          Apter Power supports HE800DQM306 sourcing, official documentation access, and installed-system matching guidance.

        HE800DQM306

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Horner HE800DQM306 is a 16-point SmartStack digital output module for compatible Horner metal controller systems.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for HE800DQM306
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for HE800DQM306

        • Manufacturer:
          HORNER
        • Part Number:
          HE800DQM306
        • Product Family:
          HORNER
        • Product Type:
          16-Point Digital Output Module
        • Stock:
          1
        • Outputs:
          16 positive-logic DC channels
        • Output range:
          10-30 VDC
        • Channel rating:
          0.5 A maximum
        • Weight:
          0.564 lbs (0.256 kg)
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Wiring Layout Protection Panel Limits Applications

        Features:

        • HE800DQM306 provides 16 sourcing DC outputs.
        • Outputs use a 10 to 30 VDC field supply.
        • One common serves all 16 output points.
        Horner HE800DQM306 is the lower-density DQM option for systems that need one coordinated bank of discrete outputs.

        The shared common suits relays, indicators, and small DC actuators that operate from the same field supply.

        This configuration is appropriate when 16 points cover the required output count; the DQM406 provides a separate higher-density alternative.

        The Horner HE800DQM306 SmartStack Digital Output Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        Horner HE800DQM306 SmartStack Digital Output Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Single Common: All 16 sourcing channels depend on one shared power common. If the common or its field supply is lost, several outputs can appear faulty even when their individual channels are intact.
        • Positive Logic: Each output supplies current to the connected load, which then returns to the field-supply reference. This current path must match positive-logic devices rather than loads intended for a sinking output stage.
        • Removable Terminal: The spring-clamp terminal block separates from the electronics module. That arrangement keeps the field conductors grouped when the module is removed for inspection or replacement.
        • Short-Circuit Response: Electronic protection is built into the transistor output circuitry to help protect a channel during a field short. The load fault still needs to be cleared before the output is returned to service.
        • Startup Current: The manual separates the 650 mA inrush allowance from the 0.5 A maximum load current. Coils, lamps, and similar loads should therefore be checked for both startup and running current.
        • Bank Diagnosis: A problem at the shared common can affect the complete 16-point group. Checking common voltage and supply continuity first can prevent several healthy outputs from being treated as separate failures.
        • Local Temperature: The 0 to 60 degrees C rating applies at the module inside the enclosure, not only to the temperature of the surrounding room. Panel heat from nearby equipment must be included in this check.
        • Moisture Control: Operation from 5 to 95 percent relative humidity is specified only for non-condensing conditions. Enclosure design should prevent moisture from forming on the terminal block or electronics.
        • Power Budget: The module draws 0.12 W in steady operation from the controller system, with negligible inrush. This small demand still belongs in the SmartStack power calculation for a populated controller.
        • Grouped DC Loads: The single-common layout fits a compact bank of relays, indicators, or actuators that share one 10 to 30 VDC field reference. It is less suitable when loads must be separated into independently powered groups.
        • Sequence Control: The documented 1 ms turn-on and turn-off response supports normal machine interlocks and sequence outputs. Precision pulse generation should be assigned to a purpose-built high-speed module instead.
        • Model Choice: HE800DQM306 covers a 16-point requirement with one common. MAN0372 identifies HE800DQM406 as the related choice when 32 outputs and two commons are required.
        Description
        The Horner HE800DQM306 adds a 16-point positive-logic output bank to a SmartStack Metal controller.

        Because one power common serves the complete bank, the module is best suited to grouped 10 to 30 VDC loads that share the same field-supply reference.

        A 1 ms switching response, electronic short-circuit protection, and a removable spring-clamp terminal block support routine machine-control outputs and practical service access.
        Alternative Names
        HE800-DQM306 HE800 DQM306 HEDQM306 HE-DQM306 Horner HE800DQM306 Horner DQM306 SmartStack DQM306 Horner HE800DQM306 16-point output module
        Technical notes
        Horner HE800DQM306 suits compact 16-point field-output expansion where one common simplifies a coordinated load group.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        How can Horner HE800DQM306 help when a compact machine runs out of discrete outputs?
        By adding 16 positive-logic points, Horner HE800DQM306 expands a compatible metal SmartStack controller without requiring a separate remote I/O station.
        What should be checked before Horner HE800DQM306 drives solenoids or interposing relays?
        Compare every connected load with the Horner HE800DQM306 10 to 30 VDC range and 0.5 A per-point limit, then verify the field supply polarity.
        How can installers reduce common-wiring mistakes on Horner HE800DQM306?
        Because Horner HE800DQM306 uses one common for its 16 outputs, label the shared return and confirm all loads belong to the same planned supply group.
        What happens if an output cable connected to Horner HE800DQM306 is shorted?
        Electronic short-circuit protection is built into Horner HE800DQM306, but the fault must still be removed and the load circuit checked before operation resumes.
        Can Horner HE800DQM306 be fitted to any Horner controller?
        No. Horner HE800DQM306 is a metal SmartStack module, so the selected host must explicitly support the metal-encased SmartStack I/O format.
        How should panel conditions be prepared for Horner HE800DQM306?
        Keep Horner HE800DQM306 within 0 to 60 degrees C and 5 to 95 percent non-condensing humidity, with enclosure ventilation suited to the surrounding equipment.
