CC-PCNT01 51405046-175

/ 4.9
1001 reviews | Need a Specific Revision?
Honeywell CC-PCNT01 51405046-175 is a C300 controller module that runs the Control Execution Environment and coordinates supported Experion I/O.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for CC-PCNT01 51405046-175
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CC-PCNT01 51405046-175

  • Manufacturer:
    Honeywell
  • Part Number:
    CC-PCNT01 51405046-175
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    C300 Controller Module
  • Stock:
    1
  • Execution Environment:
    Honeywell Control Execution Environment (CEE)
  • I/O Links:
    2
  • Supported I/O:
    Series C and supported Experion I/O families
  • Redundancy Architecture:
    Matched controller and IOTA with redundancy connection
  • Engineering Tool:
    Experion Control Builder
  • Controller Base Period:
    50 ms
  • Redundancy Support:
    Yes
  • I/O Module Period:
    50 ms
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Controller Architecture I/O and Redundancy Configuration Boundary Product Applications

Features:

  • C300 execution: Runs control strategies in the Honeywell Control Execution Environment.
  • Dual I/O links: Coordinates supported Experion I/O through two documented controller links.
  • Redundancy capable: Supports a matched controller and IOTA architecture with the required redundancy connection.
CC-PCNT01 51405046-175 is a C300 controller identity used within an engineered Experion PKS configuration.

Its operation depends on compatible firmware, IOTA, networks, I/O-link assignments, execution settings, and the Control Builder database.

Controller replacement is therefore a configuration-controlled activity, not only a physical module exchange.

Apter Power supports CC-PCNT01 51405046-175 enquiries with sourcing, documentation, controller matching, and Experion configuration guidance.
Honeywell CC-PCNT01 51405046-175 C300 Controller Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • CEE role: Executes configured control modules and strategies within Experion PKS.
  • Engineering environment: Uses Experion Control Builder for configuration and maintenance.
  • Network boundary: The documented C300 configuration uses the Fault Tolerant Ethernet control network.
  • Time sources: The documented C300 configuration supports SNTP and PTPv2 time sources; the IOTA GPS connector is not supported.
  • I/O connectivity: In 50 ms CEE, the controller can use 375 Kbaud PM I/O or Series A I/O and 750 Kbaud Series C I/O; 20 ms CEE supports only Series C I/O at 750 Kbaud.
  • Redundancy hardware: A redundant C300 arrangement uses two controllers, two IOTAs, and the Ethernet STP redundancy connection.
  • Device indexing: Honeywell assigns the primary controller an odd device index n and its redundancy partner index n+1.
  • Switchover context: Honeywell lists 500 ms processing interruption for 50 ms CEE and 200 ms for 20 ms CEE; dual I/O-link failures can extend the interruption.
  • Identity control: Retain CC-PCNT01 together with part number 51405046-175 and the installed hardware revision.
  • Configuration package: Keep the validated Control Builder database, firmware, network identity, and I/O assignments with the installed-controller record.
  • Replacement note: Honeywell documents CC-PCNT02 as the model for new installations and field replacements of CC-PCNT01.
  • 20 ms boundary: The optional 20 ms CEE requires separately loaded firmware and a license and supports only Series C I/O within Honeywell’s documented release conditions.
  • Continuous control: Executes regulatory, logic, sequence, and equipment-control strategies engineered for the C300.
  • FTE controller nodes: Operates as a C300 controller on the documented Experion control network.
  • Redundant process control: Supports a two-controller C300 arrangement with two IOTAs and the documented redundancy connection.
  • Batch and custom applications: Executes batch operations and directly hosts custom programmable applications within the documented C300 architecture.
Description
CC-PCNT01 51405046-175 is a Honeywell C300 controller module for Experion PKS. It executes control strategies in the Control Execution Environment (CEE) and communicates with supported I/O through two controller I/O links.

In an installed system, CC-PCNT01 51405046-175 is engineered through Experion Control Builder and supports the documented controller and I/O execution periods. Redundant service uses matched controller hardware, the appropriate IOTA and redundancy connection, plus a synchronized Experion configuration.

Replacement of CC-PCNT01 51405046-175 should preserve the full part number, controller and IOTA revisions, redundancy role, firmware compatibility, network identity, I/O-link assignments, CEE configuration, and backup records. CC-PCNT02 or CC-PCNT05 should not be treated as direct equivalents without Honeywell migration guidance.
Alternative Names
CC-PCNT01 51405046-175 CC PCNT01 51405046 175 CCPCNT0151405046175 Honeywell CC-PCNT01 Honeywell 51405046-175 C300 CC-PCNT01
Technical notes
CC-PCNT01 runs the C300 Control Execution Environment and connects to supported Experion I/O through two I/O links. A reliable controller replacement matches the IOTA, redundancy role, firmware level, network identity, I/O-link assignments, execution settings, Control Builder database, and validated backup before the controller is returned to service.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What should an RFQ for CC-PCNT01 51405046-175 include when the installed node belongs to a redundant C300 pair?
Include the complete module identity, controller/IOTA arrangement, CEE mode, I/O-link types, device-index relationship, and installed firmware so the request distinguishes a spare from a migration project.
Can EIM or Profit Controller functions be planned on CC-PCNT01 51405046-175?
No under Honeywell’s published extended-function boundary. Those functions require CC-PCNT02 loaded with the extended-functionality firmware image.
Why can field I/O remain unavailable after CC-PCNT01 51405046-175 returns to a healthy controller state?
Controller status and the downstream I/O path are separate diagnostic points. Review both I/O links, the configured link speed and I/O family, IOTA connections, and device assignments before attributing the condition to the controller.
Why should CC-PCNT01 51405046-175 be treated as part of the complete redundant pair during service?
The redundant architecture uses two controllers, two IOTAs, and a dedicated redundancy connection, so partner status and synchronization affect the service decision.
Can PM I/O or Series A I/O remain when CC-PCNT01 51405046-175 is changed to 20 ms CEE?
No under Honeywell’s documented 20 ms configuration. That mode supports Series C I/O at 750 Kbaud; PM I/O and Series A support belongs to the 50 ms configuration.
Can CC-PCNT01 51405046-175 use 20 ms CEE by changing only the execution-period setting?
No. Honeywell requires separately loaded firmware and a license, and the published 20 ms configuration is limited to Series C I/O and the stated system-release conditions.
