          Apter Power offers exact-cable quotations, technical documentation, sourcing support, and guidance on the matching extender-kit layout.

        4000212-002

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Invensys Triconex 4000212-002 is a 2-ft Tri-GP I/O bus cable used with extender modules to link controller I/O columns.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for 4000212-002
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 4000212-002

        • Manufacturer:
          Invensys
        • Part Number:
          4000212-002
        • Product Family:
          Triconex
        • Product Type:
          2-ft I/O Bus Cable
        • Stock:
          1
        • Cable role:
          I/O bus connection between Tri-GP I/O columns
        • Manufacturer-listed length:
          2 ft
        • System channel arrangement:
          One cable per I/O bus channel; three channels per full link
        • 2281 kit quantity:
          Three 4000212-002 cables per complete kit
        • Weight:
          0.14 kg
        • Estimated shipping dimensions:
          3 x 63 x 1.5 cm
        • Tariff Code:
          Please confirm the destination before shipping
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Bus Architecture Kit Boundary Cabinet Layout Product Applications

        Features:

        • Inter-column role: carries I/O-bus communication between Tri-GP I/O columns through extender modules.
        • Channel separation: each of the three bus channels follows a distinct cable path.
        • Spare-part identity: the cable has its own orderable part number within the 2281 extender kit.
        The cable belongs in the Tri-GP extension path between I/O columns, while baseplate interconnect assemblies join modules within one column.

        Keeping the three bus channels on separate leads preserves the system architecture when a cabinet is expanded or restored.

        For an exact spare order, the installed cable length and the presence of extender modules determine whether a cable-only replacement is appropriate.

        Apter Power supports Invensys Triconex 4000212-002 2-ft I/O Bus Cable sourcing with quotations, technical documentation and configuration review.
        Invensys Triconex 4000212-002 2-ft I/O Bus Cable Manuals,Datasheets,Link
        Important Notice: These Apter resources support cable identification and a quotation for the installed Tri-GP system.
        • Controller path: the Tri-GP I/O bus links main processors to I/O modules through the baseplate arrangement.
        • Column extension: bus cables link extender modules when an installation spans more than one I/O column.
        • Channel separation: a full TMR extension uses a distinct cable for each of the A, B and C bus channels.
        • Individual part: 4000212-002 names the 2-ft cable, rather than a powered extender assembly.
        • 2281 kit: the listed kit includes two 3000678-100 extender modules and three of these cables.
        • Other hardware: the kit separately lists an I/O interconnect assembly and top/bottom I/O end caps.
        • Between columns: extender modules and bus cables connect the end of one I/O column to the next.
        • Within a column: an I/O interconnect assembly, rather than this cable, joins neighboring baseplates.
        • Panel planning: the 2-ft listed cable length should suit the installed spacing between the paired extender positions.
        • Multi-column Tri-GP panel: an extender pair and three cable paths link separate I/O columns.
        • Exact spare replacement: one damaged 2-ft bus cable can be sourced by its own part number without ordering a complete 2281 kit.
        • Extender-kit planning: a three-channel connection can be checked against the 2281 bill of materials before a cabinet expansion or restoration.
        Description
        In a Tri-GP controller with more than one I/O column, 4000212-002 is the 2-ft I/O bus cable identified in Invensys' extender-kit parts list. It is a cable component, not the complete 2281 extender kit or the separate 3000678-100 extender module.

        The triplicated I/O bus uses one cable for each of its three channels when it crosses between columns. A full 2281 kit contains three 4000212-002 cables alongside two extender modules and other interconnect hardware, so an exact-model spare order should distinguish the required cable quantity from the complete kit.
        Alternative Names
        Triconex 4000212-002 Invensys 4000212-002 Invensys Triconex 4000212-002 Tri-GP 4000212-002 4000212 002 4000212002 4000212/002 4000212-002 I/O bus cable
        Technical notes
        Invensys bases I/O-bus termination on the whole installed route, not on the length of 4000212-002 alone. Baseplates, extender modules and all extension cables contribute to that route. In a multi-column cabinet, this prevents a short replacement lead from masking a longer system-level termination requirement.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        If one channel remains unavailable after replacing 4000212-002, should the other two cable paths be ignored?
        No. The Tri-GP inter-column link uses three separate bus channels, so the remaining channel paths and their extender connections still matter. Apter Power can help match the installed cable set to the cabinet record.
        After adding an I/O column with 4000212-002, can a connected bus cable replace that column’s logic-power wiring?
        No. Each Tri-GP I/O column has a separate logic-power connection. A present bus link therefore does not by itself establish that the new column has the power it needs.
        Where can a maintenance team look when I/O communication remains abnormal after fitting 4000212-002?
        Tri-GP makes internal diagnostic and alarm data available to the application and operator, including through a TriStation workstation. That record can guide the next investigation without assuming the new cable is the only possible cause.
        Can 4000212-002 alone establish that a planned multi-column route remains within the Tri-GP bus limit?
        No. The documented 650-ft maximum applies to the entire I/O-bus path, including baseplates, extender modules and all extension cables. A route calculation is therefore a system-level planning step, not a rating of this single 2-ft spare.
