531X305NTBANG1

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric 531X305NTBANG1 is a legacy NTB/3TB terminal board used to organize field and drive-control connections in an established GE control assembly.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 531X305NTBANG1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 531X305NTBANG1

  • Manufacturer:
    General Electric
  • Part Number:
    531X305NTBANG1
  • Product Family:
    GE Mark VIe Distributed I/O
  • Product Type:
    NTB/3TB Terminal Board
  • Stock:
    1
  • Board family:
    531X305NTBA
  • Interface boundary:
    Field wiring to legacy GE control assembly
  • Replacement control:
    Exact suffix and terminal map required
  • Weight:
    0.4 kg
  • Estimated shipping dimensions:
    28.6x7x3.8cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Terminal Interface Drive Matching Wiring Recovery Product Applications

Features:

  • Complete GE part number 531X305NTBANG1 with NG1 suffix.
  • NTB/3TB terminal-board role in a legacy control assembly.
  • Exact terminal, jumper and plug mapping required for replacement.
The board is an interface boundary, so wiring evidence is as important as the printed part number.

Closely related 531X variants may share a layout while carrying different termination assignments.

Receiving should compare the suffix and board details with the removed assembly before site release.
Availability is subject to Apter Power inventory and sourcing confirmation.
General Electric 531X305NTBANG1 NTB/3TB Terminal Board Manuals,Datasheets,Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Organizes the documented field and control connections.
  • Uses terminal numbering and conductor labels as restoration references.
  • Requires jumpers and plugs to return to their original positions.
  • Should be tested for continuity before automatic operation.
  • Match the complete 531X305NTBANG1 identity.
  • Confirm the host assembly and connector orientation.
  • Do not approve a neighboring suffix from outline dimensions alone.
  • Retain cabinet drawings and removal photographs for review.
  • Label every conductor before board removal.
  • Photograph terminal groups, jumpers and plug positions.
  • Reconnect circuits in the documented sequence.
  • Stop commissioning if a terminal map cannot be reconciled.
  • Legacy GE control-cabinet terminal restoration.
  • Field-wiring interface replacement during planned outages.
  • Exact-suffix spares for established drive/control assemblies.
  • Obsolete terminal-board maintenance planning.
Description
Cabinet wiring converges on 531X305NTBANG1, an NTB/3TB terminal board that separates field conductors from the associated legacy GE control electronics. Its value lies in creating a serviceable termination point rather than adding a new control function.

Every terminal, jumper and plug on 531X305NTBANG1 contributes to the wiring map that the host assembly expects. When that map is preserved, the replacement board can return existing signals to their former destinations without forcing changes elsewhere in the cabinet.

The NG1 suffix makes 531X305NTBANG1 a particular member of the 531X305NTBA board family. That distinction matters during sourcing because related boards may share the same outline while assigning connections differently; the complete suffix protects the installation from a visually plausible but electrically unsuitable choice.
Alternative Names
General Electric 531X305NTBANG1 GE 531X305NTBANG1 531X305NTBA NG1 531X305NTBANGI 531X305NTBANG-1 531X3O5NTBANG1 531X305NTB terminal board GE NTB/3TB board 531X305 NTBA NG1
Technical notes
Retain the complete 531X305NTBANG1 identity. Photograph terminal numbers, jumpers, plugs and wire labels before removal, and reconcile any suffix difference before reconnecting field circuits.
