ICS Triplex T8461C is a Trusted TMR 24/48 VDC digital output module with 40 monitored output channels.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for T8461C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for T8461C

  • Manufacturer:
    ICS Triplex
  • Part Number:
    T8461C
  • Product Family:
    Trusted Triple Modular Redundant
  • Product Type:
    Trusted TMR 24/48 VDC Digital Output Module
  • Stock:
    3
  • Output Channels:
    40
  • Channel Groups:
    5 groups of 8
  • Field Supply:
    18 to 58 VDC
  • Backplane Supply:
    20 to 32 VDC
  • Maximum Continuous Current:
    0.75 A per channel
  • Backplane Power:
    26 W
  • Field Power Dissipation:
    36 W
  • Short-Circuit Protection:
    Electronic latching protection
  • SOE Resolution:
    1 ms
  • Operating Temperature:
    0 to 60 °C
  • Product Dimensions:
    266 × 31 × 303 mm
  • Product Weight:
    1.3 kg
  • Weight:
    2.7 lbs (1.3 kg)
  • Estimated shipping dimensions:
    3x30.3x26.5cm
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    Mexico
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Diagnostics & Protection Operating Environment Firmware & Updates

Features:

  • 40 monitored TMR digital output channels.
  • Electronic latching overcurrent protection per channel.
  • Automatic line monitoring with 1 ms event reporting.
T8461C is the Trusted TMR 24/48 VDC digital output module configuration for safety-related field actuation.

Its triplicated architecture supervises output and wiring conditions while maintaining fault-tolerant control of connected loads.

Before replacement, verify field voltage, Trusted termination hardware, processor compatibility, firmware, and the approvals required for the installation.

Availability is subject to Apter Power stock, firmware, and hardware-revision confirmation.
ICS Triplex T8461C manuals and reference links: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ICS Triplex T8461C Trusted TMR Digital Output Module

General

  • Manufacturer ICS Triplex
  • Model T8461C
  • Condition New and factory sealed
  • Product Family Trusted Triple Modular Redundant
  • Automatic line monitoring detects field-circuit conditions on the output channels.
  • Electronic latching overcurrent protection isolates a shorted or overloaded channel.
  • Sequence-of-events reporting provides 1 ms resolution for output-state analysis.
  • The documented operating-temperature range is 0 to 60 °C.
  • Storage temperature is −25 to 70 °C with 10% to 95% non-condensing humidity.
  • Confirm the applicable Trusted system safety and environmental approvals for the site.
  • Rockwell Automation currently lists Trusted T8461 firmware vS47 for this product family.
  • Review the applicable firmware release notes before changing an installed module revision.
  • Verify processor release, system configuration, and maintenance procedure before applying an update.
Description
ICS Triplex T8461C is a Trusted Triple Modular Redundant 24/48 VDC digital output module with 40 output channels arranged in five groups of eight.

Each channel provides automatic diagnostics, line monitoring, electronic overcurrent protection, and 1 ms sequence-of-events resolution for safety-related control outputs.

Confirm the TMR processor release, field supply, companion Trusted termination hardware, firmware, and hazardous-location requirements before replacement or commissioning.
Alternative Names
T8461C ICS Triplex T8461C Trusted T8461C T8461 C
Technical notes
T8461C provides 40 monitored TMR digital outputs with electronic overcurrent protection and 1 ms SOE resolution.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How are the 40 T8461C outputs organized?
They are arranged as five isolated groups of eight channels.
What field-supply range does T8461C accept?
The documented field-supply range is 18 to 58 VDC.
How is an output short circuit handled?
Electronic latching overcurrent protection isolates the affected channel and reports the fault.
Can T8461C monitor connected field wiring?
Yes. Automatic line monitoring is part of the module diagnostics.
What sequence-of-events resolution is available?
The module records output events with 1 ms resolution.
Which checks are required before installing a replacement?
Verify field voltage, termination hardware, processor compatibility, firmware, and the supplied-unit country-of-origin label.
