FBM215

/ 4.9
1001 reviews | Need a Specific Revision?
Foxboro FBM215 is an eight-channel isolated analog output module supporting mixed standard 4-20 mA and HART field devices in Foxboro DCS systems.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for FBM215
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FBM215

  • Manufacturer:
    Invensys
  • Part Number:
    FBM215
  • Product Family:
    Foxboro
  • Product Type:
    Eight-Channel Isolated HART Analog Output Module
  • Stock:
    1
  • Analog output channels:
    8, independent and isolated
  • Channel mix:
    Any mix of standard 4-20 mA and HART devices
  • Output accuracy:
    ±0.05% of span from 4 to 20 mA
  • Output load:
    750 Ω maximum
  • Output resolution:
    13 bits
  • Maximum rate of change:
    20 mA in 60 ms
  • Isolation test:
    600 VAC for one minute
  • Power consumption:
    7 W maximum
  • Heat dissipation:
    5 W maximum
  • Module Fieldbus:
    Redundant 2 Mbps
  • Input power:
    24 VDC +5%, -10%
  • Operating temperature:
    -20 to +70°C
  • Storage temperature:
    -40 to +70°C
  • Relative humidity:
    5 to 95%, noncondensing
  • Contamination class:
    ISA-S71.04 Class G3
  • Dimensions:
    4.5 × 10.2 × 10.4 cm
  • HART protocol:
    Versions 5, 6 and 7
  • HART communications:
    Point-to-point master/slave, asynchronous half-duplex, 1200 baud
  • HART message rate:
    2 messages per second; burst mode not supported
  • Operating altitude:
    -300 to +3,000 m
  • Storage altitude:
    -300 to +12,000 m
  • Vibration:
    0.75 g from 5 to 500 Hz
  • Weight:
    0.284 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Output & Load HART Communications Commissioning Application
  • Confirm the installed FBM215 output mode, HART assignments and channel configuration before replacement
  • Confirm the exact module identity, termination hardware and cable before replacement
  • Preserve field wiring, channel configuration, diagnostics and control state before removal

Foxboro FBM215 is an eight-channel isolated analog output module supporting mixed standard 4-20 mA and HART field devices in Foxboro DCS systems.

FBM215 is the functional designation; RH922VU is the current electronic-module part number. Termination hardware is separate and must match the installed project design.

Before replacement, verify the exact label, termination hardware, cable, signal limits, field wiring, saved configuration and supported system environment.

Availability, condition, price, and shipping time for FBM215 are confirmed during quotation.

Foxboro FBM215 Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Assign each channel as standard 4-20 mA or HART service
  • Keep total field-loop burden within the 750 ohm maximum
  • Verify actuator direction and safe output behavior before enabling control
  • Use supported HART revision 5, 6 or 7 field devices
  • Design the loop for 1200-baud point-to-point communications
  • Do not configure HART burst mode because FBM215 does not support it
  • Command traceable current points across every used output
  • Confirm Field Device Expert discovers each configured HART device
  • Verify engineering units, diagnostics, alarms and final control action
  • Standard analog output control
  • HART-capable actuator and positioner control
  • HART device configuration and diagnostics through Field Device Expert
Description
Foxboro FBM215 is an eight-channel isolated analog output module supporting mixed standard 4-20 mA and HART field devices in Foxboro DCS systems.

Its documented channel architecture, signal limits and diagnostics support model-specific Foxboro DCS field I/O service without changing the official identity of FBM215.

Before installation, verify the complete nameplate, order-number relationship, termination hardware, cable, field power, saved configuration, grounding and system compatibility.
Alternative Names
FBM215 FBM 215 Foxboro FBM215 Invensys FBM215 Invensys Foxboro FBM215 I/A Series FBM215 Foxboro FBM 215
Technical notes
FBM215 is the functional designation; RH922VU is the current electronic-module part number. Termination hardware is separate and must match the installed project design. Verify the project-specified termination assembly, cable and per-channel HART loop design.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can FBM215 mix conventional and HART outputs?
Yes. The eight isolated channels may be used in any mix of standard 4-20 mA and supported HART field devices.
Which HART protocol versions does FBM215 support?
The current official specification lists HART versions 5, 6 and 7.
Does FBM215 support HART burst mode?
No. It uses point-to-point master/slave communications at 1200 baud and up to two messages per second; burst mode is not supported.
What load can each FBM215 output drive?
The official maximum output load is 750 ohms; the complete loop burden must include field wiring and the receiving device.
Why might analog output work while HART fails on FBM215?
Check loop impedance, cable capacitance, shielding, grounding, device address, HART revision and communications configuration while confirming the analog current remains valid.
What should be recorded before replacing FBM215?
Record the full label, slot, termination and cable, every channel mode and scale, HART device identity, output state, alarms and diagnostics.
How should FBM215 be commissioned?
Command traceable current points on every used channel, verify load and control direction, then confirm HART device discovery, variables and diagnostics where configured.
