    Honeywell hardware documentation includes FS-IOBUS-HBS in the non-redundant IOCHAS-0001S assembly.

FS-IOBUS-HBS

/ 4.9
1001 reviews | Need a Specific Revision?
FS-IOBUS-HBS is a non-conformal-coated non-redundant horizontal i/o bus backplane for Honeywell Safety Manager systems.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for FS-IOBUS-HBS
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FS-IOBUS-HBS

  • Manufacturer:
    Honeywell
  • Part Number:
    FS-IOBUS-HBS
  • Product Family:
    Honeywell Safety Systems
  • Product Type:
    Non-redundant horizontal I/O bus backplane
  • Stock:
    1
  • Bus configuration:
    Non-redundant horizontal I/O bus
  • Associated chassis:
    IOCHAS-0001S
  • I/O module connectors:
    18 flat-cable connectors
  • I/O slot range:
    Slots 1–18
  • Extender connectors:
    1 flat-cable connector, slot 21
  • Extender cable:
    1 × 20-pin flat-cable assembly
  • Extender module:
    IO-0001
  • Coating:
    Non-conformal-coated FS version
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Safety & Compliance Performance & Efficiency

Product overview:

  • Horizontal I/O bus for the S chassis
  • 18 I/O module flat-cable connectors
  • One 20-pin extender cable assembly

FS-IOBUS-HBS carries non-redundant Safety Manager I/O bus signals horizontally across the IOCHAS-0001S module positions.

Connector alignment is essential because the assembly links every module slot to the single slot-21 IO-0001 extender.

Verified resources for FS-IOBUS-HBS:

Verified specifications for FS-IOBUS-HBS:

  • Bus configuration: Non-redundant horizontal I/O bus
  • Associated chassis: IOCHAS-0001S
  • I/O module connectors: 18 flat-cable connectors
  • I/O slot range: Slots 1–18
  • Extender connectors: 1 flat-cable connector, slot 21
  • Extender cable: 1 × 20-pin flat-cable assembly
  • Extender module: IO-0001
  • Coating: Non-conformal-coated FS version

Typical applications:

  • Horizontal bus distribution in IOCHAS-0001S
  • Connection of 18 non-redundant I/O modules
  • Replacement of damaged flat-cable bus assemblies

The assembly is a chassis-specific signal interconnect and is not intended for external field wiring.

Safety and compliance:

  • Single I/O bus path
  • Fixed slot-21 extender connection
  • Cable orientation must follow chassis documentation

De-energize and document every flat-cable position before service to avoid slot-to-slot connection errors.

Performance and efficiency:

  • Eighteen module links on one horizontal assembly
  • One 20-pin connection to IO-0001
  • Compact in-chassis signal routing

The bus backplane reduces individual wiring while providing a consistent communication path across all non-redundant I/O slots.

Description

FS-IOBUS-HBS is a non-conformal-coated non-redundant horizontal i/o bus backplane for the Honeywell Safety Manager platform. FS-IOBUS-HBS provides eighteen flat-cable connections for I/O modules in slots 1 through 18 and one connection for the IO-0001 extender in slot 21.

A 20-pin flat-cable assembly connects the horizontal backplane to the middle connector of the IO-0001 module. Verify the S chassis, cable orientation, slot numbering and connector condition before fitting or replacing this bus component.

Alternative Names
FS-IOBUS-HBS FS IOBUS HBS Honeywell FS-IOBUS-HBS Honeywell FS IOBUS HBS Safety Manager FS-IOBUS-HBS FS-IOBUS-HBS Non-redundant horizontal I/O bus backplane FSIOBUSHBS Non-redundant horizontal I/O bus backplane Honeywell Safety Manager FS-IOBUS-HBS
Technical notes
FS-IOBUS-HBS is the non-redundant horizontal I/O bus backplane for IOCHAS-0001S. It links 18 I/O positions to a single IO-0001 extender through a 20-pin cable assembly.
