E84DGFCRANP

/ 4.9
1001 reviews | Need a Specific Revision?
Lenze E84DGFCRANP is an 8400 motec PROFINET communication unit operating at 100 Mbit/s as a PROFINET IO Device. It provides two switched network ports, five digital inputs and one digital output in an IP65 field-mounted execution.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for E84DGFCRANP
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for E84DGFCRANP

  • Manufacturer:
    Lenze
  • Part Number:
    E84DGFCRANP
  • Product Family:
    Lenze Drives
  • Product Type:
    8400 motec PROFINET Communication Unit
  • Stock:
    1
  • Communication speed:
    100 Mbit/s with automatic detection
  • Process-data width:
    1 to 8 words of 16 bits
  • Logical process-data channels:
    1
  • Maximum cable length:
    100 m between nodes
  • Rated auxiliary voltage:
    24 V DC
  • Insulation voltage to PE:
    50 V AC
  • Digital inputs:
    5
  • Digital outputs:
    1
  • Free option slots:
    5
  • Operating temperature:
    -30 to +55 deg C, class 3K3
  • Storage temperature:
    -30 to +60 deg C, class 1K3
  • Transport temperature:
    -30 to +75 deg C, class 2K3
  • Enclosure rating:
    IP65
  • Communication profile:
    PROFINET RT, Conformance Class B
  • Network role:
    PROFINET IO Device
  • Supported topologies:
    Tree, star and line
  • Integrated switch:
    Two-port switch for line topology
  • Identification functions:
    I&M 0 through I&M 4
  • Status indication:
    Four communication LEDs with Link / Activity
  • Controller enable:
    Integrated
  • Connector execution:
    I/O terminal variant with PN-IN and PN-OUT
  • Minimum compatible drive firmware:
    8400 motec V03.01.00.13 for PROFINET
  • Device description:
    GSDML for Lenze PROFINET devices
  • Weight:
    0.84 lbs (0.38 kg)
  • Estimated shipping dimensions:
    17.1 x 12.3 x 5 cm
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Communication Firmware & Updates Connectivity

Features:

  • Operates as a 100 Mbit/s PROFINET RT IO Device for 8400 motec drives.
  • Integrates two switched Ethernet ports plus five digital inputs and one digital output.
  • Supports one cyclic channel with one to eight 16-bit process-data words.
The ordered communication unit is the IP65 PN-IN and PN-OUT terminal execution for field-mounted 8400 motec drive systems. It includes controller enable and four network-status LEDs.

PROFINET process data is exchanged cyclically while the built-in switch supports line, star and tree topologies. I&M records provide standardized device identification and maintenance information.

Confirm the drive firmware, GSDML revision, station name and IP plan before network commissioning. Each copper segment must remain within 100 m and connectors should preserve the enclosure rating.

Availability is reviewed against the 8400 motec firmware and required PROFINET network execution.
Verified resources for Lenze E84DGFCRANP:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Connects decentralized 8400 motec drives to PROFINET machine-control networks.
  • Supports conveyor, material-handling and packaged-machine axes using cyclic drive commands.
  • Adds local digital I/O and network diagnostics at the field-mounted drive location.
  • Uses PROFINET RT at 100 Mbit/s with automatic speed detection.
  • One logical channel exchanges from one to eight 16-bit process-data words.
  • I&M 0 through I&M 4 records support standardized network identification and maintenance.
  • The drive requires 8400 motec firmware V03.01.00.13 or later for PROFINET use.
  • Engineering must use the Lenze GSDML file that corresponds to the installed device execution.
  • Firmware and device-description compatibility should be confirmed before replacing an operating unit.
  • Two integrated switch ports support line, star and tree topologies.
  • Copper network segments are limited to 100 m between active nodes.
  • PN-IN and PN-OUT connectors, station name and IP settings must be checked during commissioning.
Description
Lenze E84DGFCRANP is an 8400 motec communication unit that connects the field-mounted drive to a PROFINET RT network. It operates as a PROFINET IO Device at 100 Mbit/s and includes two switched network ports for line, tree or star topologies. The integrated switch lets one network cable enter and another continue to the next device, supporting decentralized machine layouts without requiring a separate external switch beside every drive.

The unit exchanges one to eight 16-bit process-data words with the controller while also providing five digital inputs and one digital output for local machine signals. Integrated controller enable, identification data and communication LEDs support commissioning and service without changing the drive's decentralized installation concept. PROFINET I&M records and the four communication indicators help maintenance teams identify the installed device, observe link activity and distinguish a network interruption from a drive-side control or wiring problem.

Its IP65 construction and -30 to +55 deg C operating range suit installation close to the motor when the matching 8400 motec hardware is used. Network segments are limited to 100 m, and the PROFINET GSDML, connector execution and minimum compatible drive firmware must be verified before integration. The 24 V auxiliary supply, port assignment, device name and controller configuration should be prepared together so the unit can join the intended PROFINET topology without duplicate addressing or missing process data.
Alternative Names
E84DGFCRANP Lenze E84DGFCRANP E84DGFCR ANP 8400 motec PROFINET Unit Lenze PROFINET IO Device E84DGFCRANP Communication Module Lenze 8400 motec Network Unit
Technical notes
Before integrating E84DGFCRANP, confirm 8400 motec firmware V03.01.00.13 or later and load the matching GSDML; duplicate PROFINET device names will prevent network startup.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How much cyclic data can Lenze E84DGFCRANP exchange?
The single logical process-data channel supports one to eight words, with each word containing 16 bits.
Which PROFINET role is assigned to Lenze E84DGFCRANP?
It operates as a PROFINET IO Device using PROFINET RT at 100 Mbit/s and Conformance Class B.
How does Lenze E84DGFCRANP support a line topology?
An integrated two-port switch provides separate PN-IN and PN-OUT connections for daisy-chained network segments.
What firmware baseline is required by Lenze E84DGFCRANP?
The compatible 8400 motec drive must run firmware V03.01.00.13 or later for PROFINET operation.
Which commissioning file is used for Lenze E84DGFCRANP?
Engineering systems use the matching Lenze GSDML device description to configure the PROFINET IO Device.
What network details help quote Lenze E84DGFCRANP correctly?
Provide the drive firmware, controller platform, topology, device-name plan and required digital I/O usage.
