Triconex 8310 is a 175 W power module for Tricon chassis, converting 120 VAC/DC input into regulated 6.5 VDC logic power with onboard diagnostics.
In Stock
Ships by Sunday, October 18
Get a quick price for 8310
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 8310

  • Manufacturer:
    Invensys
  • Part Number:
    8310
  • Product Family:
    Triconex
  • Product Type:
    High-Density Power Module
  • Stock:
    1
  • Nominal input:
    120 VAC/VDC
  • AC input range:
    85 to 140 VAC, 47 to 63 Hz
  • DC input range:
    95 to 180 VDC
  • Fuse:
    5 A time-delay
  • Minimum input power:
    240 W
  • Rated output power:
    175 W at 60 °C
  • Output voltage:
    6.5 VDC ±1%
  • Maximum output current:
    27 A at 60 °C
  • Output hold time:
    20 ms minimum
  • Input-output isolation:
    >1000 VAC or 1500 VDC
  • Input conductors:
    Three 12 AWG wires
  • Alarm contacts:
    NO / NC / common
  • Alarm-contact rating:
    120 VAC at 1 A
  • Overtemperature threshold:
    Internal temperature above 83 °C
  • Indicators:
    PASS / FAULT / ALARM / TEMP / BAT LOW
  • Supported chassis:
    Main / Expansion / RXM
  • Redundant installation:
    Supported
  • Operating temperature:
    0 to 60 °C
  • Storage temperature:
    -40 to 85 °C
  • Relative humidity:
    5 to 95%, non-condensing
  • Installation environment:
    Industrial control enclosure
  • Weight:
    7.2 lbs (3.3 kg)
  • Estimated shipping dimensions:
    6.1 × 41 × 17.7 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Performance Efficiency Diagnostics

Features:

  • Accepts 120 VAC or DC-class input power for a Tricon chassis.
  • Delivers 175 W of regulated 6.5 VDC logic power at 60 °C.
  • Supports redundant power-module installation with onboard health indicators.
The model is the 8310 high-density supply for 120 VAC/VDC installations rather than the 24 or 230 volt variants.

It feeds the chassis logic bus and reports internal thermal, alarm and battery-related conditions.

Input range, fuse type, conductor size, earth connection and worst-case rack wattage must be validated before energization.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Triconex 8310:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Powers Tricon main chassis carrying processors, communication modules and I/O.
  • Provides a redundant logic-power source in expansion or RXM chassis assemblies.
  • Replaces an installed 8310 when the incoming 120 V supply and total rack load remain unchanged.
  • The module provides 175 W output at 60 °C with a 27 A maximum output-current rating.
  • Regulated output is 6.5 VDC within ±1% across the stated operating conditions.
  • Minimum input power available to each supply must be 240 W.
  • Dual installation shares the operational power demand while maintaining redundancy.
  • A twenty-millisecond minimum hold time supports the logic bus through brief input interruptions.
  • Power-budget calculations should use the published consumption of every populated module.
  • PASS and FAULT indicators display the internal supply health state.
  • ALARM and TEMP indicators warn of chassis or excessive-temperature conditions.
  • The BAT LOW indication reports the monitored backup-battery condition.
Description
Triconex 8310 converts an 85–140 VAC or 95–180 VDC source into regulated logic power for a Tricon chassis. The module is rated for 175 W output at the manual's 60 °C design condition. The high-density supply accepts the documented 120 VAC or DC input ranges and produces regulated 6.5 VDC logic power for supported Tricon chassis.

Two power modules can be installed for redundant operation, allowing the controller load to remain supported if one source path is lost. Front indicators report pass, fault, alarm, temperature and low-battery conditions. A 175 W output rating at the upper operating temperature, together with hold-up energy and redundant installation, supports continuous controller operation.

Calculate the complete rack demand under the single-supply worst case and confirm the five-amp time-delay fuse, input wiring and protective earth. Model 8310 voltage limits must not be confused with the 24 VDC 8311 or 230 VAC 8312 versions. Alarm contacts and PASS, FAULT, ALARM, TEMP and BAT LOW indicators provide distinct maintenance signals for source, thermal and backup-power conditions.
Alternative Names
8310 Triconex 8310 Tricon 8310 Schneider Electric Triconex 8310 8310 Power Module 8310 120 VAC/DC Power Module 8310 Tricon Power Supply 8310 High-Density Power Module
Technical notes
8310 selection requires a full single-module chassis load calculation at 60 °C and verification of the 120 VAC/VDC input and five-amp time-delay protection.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which signal or interface value should be checked first for 8310?
The 8310 front label and 120 VAC/VDC input ranges separate it from 8311 and 8312 power modules.
How is 8310 matched to the installed rack or termination path?
Confirm the Tricon chassis, redundant supply arrangement, input source, fuse and complete module power budget.
What field application makes practical use of 8310?
It provides regulated logic power for processors, communications and I/O throughout the supported chassis types.
How is an available-condition offer for 8310 established?
Apter Power can confirm the exact module, condition, available quantity and planned shipping time.
Which engineering comparison reduces replacement risk for 8310?
Verify isolation, line/neutral/earth wiring, single-supply capacity and all health indicators after replacement.
What documentation is useful when requesting pricing for 8310?
Send the module label, chassis population, input voltage, required redundancy, quantity and destination.
