General Electric IS200VAICH1DBC is a VME analog input card for GE Speedtronic Mark VI systems. It acquires and converts analog signals to monitor key parameters such as pressure, temperature, flow, and valve position in industrial applications.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for IS200VAICH1DBC
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS200VAICH1DBC

  • Manufacturer:
    General Electric
  • Part Number:
    IS200VAICH1DBC
  • Product Family:
    GE Mark VI Gas Turbine Control
  • Product Type:
    VME Analog Input Card
  • Stock:
    1
  • Slot:
    Standard VME bus slot
  • Version:
    BC (new version, AB compatible)
  • Total Channels:
    24
  • Analog Inputs:
    20
  • Analog Outputs:
    4
  • Signal Range:
    4-20 mA / ±1 mA
  • Redundancy:
    Supports TMR (Triple Redundancy) / Simplex
  • Adapter Terminals:
    TBAIH1C / STAI
  • Operating Temperature:
    0°C to +60°C (32°F to 140°F)
  • Storage Temperature:
    -40°C to +85°C (-40°F to 185°F)
  • Operating Humidity:
    5% to 95% RH (non-condensing)
  • Weight:
    0.34 kg
  • Estimated shipping dimensions:
    2x18.6x26.1cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Installation Application Scenarios Operation

Features:

  • Twenty analog inputs and four analog outputs support 4-20 mA and ±1 mA signal ranges for process measurement applications.
  • Compatibility with TMR and simplex systems allows adaptation to varying reliability requirements.
  • Wide temperature and humidity tolerances help maintain stable performance in power generation and heavy-duty automation facilities.
General Electric IS200VAICH1DBC is a key VME component used in GE Speedtronic Mark VI gas and steam turbine control platforms. Through continuous acquisition of analog information, the card helps maintain stable operation of critical industrial processes. Power plants and heavy industries frequently rely on such modules to supervise essential operating conditions. Compatibility between the BC version and the earlier AB version provides additional flexibility during maintenance or upgrades.

Field instruments generating current signals can be connected directly to General Electric IS200VAICH1DBC for measurement and control purposes. Pressure, temperature, flow, and valve position data are continuously transmitted to the control system for analysis and regulation. Adapter terminals TBAIH1C and STAI assist with efficient wiring arrangements and simplify installation procedures. Support for both redundant and simplex structures makes the module suitable for a broad range of system designs.

Industrial environments often expose equipment to temperature changes and electromagnetic disturbances. General Electric IS200VAICH1DBC addresses these challenges with a modular design intended for long-term operation. An operating temperature range from 0°C to +60°C and humidity tolerance of 5% to 95% RH allow dependable performance under demanding conditions. Such characteristics make the module a practical choice for turbine control and large-scale automation applications.

The IS200VAICH1DBC General Electric VME Analog Input Card may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IS200VAICH1DBC VME Analog Input Card Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
General Electric IS200VAICH1DBC VME Analog Input Card Specs

General

  • Manufacturer General Electric
  • Model IS200VAICH1DBC
  • Condition New Original ready stock
  • Product Family IS200VAICH1D,IS200VAICH1DA,IS200VAICH1DAB
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Power-off Verification: Always disconnect the rack power before operation.
  • Align the Rails: Align the card vertically with the VME rack rails.
  • Push In Smoothly: Push the card in evenly with both hands until it contacts the backplate.
  • Tighten the Screws: Tighten the fixing screws on the top and bottom sides of the panel.
  • Connect the Cable: Securely insert the signal cable from the front terminal board into the interface.
  • Gas Turbine Control: Used in the Mark VI system to monitor turbine exhaust temperature.
  • Steam Turbine Monitoring: Real-time acquisition of main steam pressure and valve opening feedback.
  • Power plant auxiliary automation: Flow transmitters connected to boiler feed pumps.
  • Heavy industry process control: Large-scale VME core control systems in steel mills and chemical industries.
  • Power-on Self-test: Observe the LED indicator status after the rack is powered on.
  • Status Confirmation: A solid green running light indicates successful board initialization.
  • Channel Calibration: Perform zero-point calibration on the analog input using the control software.
  • Data Monitoring: View the 4-20mA sampling data in real time on the host computer.
  • Periodic Maintenance: Regularly check the board temperature and the contact of the gold fingers.
Description
General Electric IS200VAICH1DBC serves as a VME analog input card installed in a standard VME bus slot. The BC version is fully compatible with the earlier AB version and provides a total of 24 channels, including 20 analog inputs and 4 analog outputs. Signal interfaces support 4-20 mA and ±1 mA ranges, making the module suitable for a wide variety of field devices.

Within GE Speedtronic Mark VI turbine control architecture, General Electric IS200VAICH1DBC plays an important role in collecting analog information from sensors and transmitting processed data to the control system. Pressure transmitters, temperature sensors, flow instruments, and valve position devices can all be connected to the module for continuous process supervision.

General Electric IS200VAICH1DBC is widely applied in gas and steam turbine control systems used in power generation and heavy industrial facilities. The card supports both TMR (Triple Redundancy) and simplex configurations, providing flexibility for applications that require different levels of system availability and reliability. Adapter terminals TBAIH1C and STAI simplify field wiring and integration.

Designed for harsh operating conditions, General Electric IS200VAICH1DBC can function within an ambient temperature range of 0°C to +60°C and tolerate storage temperatures from -40°C to +85°C. Operating humidity between 5% and 95% RH without condensation allows reliable performance in environments exposed to temperature fluctuations and industrial electromagnetic interference. Modular construction further contributes to dependable operation in turbine control applications.
Revisions

Revision Part #

Also known as

IS200VAICH1DA
IS200VAICH1D-A, Series A, Rev A
IS200VAICH1DAA
IS200VAICH1D-AA, Series AA, Rev AA
IS200VAICH1DAB
IS200VAICH1D-AB, Series AB, Rev AB
Alternative Names
IS2OOVAICH1DBC IS200VAICHIDBC IS200VAICH1DAB IS200VAICH1DA IS200VAICH1DAA IS200VCRCH1B IS200VRTDH1D IS200VSVOH1B
Technical notes
The General Electric IS200VAICH1DBC is a high-reliability VME analog input card designed for Mark VI systems, supporting up to 16 channels of high-resolution 4-20 mA or ±10 V sensor signals for critical turbine control.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does General Electric IS200VAICH1DBC fit a standard VME slot?
Installation of General Electric IS200VAICH1DBC requires a standard VME bus slot, allowing convenient integration into existing Mark VI systems.
How much temperature variation can General Electric IS200VAICH1DBC withstand?
Normal operation is supported between 0°C and +60°C, while storage conditions can range from -40°C to +85°C.
Which terminal boards are compatible with General Electric IS200VAICH1DBC?
Field connections for General Electric IS200VAICH1DBC are accomplished through TBAIH1C and STAI adapter terminals.
