Triconex 3720 is a 64-point isolated 0–5 VDC TMR analog input module with a 10 ms update rate and programmable 12- or 14-bit resolution.
In Stock
Ships by Wednesday, September 30
Fast Shipping Available
Get a quick price for 3720
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3720

  • Manufacturer:
    Invensys
  • Part Number:
    3720
  • Product Family:
    Triconex
  • Product Type:
    Isolated TMR Analog Input Module
  • Stock:
    1
  • Voltage range:
    0–5 VDC, +6%
  • Architecture:
    TMR analog input
  • Input points:
    64 single-ended
  • Isolation:
    Isolated
  • Input update rate:
    10 ms
  • Resolution:
    12 or 14 bits programmable
  • Accuracy:
    <0.15% FSR, 0°C to 60°C
  • Input resistance:
    10 MΩ minimum
  • Power-off resistance:
    140 kΩ typical
  • Leg-to-leg isolation:
    420 kΩ typical
  • Input overrange protection:
    150 VDC / 115 VAC continuous
  • Current range:
    0–20 mA, +6% overrange, 250 Ω shunt
  • Indicators:
    Pass, Fault, Active, Field
  • Color code:
    Yellow
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Performance Configuration & Programming Temperature Range

Features:

  • Handles sixty-four isolated, single-ended 0–5 VDC analog input points.
  • Refreshes the input image at a documented 10 ms rate.
  • Supports software-selectable 12-bit or 14-bit conversion.
This ordering code identifies the high-density isolated 0–5 VDC analog-input module with sixty-four single-ended points.

Its fast acquisition and selectable conversion depth suit large groups of process measurements that feed TMR logic.

Commissioning should confirm scaling, resolution, shunt resistors, ETP assignment and the isolation strategy recorded in the project.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Triconex 3720:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Aggregates dense banks of 0–5 VDC instrumentation in high-availability control cabinets.
  • Reads 0–20 mA transmitter loops through the specified 250-ohm input shunt.
  • Supports fast-changing process measurements where a 10 ms input refresh is required.
  • All sixty-four single-ended inputs are updated on the documented 10 ms acquisition cycle.
  • Programmable 12-bit or 14-bit conversion lets the project select the required measurement detail.
  • The isolated channel arrangement consolidates a large input count without sharing the non-isolated 3701 architecture.
  • Resolution is selected in the engineering configuration and must match the active application database.
  • Current-loop service uses the documented 250-ohm shunt to convert 0–20 mA into the voltage input.
  • Configured channel assignments must correspond to the external termination panel and interface cable.
  • Measurement accuracy is specified below 0.15% of full scale from 0°C to 60°C.
  • Temperature limits apply to the complete installed module and termination arrangement during operation.
  • Cabinet thermal conditions should be confirmed before the module is used at the edge of its stated range.
Description
Triconex 3720 provides sixty-four isolated, single-ended analog inputs for 0–5 VDC measurements in a TMR controller. Its triplicated acquisition structure carries each field value to the main processors while maintaining channel isolation at the module interface. The module therefore combines a large measurement population with the independent signal boundaries required by installations that separate field circuits at the input interface.

The high point count suits installations that must bring a large set of analog process variables into one chassis position. Selectable conversion resolution lets the engineering configuration balance measurement detail with the required response behavior. This makes the hardware appropriate for process areas where measurement separation and efficient use of chassis capacity are both important engineering considerations.

External termination hardware completes the path from field wiring to the backplane. Planning a replacement requires the existing resolution selection, current-conversion shunts and channel reference scheme to be preserved with the correct interface cable. Those selections should be recorded before maintenance so the replacement reproduces the intended conversion behavior, wiring separation and connection path without introducing hidden differences.
Alternative Names
3720 Triconex 3720 3720 Isolated TMR Analog Input Module Triconex 3720 Isolated TMR Analog Input Module 3720 Tricon v9–v11 Analog Input Modules Triconex 3720 Tricon v9–v11 Analog Input Modules Triconex 3720 Tricon v9–v11 Analog Input Modules Isolated TMR Analog Input Module
Technical notes
3720 resolution is programmable; preserve the 12/14-bit setting and verify the isolated single-ended termination path before moving channel data.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What hardware feature confirms the exact 3720 part?
The decisive values are sixty-four isolated inputs, 0–5 VDC range, 10 ms update and selectable 12/14-bit conversion.
Which companion equipment belongs with 3720?
It needs the matching Tricon chassis slot, ETP, interface cable and the project’s recorded resolution setting.
How does 3720 support the intended control function?
Use it for high-density analog acquisition where isolated single-ended points and rapid scanning are required.
Who can check stock and lead time for 3720?
A current quote is prepared after the complete label, condition, quantity and delivery target are checked.
Which engineering comparison should precede a 3720 swap?
Carry over channel scaling, 250-ohm shunts, resolution, termination assignment and field shield practice.
What should be supplied with a request for 3720 manuals and pricing?
Share the ETP and cable numbers, system version, resolution setting, channel schedule and shipping destination.
