    For TC-201-02-15M0, Apter Power supports sourcing, documentation, and system-matching review.

TC-201-02-15M0

/ 4.9
1001 reviews | Need a Specific Revision?
ICS Triplex TC-201-02-15M0 is a 15.0 m internal Trusted companion-slot cable connecting 40 analogue or digital input signals from an internal FTA to an I/O module.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for TC-201-02-15M0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for TC-201-02-15M0

  • Manufacturer:
    ICS Triplex
  • Part Number:
    TC-201-02-15M0
  • Product Family:
    Power Cables
  • Product Type:
    Trusted Internal 40-Channel Input-to-FTA Companion Slot Cable
  • Stock:
    1
  • Cable Length:
    15.0 m
  • Cable Arrangement:
    Internal companion slot
  • Signal Direction:
    Input from internal FTA to module
  • Channel Capacity:
    40 input channels
  • Chassis Connectors:
    Two 96-way type C connectors
  • FTA Connector:
    One 96-way type R connector
  • Maximum Working Voltage:
    60 V
  • Maximum Current:
    2 A per channel
  • Stripback Length:
    1.5 m at both ends
  • Protective Sheathing:
    Nylon Rilgain
  • Estimated shipping dimensions:
    15.0 m cable length
  • Tariff Code:
    8544429000
  • Country of origin:
    United States
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Termination Length & Routing Earth Connections

Features:

  • 15.0 m finished cable length identified by the 15M0 suffix
  • Internal companion-slot path for 40 analogue or digital input channels
  • Preterminated type C chassis connectors and type R FTA connector
The complete code TC-201-02-15M0 combines the TC-201 internal input-cable construction with material code 02 and the 15M0 length designation. Retaining the full suffix is necessary when the cabinet layout depends on the specified reach.

This cable carries conditioned input signals between an internal Trusted FTA and the compatible I/O module. Connector hoods and screen conductors provide defined mechanical and earthing interfaces rather than a field-cut flying-lead arrangement.

A 15 m run is at the manual's recommended I/O cable limit. Before installation, confirm tray routing, bend handling, adjacent-enclosure placement, module and FTA references, and both safety-earth and screen-earth terminations.

Quotation, official documentation, and configuration support for the ICS Triplex TC-201-02-15M0 Trusted Internal 40-Channel Input-to-FTA Companion Slot Cable are available from Apter Power.
ICS Triplex TC-201-02-15M0 Trusted Internal 40-Channel Input-to-FTA Companion Slot Cable Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ICS Triplex TC-201-02-15M0 Trusted Internal 40-Channel Input-to-FTA Companion Slot Cable Specs

General

  • Manufacturer ICS Triplex
  • Model TC-201-02-15M0
  • Condition New Original ready stock
  • Product Family Trusted I/O Companion Slot Cables
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Preterminated interfaces

  • Chassis End: A double-width hood contains two 96-way type C connectors for the I/O module interface.
  • FTA End: A single-width hood contains the 96-way type R connector for the internal FTA.
  • Breakout: The multi-core cable is stripped back 1.5 m at both ends and covered by Rilgain sheathing.
  • Earth Path: Braids and the remote screen drain provide the documented safety-earth and screen-earth connections.

15 m installation considerations

  • Cable Length: TC-201-02-15M0 is documented with cable length of 15.0 m.
  • Cable Arrangement: TC-201-02-15M0 is documented with cable arrangement of Internal companion slot.
  • Signal Direction: TC-201-02-15M0 is documented with signal direction of Input from internal FTA to module.
  • Channel Capacity: TC-201-02-15M0 is documented with channel capacity of 40 input channels.

Screen and safety earth

  • Catalog check: Retain the complete TC-201-02-15M0 order code when matching the installed trusted internal 40-channel input-to-fta companion slot cable.
  • System pairing: Confirm the approved Trusted I/O Companion Slot Cables chassis, module, cable, or backplane context before replacement.
  • Physical review: Check the documented 15.0 m cable length product dimensions together with connectors, routing, and enclosure clearance.
  • Official procedure: Use the applicable manufacturer manual for installation, energization, diagnostics, and maintenance.
Description
Within the Trusted companion-slot range, TC-201-02-15M0 denotes an internal 40-channel input cable manufactured to a 15.0 m length. The official selection guide assigns TC-201 assemblies to input modules and internal Field Termination Assemblies, with the length stated to the nearest 0.5 m in the final ordering suffix.

The chassis side of TC-201-02-15M0 carries two 96-way type C connectors inside a double-width hood. A single-width hood at the opposite end contains the 96-way type R connector used at the FTA, so the assembly provides the complete preterminated path rather than a flying-lead termination.

Both ends of TC-201-02-15M0 are stripped back 1.5 m and protected with nylon Rilgain sheathing. The screen and earth provisions should be installed exactly as shown in the cable manual, and the module/FTA combination must be checked against the official compatibility figure before the 15 m run is commissioned.
Alternative Names
TC201-02-15M0 TC 201 02 15M0 TC2010215M0 ICS Triplex TC-201-02-15M0 Rockwell TC-201-02-15M0 Trusted TC-201-02-15M0 TC-201-02-15M0 cable TC-201 internal input cable
Technical notes
TC-201-02-15M0 is a 15.0 m internal Trusted 40-channel input-to-FTA companion-slot cable. Confirm module, FTA, screening, and route before fitting.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How long is TC-201-02-15M0?
TC-201-02-15M0 is 15.0 m long; the 15M0 suffix follows Rockwell's documented xMx length notation.
What installation arrangement is intended for TC-201-02-15M0?
TC-201-02-15M0 is intended for an internal companion-slot connection from an internal FTA to a Trusted analogue or digital input module.
Does TC-201-02-15M0 use flying leads?
No. TC-201-02-15M0 is preterminated with two type C connectors at the chassis end and one type R connector at the FTA end.
What is the recommended maximum I/O cable length relevant to TC-201-02-15M0?
The official cable overview recommends a maximum of 15 m, which is the specified length of TC-201-02-15M0; longer runs require additional engineering consideration.
How should the screen of TC-201-02-15M0 be earthed?
TC-201-02-15M0 provides sheathed braids for connector-hood safety earth and a remote green screen-drain conductor for screen earth.
Which electrical rating applies to TC-201-02-15M0?
TC-201-02-15M0 belongs to the TC-201-02 family certified for 60 V maximum working voltage and 2 A maximum current per channel.
What information helps Apter Power review a TC-201-02-15M0 enquiry?
For TC-201-02-15M0, provide the I/O module, FTA, chassis arrangement, route, quantity, destination, and required official documentation.
