General Electric IS210JPDDG1A Mark VIe DC Power Distribution Board Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

One Source Voltage at a Time

  • 125 V dc input: The distribution input is rated for 15 A.
  • 24 V dc input: The lower-voltage input is rated for 30 A.
  • Source boundary: The 24 V and 125 V inputs cannot be energized together.
  • Polarity check: Positive and negative conductors must match the labeled input path.

Two Fuses per Output

  • Fuse count: Twelve fuses protect six output branches.
  • G1 hardware: Installed fuses are 15 A, 250 V, quarter-inch by one-and-a-quarter-inch types.
  • Isolation: A two-pole switch disconnects both conductors of each branch.
  • Maximum rating: Replacement fuse ratings must not exceed 15 A.

Six Controlled DC Branches

  • Load connectors: Six two-pin outputs provide individually fused DC feeds.
  • Status lamps: A green indicator shows the switched state of every branch.
  • Daisy-chain path: Additional connectors continue the defined distribution bus.
  • Typical loads: The board distributes relay, solenoid, and contact-wetting power.

DIN-Rail Operating Boundaries

  • Mounting: JPDD is installed as a DIN-rail power-distribution assembly.
  • Temperature: The operating range is −30 to 65 °C.
  • Configuration: No jumpers or electronic setup parameters are provided.
  • Diagnostics: The board has no electronic diagnostic reporting circuit.
Description
General Electric IS210JPDDG1A is a DIN-rail DC power distribution board for Mark VIe control and I/O power circuits. It accepts either a 24 V dc or 125 V dc source and distributes that supply through six separately controlled branches for relay, solenoid, and contact-wetting power paths.

Each output branch on IS210JPDDG1A contains two fuses, a two-pole isolation switch, and a green status lamp. This arrangement disconnects both conductors of an individual branch while retaining separate branch protection and a visible indication of the switched output state.

The input section of IS210JPDDG1A is rated for either 125 V dc at 15 A or 24 V dc at 30 A; both input voltages cannot be connected at the same time. Six two-pin fused outputs feed the defined loads, and additional connectors support daisy-chaining within the permitted DC distribution architecture.

Version G1 of IS210JPDDG1A is supplied with twelve quarter-inch by one-and-a-quarter-inch, 15 A, 250 V fuses. The board has no electronic diagnostics or configuration jumpers; installation checks center on input polarity, the six branch switches, fuse ratings not exceeding 15 A, and the −30 to 65 °C operating range.
Alternative Names
GE IS210JPDDG1A General Electric IS210JPDDG1A IS210-JPDD-G1A IS210 JPDD G1A JPDD G1A DC Distribution Board GE JPDD G1A Power Board Mark VIe JPDD Distribution Module IS210JPDD G1A
Technical notes
IS210JPDDG1A is the G1 JPDD assembly with twelve installed 15 A fuses across six switched DC output branches.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can 24 VDC and 125 VDC be connected to IS210JPDDG1A together?
No. IS210JPDDG1A accepts either the 24 V dc input or the 125 V dc input, and the two source voltages must not be applied simultaneously.
What isolates one faulty load branch on IS210JPDDG1A?
Each IS210JPDDG1A branch has two fuses and a two-pole switch, allowing both conductors of that output to be isolated.
How can an operator see whether an IS210JPDDG1A branch is switched on?
A green lamp is assigned to each IS210JPDDG1A output branch and indicates the switched DC output state.
What fuse size is installed in IS210JPDDG1A version G1?
IS210JPDDG1A G1 uses twelve quarter-inch by one-and-a-quarter-inch fuses rated 15 A and 250 V.
May a fuse above 15 A be fitted to IS210JPDDG1A?
No. IS210JPDDG1A can use approved alternate fuse ratings up to 15 A, but a branch fuse must not exceed 15 A.
Does IS210JPDDG1A report electronic diagnostic alarms?
No electronic diagnostic circuit is provided on IS210JPDDG1A; status is checked through branch lamps, switch positions, source polarity, and fuse condition.
