IC200ALG331

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IC200ALG331 is a VersaMax 16-bit four-channel isolated analog output module with per-channel 4-20 mA or ±10 V selection.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for IC200ALG331
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC200ALG331

  • Manufacturer:
    General Electric
  • Part Number:
    IC200ALG331
  • Product Family:
    GE VersaMax
  • Product Type:
    16-Bit 4-Channel Isolated Analog Voltage/Current Output Module
  • Stock:
    1
  • Analog outputs:
    4 individually isolated channels
  • Per-channel configured ranges:
    4 to 20 mA current or -10 to +10 V DC voltage
  • Output operating range:
    +1 to 20 mA current mode; -10 to +10 V DC voltage mode
  • Converter resolution:
    16 bit
  • Nominal voltage resolution:
    381 µV per LSB
  • Maximum accuracy at 25 °C:
    ±0.1% of full scale
  • Current-mode load:
    0 to 1250 Ω
  • Voltage-mode load:
    2 kΩ minimum
  • Maximum update rate:
    7 ms
  • Minimum channel crosstalk rejection:
    70 dB
  • Isolation:
    250 V AC continuous; 1500 V AC for 1 minute, output-to-logic/frame and channel-to-channel
  • Backplane consumption:
    10 mA maximum at 5 V; 115 mA maximum at 3.3 V
  • External supply:
    +18 to +30 V DC including ripple; 100 mA maximum plus load currents
  • Tariff Code:
    8538900000
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Configuration Diagnostics Compatibility Application
  • Four individually isolated output channels can be configured independently
  • Each channel supports a 4-20 mA current command or a -10 to +10 V DC voltage command
  • Sixteen-bit conversion and a 7-millisecond maximum update support precise analog control

IC200ALG331 is a General Electric VersaMax analog output module designed for isolated voltage and current command signals.

The module converts four controller output words to independently configured 4-20 mA or ±10 V channels with scaling, alarms, default behavior, and field recalibration.

Before installation or replacement, verify the two-letter hardware/firmware revision, output mode, load, external supply, carrier terminals, isolation, scaling, defaults, and saved VersaMax configuration.

Availability, condition, price, and shipping time for IC200ALG331 are confirmed during quotation.

General Electric IC200ALG331 16-Bit 4-Channel Isolated Analog Voltage/Current Output Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Each channel independently selects 4-20 mA current or -10 to +10 V DC voltage output
  • Per-channel scaling maps configured engineering-unit values to output span values
  • Output behavior can hold the last state or use a configured default value
  • Configurable high and low limits support per-channel alarm reporting
  • The module reports overrange, underrange, open-wire, and loss-of-field-power conditions
  • A nonvolatile-memory fault diagnostic covers stored calibration or configuration data
  • The official module information requires PLC CPU firmware version 1.20 or later
  • Ethernet NIU IC200EBI001 is supported in all documented versions
  • Genius and Profibus NIUs require firmware 1.10 or later, while DeviceNet NIU requires 2.10 or later
  • Isolated 4-20 mA actuator commands in light process-control systems
  • Bipolar ±10 V speed or position references in motion-control applications
  • Four-channel analog setpoint generation in complex-machine control
Description
IC200ALG331 is a General Electric 16-bit, four-channel isolated analog voltage/current output module for the VersaMax control and distributed-I/O platform.

The unit provides per-channel 4-20 mA or ±10 V selection, 250 V AC continuous channel isolation, a 7 ms maximum update, and configurable scaling, alarms, and output defaults.

Before installation or replacement, confirm the complete catalog number, hardware and firmware revision letters, output mode, external supply, load, carrier wiring, scaling, default action, and saved project.
Revisions

Revision Part #

Also known as

IC200ALG331AA
IC200ALG331-AA, Series A, Rev A
IC200ALG331BA
IC200ALG331-BA, Series B, Rev A
IC200ALG331DA
IC200ALG331-DA, Series D, Rev A
IC200ALG331DB
IC200ALG331-DB, Series D, Rev B
IC200ALG331EB
IC200ALG331-EB, Series E, Rev B
IC200ALG331FB
IC200ALG331-FB, Series F, Rev B
Alternative Names
IC200ALG331 IC200 ALG331 IC200 ALG 331 GE IC200ALG331 General Electric IC200ALG331 GE Fanuc IC200ALG331 VersaMax IC200ALG331
Technical notes
IC200ALG331 uses two-letter hardware/firmware revisions and an external 18-30 V DC supply; verify output mode, load, isolation, scaling, defaults, carrier wiring, and host firmware.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What channel architecture is used by General Electric IC200ALG331?
General Electric IC200ALG331 provides four analog output channels with individual channel-to-channel isolation.
How can each channel of General Electric IC200ALG331 be configured?
Each channel can be independently configured for a 4-20 mA current output or a -10 to +10 V DC voltage output.
How precisely and quickly does General Electric IC200ALG331 generate analog outputs?
General Electric IC200ALG331 uses 16-bit conversion, with nominal resolution of 381 nA per LSB in current mode or 381 µV per LSB in voltage mode. Its maximum module update time is 7 milliseconds.
What field-power conditions must be met when using General Electric IC200ALG331?
General Electric IC200ALG331 requires an external +18 to +30 V DC supply, including ripple. Module consumption is rated at 100 mA maximum in addition to the connected output-load currents.
Which load limits apply to General Electric IC200ALG331 outputs?
In current mode, General Electric IC200ALG331 supports loads from 0 to 1250 ohms. In voltage mode, the connected load must be at least 2 kilohms.
How does General Electric IC200ALG331 help technicians diagnose output faults?
General Electric IC200ALG331 reports high- and low-limit conditions, overrange, underrange, open-wire, loss-of-field-power, and nonvolatile-memory faults.
What should be checked before installing General Electric IC200ALG331?
Confirm the complete model, two revision letters, output mode, load, external supply, carrier wiring, channel isolation, scaling, default behavior, host firmware, and saved configuration.
