8403X-1

/ 4.9
1001 reviews | Need a Specific Revision?
Triconex 8403X-1 is the Tricon CX I/O address plug kit for baseplate column 1, cross-referenced to Schneider part 3001113-001.
In Stock
Ships by Sunday, October 18
Fast Shipping Available
Get a quick price for 8403X-1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 8403X-1

  • Manufacturer:
    Invensys
  • Part Number:
    8403X-1
  • Product Family:
    Triconex
  • Product Type:
    I/O Baseplate Address Plug Kit
  • Stock:
    1
  • Accessory type:
    Address Plug Kit
  • Column assignment:
    1
  • Schneider Electric part number:
    3001113-001
  • Compatible assembly:
    I/O Module Baseplate
  • Installation location:
    I/O Module Baseplate address-plug position
  • Configuration role:
    Identifies column 1 for the I/O Module Baseplate
  • Electrical I/O function:
    None
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Configuration Compatibility Integration

Features:

  • Assigns the documented column 1 identity to a Tricon CX I/O module baseplate.
  • Cross-references to Schneider Electric part number 3001113-001.
  • Provides a passive addressing function without processing field I/O.
The ordered kit is the -1 address variant and therefore belongs to column 1 rather than another numbered baseplate position.

It aligns the physical I/O column with the chassis addressing scheme used by the controller configuration.

Before fitting, compare the baseplate label, column number, existing plug and engineering drawing.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Triconex 8403X-1:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Establishes column identity during I/O module baseplate assembly or replacement.
  • Restores the correct address component after service on the column 1 baseplate hardware.
  • Supports unambiguous mapping between a physical I/O location and the configured chassis structure.
  • The plug assigns the documented column 1 identity within the Tricon CX baseplate arrangement.
  • Schneider part 3001113-001 is the published cross-reference for this address-plug kit.
  • The component supplies hardware identification only and does not process field or backplane signals.
  • The kit must match the target Tricon CX I/O baseplate and its column-numbering scheme.
  • Address plugs for other columns are not interchangeable even when their mechanical appearance is similar.
  • Selection should be verified from the chassis layout and the installed baseplate position.
  • The physical column designation must correspond to the logical I/O location used in the controller project.
  • Installation should be completed before the associated baseplate position is commissioned.
  • A post-installation check should confirm that hardware identity and engineering configuration report the same column.
Description
Triconex 8403X-1 is the address plug kit designated for column 1 of a Tricon CX I/O module baseplate. The documented Schneider cross-reference for this hardware identity component is 3001113-001. The component provides a simple but essential positional identity at the hardware level, helping the assembled I/O structure correspond to the controller's planned column map.

The plug establishes the physical column designation used by the chassis addressing arrangement. It contributes no I/O processing of its own, but it allows the installed baseplate position to correspond with the configured system layout. During chassis assembly or maintenance, the designated plug distinguishes column 1 from locations assigned other address identities and supports orderly module placement.

Because each column uses a specific numbered plug, the target location must be established before installation. Correct identification prevents a mismatch between the actual module position and the address expected by the controller configuration. A positionally incorrect plug can create an addressing conflict even though the baseplate and module appear mechanically compatible, so the column marking requires positive verification.
Alternative Names
8403X-1 8403X1 8403X 1 Triconex 8403X-1 Triconex 8403X1 8403X-1 I/O Baseplate Address Plug Kit Triconex 8403X-1 I/O Baseplate Address Plug Kit
Technical notes
8403X-1 is only for I/O baseplate column 1; verify the physical column and part 3001113-001 before fitting the plug.
