Features:
- Configurable for sinking/sourcing signals with 0.5A per output point.
- Accepts 10-30V DC inputs and drives outputs at 24V DC.
- Operates in Conjunction with the M Series and Standard 3500
Monitors
The IC200MDD844 is a mixed discrete I/O module that provides both digital inputs and outputs in a single VersaMax package, saving space and simplifying system configuration. Each input can be individually configured as sinking or sourcing for 12/24V DC signals, offering maximum flexibility for connecting field devices. The IC200MDD844's 8 discrete outputs deliver up to 0.5A per point, capable of directly driving small relays, solenoids, and indicator lights.
The IC200MDD844 accepts a wide input voltage range of 10-30V DC for ON-state signals, with OFF-state detection below 5V DC, ensuring reliable detection from various field devices. The module draws approximately 7mA per input, minimizing loading on sensors and allowing long cable runs. The IC200MDD844's 24V DC outputs support up to 0.5A per channel with a maximum total current per module of 4A, providing sufficient power for most discrete output applications.
The IC200MDD844 includes built-in short circuit and overload protection for each output, protecting the module and connected devices from damage. Each channel features independent LED indicators for real-time status monitoring, simplifying troubleshooting and maintenance. The IC200MDD844's isolated power supply between input and output circuits provides enhanced noise immunity, ensuring reliable operation in industrial environments.
The IC200MDD844 GE I/O Module may still be available for purchase and support from Apter Power beyond
End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada Bently Nevada 130539-35 Standard Accelerometer Interconnect Cable Manuals,
Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not
included with this equipment unless listed in the above stock item description. All prices are
shown in USD.
GE IC200MDD844 I/O Module Specs
General
- Manufacturer GE
- Model IC200MDD844
- Condition New Original ready stock
- Product Family
IC200ALG322,IC200MDL740,IC200PWR102,IC200MDL241
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not
included with this equipment unless listed in the above stock item description. All prices are
shown in USD.
- Machine Tool Automation: Extensively deployed in CNC machinery, automated cutting tools, and sorting conveyors to simultaneously capture sensor states and energize directional solenoids.
- Distributed Pumping and Valve Skids: Integrated into chemical dosing blocks or local fluid distribution cabinets to collect limit-switch feedbacks and drive 24V DC auxiliary relays.
- Assembly Lines & Electronic Assembly: Serves as localized I/O nodes for discrete assembly stations, handling proximity sensors, pushbuttons, and indication lamps on a single module.
- Inter-Module Connection Loop: Mounts cleanly on a standard VersaMax carrier rack, interlocking with the VersaMax backplane. It consumes a conservative 70 mA at 5V DC from the backplane rail.
- Fieldbus and Ethernet Bridging: It does not speak protocols natively; instead, it streams its 16 input bits and 16 output bits to a VersaMax NIU. This allows the I/O data to be transmitted over Modbus RTU, Profinet, Profibus-DP, DeviceNet, or Ethernet Global Data (EGD) networks to a host controller like an RX3i PACSystems rack.
- Physical Wiring Interface: Connects to field sensors and actuators via removable terminal strips on the carrier base. The 16 inputs are organized into two isolated groups of 8 channels, while the 16 outputs share one single large common block.
- Regulatory Approvals: The module is UL Listed (File E194432) for safety, carries full CE Compliance markings, and is certified under RoHS environmental restriction guidelines.
- Electrical Galvanic Isolation: Features comprehensive opto-isolation rated up to 1500 VAC
- Short-Term Inrush Handling: Each individual sourcing output handles up to 0.5 Amps continuously, but includes a built-in buffer that safely absorbs up to 2.0 Amps of inrush current for 100ms to accommodate inductive motor or lamp starts.
