General Electric IS200JPDBG1A is a Mark VIe PDM AC power distribution board that conditions two AC feeds and supplies monitored, protected branch circuits.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for IS200JPDBG1A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS200JPDBG1A

  • Manufacturer:
    General Electric
  • Part Number:
    IS200JPDBG1A
  • Product Family:
    GE Mark VIe Distributed I/O
  • Product Type:
    AC Power Distribution Board
  • Stock:
    1
  • AC Inputs:
    Two independent circuits
  • Nominal Voltage:
    115/230 V AC
  • Circuit Rating:
    20 A per input
  • Branch Structure:
    One fused and three fused/switched outputs per input
  • Branch Fuses:
    10 A, 250 V
  • Feedback Ports:
    P1 and P2 diagnostic ribbon connectors
  • Neutral Arrangement:
    Grounded neutral
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Dual AC Feeds Branch Protection Feedback Chain Source Boundaries

Features:

  • Keeps two 115/230 V AC distribution circuits electrically separate.
  • Reports AC magnitude and fuse condition through the PPDA chain.
  • Provides eight protected branch paths across its two input sections.
The JPDB assembly places filtering and branch protection at the AC entry point of the Mark VIe power-distribution structure.

Local switches isolate six of the branch outputs, while the remaining pair is fused without branch switching.

A G1 board is selected where source-selection hardware is not required; the monitored P1/P2 chain remains available for PDM feedback.

The General Electric IS200JPDBG1A AC Power Distribution Board may be available for purchase and support from Apter Power.
General Electric IS200JPDBG1A AC Power Distribution Board Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Input Circuit Layout

  • Line filters: One filter conditions each incoming AC circuit.
  • Input isolation: The two 20 A paths remain separate through distribution.
  • Single-source wiring: Parallel input wiring is used when both sections share one supply.
  • Voltage class: The same architecture accepts nominal 115 or 230 V AC.

Protected Load Paths

  • Fixed branches: Each input section has one fused unswitched output.
  • Switched branches: Three additional outputs per section include local switching.
  • Fuse feedback: Monitoring circuits track the condition of every branch fuse.
  • Circuit boundary: Individual outputs remain assigned to their originating AC feed.

PPDA Signal Routing

  • P1 direction: Local status travels from the board toward the PPDA I/O pack.
  • P2 pass-through: Upstream monitoring data can continue through the second ribbon port.
  • Measured state: Both AC magnitudes are included in the passive feedback set.
  • Shared diagnostics: Two JPDB boards can report through one PPDA when cabled accordingly.

G1 Configuration Limits

  • Selector interface: The G1 board does not include the source-selector connector.
  • Hardware setup: No jumpers or adjustable devices are fitted.
  • Neutral reference: The supported AC arrangement uses a grounded neutral.
  • DC branch option: A dedicated connection can feed an optional JPDF module.
Description
General Electric IS200JPDBG1A is the JPDB AC power distribution board in the Mark VIe Power Distribution Module. It conditions, monitors, and divides incoming AC power before branch circuits feed other control-system loads.

Two line filters on IS200JPDBG1A serve separate 20 A circuits for 115 or 230 V AC. Each side provides one fused output and three outputs that combine fusing with local switching, keeping the two incoming feeds electrically distinct through the branch stage.

Power-status feedback from IS200JPDBG1A leaves through P1 toward a PPDA I/O pack, while P2 passes monitoring signals from another distribution board. The board also provides a connection path for an optional JPDF 125 V DC distribution module.

The G1 configuration of IS200JPDBG1A has no AC source-selector connector and no adjustable hardware. When one AC source supplies the installation, both input circuits are wired in parallel to prevent missing-source alarms, and the AC neutral remains grounded.
Alternative Names
IS200JPDBG1A IS200-JPDB-G1A IS200 JPDB G1A GE IS200JPDBG1A General Electric IS200JPDBG1A Mark VIe JPDB G1A IS200JPDB G1A AC Distribution Board IS2OOJPDBG1A
Technical notes
General Electric IS200JPDBG1A separates two filtered AC feeds into protected branch circuits and reports power and fuse status through the PPDA feedback chain.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why can a single AC source cause a missing-source alarm on IS200JPDBG1A?
With one source, both IS200JPDBG1A input circuits must be wired in parallel so the PPDA sees voltage on each monitored AC path.
IS200JPDBG1A has no source-selector socket—is hardware missing?
No. IS200JPDBG1A is the G1 arrangement, which omits the selector connector; that interface belongs to the G2 board version.
A load branch from IS200JPDBG1A is dead although the input remains live. What should be separated in the check?
Check the fuse and local switch assigned to that IS200JPDBG1A branch, then compare the reported fuse state without disturbing the other input circuit.
How should P1 and P2 be oriented when adding IS200JPDBG1A to a PPDA feedback chain?
Route IS200JPDBG1A P1 toward the PPDA and use P2 for monitoring signals arriving from another power-distribution board.
Can IS200JPDBG1A feed a 125 V DC branch assembly directly?
IS200JPDBG1A includes the connection intended for an optional JPDF 125 V DC distribution module; the downstream board provides the DC branch distribution.
What neutral arrangement must be preserved around IS200JPDBG1A?
IS200JPDBG1A is designed for a grounded AC neutral, so line and neutral conductors must retain their documented positions at the board.
