TC-011-02-4M5

/ 4.9
1001 reviews | Need a Specific Revision?
The ICS TRIPLEX TC-011-02-4M5 Fan Power Cable is a 4.5-meter cable designed to deliver reliable power to rack cooling fan assemblies within the Rockwell Automation Trusted Triple Modular Redundant (TMR) safety-instrumented system.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for TC-011-02-4M5
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for TC-011-02-4M5

  • Manufacturer:
    ICS Triplex
  • Part Number:
    TC-011-02-4M5
  • Product Family:
    Power Cables
  • Product Type:
    Fan Power Cable
  • Stock:
    1
  • Length:
    4.5 m
  • Rated Voltage:
    24 VDC
  • Cable Material:
    LSZH (Low Smoke Zero Halogen)
  • Flame Retardancy Standard:
    IEC 60332-3 Category A
  • Connector Type:
    Pre-assembled with dedicated connectors
  • Application:
    Rack fan power supply
  • Connection Path:
    MCB (T8292) to Fan Assembly (T8270)
  • Weight:
    0.45 kg
  • Estimated shipping dimensions:
    25 cm × 25 cm × 8 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Diagnostics & Protection Operating Environment

Features:

  • Connection Between the Power Distribution Unit MCB (T8292) and the Fan Assembly (T8270)
  • Integrates 24V DC Power Delivery with LSZH Flame-Retardant Cable Construction
  • Functions Together with the Trusted TMR System Rack and Standard Trusted Modules
The ICS TRIPLEX TC-011-02-4M5 Fan Power Cable serves as the dedicated fan power interconnect within a Trusted TMR system rack, providing reliable 24V DC power transmission from the power distribution unit to the cooling fan assembly. It continuously maintains a stable electrical pathway between the MCB (T8292) and the fan module (T8270), ensuring consistent thermal management to support steady-state operation of all monitors and modules within the enclosure. Reliable power continuity is standard with the TC-011-02-4M5, and its LSZH (Low Smoke Zero Halogen) construction ensures safe operation by minimizing toxic smoke and corrosive gas emissions in the event of exposure to high temperatures. The TC-011-02-4M5 incorporates improvements in fire safety and environmental compliance over conventional cable designs, featuring IEC 60332-3 Cat A flame retardancy certification within the Trusted system architecture.

The TC-011-02-4M5 provides essential power distribution functions specific to rack cooling, and is a critical component of the thermal management path, directly affecting the proper, normal operation of the overall Trusted monitor system. One TC-011-02-4M5 cable is required per fan assembly connection, with cable length selected according to the physical routing distance within the rack. The TC-011-02-4M5 occupies a dedicated interconnection role and is always routed between the power distribution MCB and the T8270 fan assembly position.

For varying rack layout requirements, the Trusted System offers alternative length options within the same cable series. In addition to the standard 4.5-meter TC-011-02-4M5, shorter and longer variants are available to accommodate different cabinet dimensions and routing configurations. The Trusted cable series executes length selection using the standardized part numbering system specified in the product options. Using this method, the system designer can select the appropriate cable based on installation distance, with the TC-011-02-4M5 specifically designated for medium-span connections approximately 4.5 meters in length.

The TC-011-02-4M5 ICS TRIPLEX Fan Power Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ICS TRIPLEX TC-011-02-4M5 Fan Power Cable Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ICS TRIPLEX TC-011-02-4M5 Fan Power Cable Specs

General

  • Manufacturer ICS TRIPLEX
  • Model TC-011-02-4M5
  • Condition New Original ready stock
  • Product Family TC-011-02-1M5,TC-011-02-6M0,TC-011-03-1M5
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • System Rack Cooling: Connects system enclosure cooling fans to sustain mandatory thermal management inside active Trusted chassis racks.
  • Oil & Gas Processing: Used in control cabinets managing critical Emergency Shutdown (ESD) and fire and gas systems.
  • Power Generation Facilities: Powers rack fans cooling high-density control loops and turbine safety systems.
  • Chemical & Petrochemical Refineries: Ensures heat dispersion in volatile production settings where safety-instrumented infrastructure must run 24/7.
  • Overcurrent & Short-Circuit Defense: Integrates directly with the system's PDU MCB to isolate local wiring faults or fan motor lockups instantly.
  • Cross-Sectional Integrity: Engineered with heavy-gauge internal wire cross-sectional areas to eliminate power loss or localized overheating over its 4.5-meter run.
  • System-Level Thermal Supervisions: Enables uninterrupted fan operation, allowing system modules to monitor chassis airflow and register high-temperature diagnostics before hardware degradation occurs.
  • LSZH Sheathing: Built using Low Smoke Zero Halogen compounds, preventing toxic gas emissions and maximizing visibility during an external control room fire.
  • Flame Retardancy: Fully rated and tested to the IEC 60332-3 Category A standard for flame propagation resistance.
  • Harsh Industrial Conditions: Shielded jacket provides high tolerance against physical wear, chemical corrosion, and ambient thermal stresses inside enclosed plant cabinets.
Description
The ICS TRIPLEX TC-011-02-4M5 Fan Power Cable is a pre-assembled, LSZH (Low Smoke Zero Halogen) rated interconnect cable specifically engineered for Trusted TMR system rack fan power distribution. As a critical component within the Trusted TC000 power cable family, the TC-011-02-4M5 provides a reliable 24V DC power pathway between the power distribution unit MCB (T8292) and the fan assembly module (T8270), ensuring continuous cooling operation for industrial control enclosures.

This TC-011-02-4M5 fan power cable is designed to address the challenge of maintaining stable and safe electrical connectivity in harsh industrial environments where fire safety and low-toxicity emissions are paramount. By utilizing LSZH materials that comply with IEC 60332-3 Cat A flame retardancy standards, the TC-011-02-4M5 mitigates risks associated with smoke and corrosive gas release during potential fire events, thereby protecting both personnel and sensitive control equipment. The cable's 4.5-meter length offers flexible routing options within standard industrial racks while maintaining signal integrity and power delivery consistency for 24V DC fan operations.

The TC-011-02-4M5 finds its primary application in safety-critical industries such as oil and gas, petrochemical processing, and power generation, where it supports Safety Instrumented Systems (SIS) built on the ICS TRIPLEX Trusted TMR platform. In these demanding environments, the TC-011-02-4M5 serves as an essential infrastructure element that sustains proper thermal management within control system cabinets, directly contributing to the overall system availability and long-term operational reliability required by process automation standards.

For installation and integration, the TC-011-02-4M5 arrives fully assembled with dedicated connectors at both ends, enabling straightforward deployment within Trusted TMR rack configurations. Installers should follow manufacturer guidelines to ensure proper connection between the MCB power distribution unit and the T8270 fan assembly, verifying secure mating to prevent intermittent power loss. The TC-011-02-4M5 is designed for direct integration into existing Trusted system architectures without requiring additional termination work, simplifying field installation and reducing commissioning time.
Alternative Names
TC-O11-O2-4M5 TC-0II-02-4M5 TC-011-02-1M5 TC-011-02-6M0 TC-011-03-1M5 TC-011-03-4M5 TC-011-03-6M0
Technical notes
The TC-011-02-4M5 power cable plays a critical role in maintaining optimal thermal management inside high-density control cabinets, thereby protecting expensive supervisory system hardware from catastrophic overheating.
