    Apter Power supplies the Honeywell MC-TDOY22 51204162-175 for maintenance and replacement in compatible legacy Process Manager I/O installations requiring dependable 24 Vdc field termination.

MC-TDOY22 51204162-175

/ 4.9
1001 reviews | Need a Specific Revision?
The Honeywell MC-TDOY22 51204162-175 is a conformally coated 24 Vdc isolated digital-output FTA with 32 channels, compression terminals, and redundancy support.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for MC-TDOY22 51204162-175
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MC-TDOY22 51204162-175

  • Manufacturer:
    Honeywell
  • Part Number:
    MC-TDOY22 51204162-175
  • Product Family:
    Honeywell Experion PKS ( C200, C300 )
  • Product Type:
    24 Vdc Isolated Digital Output Field Termination Assembly
  • Stock:
    20
  • Output Channels:
    32 isolated digital outputs
  • Nominal Load Voltage:
    24 Vdc
  • Maximum Load Current:
    500 mA per output
  • Maximum External Supply Capacity:
    5 A for 32 outputs
  • Application Configuration:
    Single or redundant
  • Terminal Type:
    Compression terminals
  • Conformal Coating:
    Yes
  • CE Compliance:
    CE-compliant version
  • Compatible IOP:
    MU-PDOY22
  • Estimated shipping dimensions:
    Module Dimensions - 4.75 × 12.0 inches (120.7 × 304.8 mm)
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Compliance Compatibility

Features:

  • 32 Isolated Outputs
  • Coated Compression FTA
  • Supported I/O Architecture
The Honeywell MC-TDOY22 51204162-175 provides 32 isolated digital outputs. Its associated IOP output drivers can operate loads requiring up to 500 mA per output at 24 Vdc.

The Honeywell MC-TDOY22 51204162-175 uses compression terminals and a conformally coated assembly. Part number 51204162-175 identifies the CE-compliant version listed in Honeywell’s installation documentation.

The Honeywell MC-TDOY22 51204162-175 is intended for the MU-PDOY22 Digital Output IOP. Honeywell documentation supports installation in single or redundant Process Manager I/O applications.

The MC-TDOY22 51204162-175 Honeywell Digital Output FTA Specifications may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell MC-TDOY22 51204162-175 Digital Output FTA Specifications Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Honeywell MC-TDOY22 51204162-175 Digital Output FTA Specifications

General

  • Manufacturer Honeywell
  • Model MC-TDOY22 51204162-175
  • Condition New Original ready stock
  • Product Family MC-TDOY22 51204162-175,MU-TDOY22 51204162-125,MC-TDOY62 51204156-175
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Discrete field-device switching in Process Manager I/O systems
  • Control of properly rated 24 Vdc relays and solenoids
  • Field or control-room digital-output termination
  • Single or redundant PM, APM, and HPM I/O installations
  • CE-compliant part-number version
  • Conformally coated MC assembly
  • Safety-ground connection required for CE applications
  • Approved cable required for the circuit current and operating voltage
  • Designed for the MU-PDOY22 Digital Output IOP
  • Supports single or redundant I/O applications
  • Provides the FTA interface for PM, APM, and HPM systems
  • Process Manager I/O can support migration to C200 or C300 architectures
Description
The Honeywell MC-TDOY22 51204162-175 is a conformally coated, CE-compliant 24 Vdc isolated Digital Output Field Termination Assembly. It provides 32 isolated outputs through compression terminals for Process Manager I/O field wiring.

The Honeywell MC-TDOY22 51204162-175 is designed for use with the MU-PDOY22 Digital Output IOP in single or redundant configurations. A separate user-provided 24 Vdc source supplies the connected output loads.
Alternative Names
MC-TDOY22 51204162-175 MC-TDOY22 51204162-175 MCTDOY22 51204162175 MC TDOY22 51204162 175 MC-TDOY22-51204162-175
Technical notes
The Honeywell MC-TDOY22 51204162-175 is a 32-output, 24 Vdc isolated Digital Output FTA with compression terminals and conformal coating. Use it only with the supported MU-PDOY22 IOP. Connect an independent external 24 Vdc supply for field loads, and install suppression diodes across inductive loads.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What should a buyer verify before ordering the MC-TDOY22 51204162-175?
Verify the complete part number, CE-compliant version, conformal coating, compression-terminal configuration, physical condition, and compatibility with the installed MU-PDOY22 IOP.
Can the MC-TDOY22 51204162-175 replace a relay-output FTA?
No. The MC-TDOY22 51204162-175 is a 32-channel 24 Vdc isolated output FTA, not a 16-channel electromechanical relay FTA. Confirm the field-load circuit before replacement.
What external power is required for the MC-TDOY22 51204162-175?
The field loads require an independent user-provided 24 Vdc supply. Honeywell states that the supply must be capable of delivering up to 5 A for all 32 outputs.
What installation precautions apply to the MC-TDOY22 51204162-175?
Use approved wiring for the circuit current and voltage, connect the grounding bus correctly, observe CE grounding requirements, and install suppression diodes across inductive loads.
