General Electric DS200VPBLG1A is an LS2100 VME P2 backplane board that distributes control power and interconnects the LCI card cage.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for DS200VPBLG1A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DS200VPBLG1A

  • Manufacturer:
    General Electric
  • Part Number:
    DS200VPBLG1A
  • Product Family:
    General Electric
  • Product Type:
    VME P2 Backplane Board
  • Stock:
    1
  • Board Designation:
    VPBL
  • System:
    LS2100 load-commutated inverter control
  • Backplane Section:
    VME P2
  • Card-Cage Areas:
    J2 and J3
  • Referenced Manual:
    GEI-100227
  • Startup Rails:
    +5 V, +15 V, -15 V and +24 V
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Backplane Role Power Rails Rack Startup System Context

Features:

  • Forms the P2 backplane for the J2 and J3 portions of the LS2100 VME card cage.
  • Provides the rack paths used for internal board interconnection and electronics power.
  • Exposes the regulated rails checked during LS2100 control-rack startup.
DS200VPBLG1A belongs to the printed-wiring-board set documented for GE LS2100 installation and startup.

The J2 area supports control and interface boards, while J3 is reserved for connections that cannot be placed on the board fronts.

Startup checks confirm +5 V, +15 V, -15 V and +24 V at the backplane before the full rack remains energized.

The General Electric DS200VPBLG1A LS2100 VME P2 Backplane Board may be available for purchase and technical support through Apter Power.
General Electric DS200VPBLG1A VME P2 Backplane Board Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

VME P2 Functions

  • Rack Position: The VPBL assembly forms the rear P2 connection plane.
  • J2 Area: This portion carries the supported LS2100 control-board positions.
  • J3 Area: Rear external connections use the section not available on board fronts.
  • System Scope: The backplane belongs to the LS2100 LCI control rack.

Control-Rack Supply Checks

  • Logic Rail: The +5 V point is verified at the backplane during startup.
  • Positive Analog: A regulated +15 V rail is measured at VPBL.
  • Negative Analog: The complementary -15 V supply is checked at the same assembly.
  • Auxiliary Rail: The backplane also exposes the +24 V electronics supply.

Energization Sequence

  • Initial Check: Power rails are measured with the control-rack boards withdrawn.
  • Board Insertion: Rack boards are reinserted only after power is removed.
  • Loaded Check: The four supply rails are measured again with every board installed.
  • Adjustment Point: The electronics supply is trimmed until the VPBL readings meet the LS2100 limits.

LS2100 Control Architecture

  • Equipment Type: LS2100 is a load-commutated-inverter static-starter control platform.
  • Rack Function: The VME cage groups the digital controller and supporting interface boards.
  • Reference Set: VPBL is listed in the LS2100 printed-wiring-board reference.
  • Board Manual: GEI-100227 is the dedicated VPBL document identifier.
Description
General Electric DS200VPBLG1A is the VME P2 backplane board used in an LS2100 load-commutated inverter control rack. It provides the rear card-cage structure for the J2 and J3 sections rather than functioning as a standalone processor or field I/O card.

Within the rack, General Electric DS200VPBLG1A links the controller and interface boards through the VME backplane arrangement. The J2 section supports the internal control-board positions, while the J3 area carries external connections that are not accommodated on the individual board fronts.

Control-electronics startup places General Electric DS200VPBLG1A at the measurement point for the +5 V, +15 V, -15 V and +24 V rails. Those values are checked before all rack boards remain inserted so the LS2100 power supply can be adjusted within its specified limits.
Alternative Names
DS200 VPBL G1A GE DS200VPBLG1A DS200VPBL-G1A VPBL G1A VME Backplane LS2100 DS200VPBLG1A General Electric DS200 VPBL G1A DS 200 VPBL G1A DS200VP8LG1A
Technical notes
General Electric DS200VPBLG1A is the LS2100 VME P2 backplane for the J2/J3 card-cage sections and control-power rails.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why should DS200VPBLG1A power rails be checked both unloaded and loaded?
DS200VPBLG1A is the backplane measurement point; comparing both conditions confirms that the electronics supply remains within range after the rack boards are installed.
Which voltages matter during General Electric DS200VPBLG1A startup?
At General Electric DS200VPBLG1A, verify the +5 V, +15 V, -15 V and +24 V control-electronics rails specified for the LS2100 rack.
What distinguishes DS200VPBLG1A from an LS2100 processor board?
DS200VPBLG1A is the P2 interconnection and power backplane; processing is performed by the plug-in boards seated in the VME cage.
Where do rear external connections enter around General Electric DS200VPBLG1A?
General Electric DS200VPBLG1A uses the J3 section for connections that are not available on the front edges of the installed boards.
What safety step applies before boards are inserted around DS200VPBLG1A?
Remove power before inserting or withdrawing cards from DS200VPBLG1A, then repeat the loaded rail checks after the rack is assembled.
Which document identifier should be matched to General Electric DS200VPBLG1A?
The board-specific reference for General Electric DS200VPBLG1A is GEI-100227, while GEH-6678 covers LS2100 installation and startup.
