    Apter Power supports 6SL3120-1TE15-0AA4 quotations, product manuals and SINAMICS S120 module matching.

6SL3120-1TE15-0AA4

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6SL3120-1TE15-0AA4 is a SINAMICS S120 booksize Single Motor Module with internal air cooling and a 5 A output rating.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6SL3120-1TE15-0AA4
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6SL3120-1TE15-0AA4

  • Manufacturer:
    Siemens
  • Part Number:
    6SL3120-1TE15-0AA4
  • Product Family:
    Siemens SINAMICS
  • Product Type:
    Single Motor Module
  • Stock:
    1
  • DC Link Range:
    510–720 V DC
  • Motor Output:
    400 V 3 AC, 5 A
  • Typical Motor Rating:
    2.7 kW (3 hp)
  • Mechanical Format:
    Booksize, 50 mm width
  • Cooling Method:
    Internal air cooling
  • Pulse Frequency:
    4 kHz without derating; up to 16 kHz with derating
  • Safety Functions:
    Extended Safety Integrated functions supported
  • Control Connection:
    DRIVE-CLiQ cable included
  • Weight:
    11.993 lbs (5.44 kg)
  • Estimated shipping dimensions:
    5×38×27cm
  • Tariff Code:
    85044085
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals DC Link & Output Pulse Operation Cooling Layout Control Integration

Features:

  • Converts the shared SINAMICS S120 DC link into one three-phase motor output.
  • Uses the 50 mm booksize housing with internal air cooling.
  • Supports extended Safety Integrated functions through the documented control architecture.
The 5 A rating belongs to the motor output of 6SL3120-1TE15-0AA4 rather than its DC-link input.

Pulse frequency and ambient temperature determine when output derating must be applied.

The complete AA4 suffix distinguishes this discontinued hardware version from adjacent order variants.

The Siemens 6SL3120-1TE15-0AA4 Single Motor Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6SL3120-1TE15-0AA4 Single Motor Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Power Conversion Path

  • Input side: The motor module is connected to a 510–720 V DC link.
  • Output side: It produces a 400 V three-phase AC motor supply rated at 5 A.
  • Power assignment: The typical motor rating is 2.7 kW or 3 hp.
  • Topology: One 6SL3120-1TE15-0AA4 controls one motor from the shared drive DC bus.

Switching-Frequency Boundary

  • Base point: The documented output applies at a 4 kHz pulse frequency.
  • Higher settings: Pulse frequencies up to 16 kHz are available with derating.
  • Motor behavior: Optimized pulse patterns shape the inverter output for motor operation.
  • Selection check: The configured pulse frequency and required motor current must be reviewed together.

Booksize Thermal Arrangement

  • Enclosure width: The 6SL3120-1TE15-0AA4 occupies a 50 mm booksize position.
  • Heat path: Internal airflow removes the module losses through the enclosure.
  • Base ambient: Rated operation is specified through 40 °C without temperature derating.
  • Upper boundary: Operation to 55 °C follows the published derating curve.

DRIVE-CLiQ and Safety Functions

  • Control link: The supplied DRIVE-CLiQ cable connects the module within the S120 drive system.
  • Safety scope: Extended Safety Integrated functions are supported by this hardware version.
  • Order identity: The AA4 suffix remains part of the module and support-function match.
  • Commissioning boundary: Electrical ratings and the configured control topology must agree before operation.
Description
Siemens 6SL3120-1TE15-0AA4 is a SINAMICS S120 Single Motor Module in the booksize format. It converts the common 600 V DC link supply into a three-phase motor output rated at 400 V AC and 5 A for one connected motor.

The power stage of 6SL3120-1TE15-0AA4 operates from a 510–720 V DC link and is assigned a typical motor rating of 2.7 kW. Its pulse pattern is optimized for motor operation, while the available switching-frequency settings determine the applicable derating boundary.

Internal air cooling carries the losses of 6SL3120-1TE15-0AA4 through the 50 mm-wide booksize enclosure. The module also supports extended Safety Integrated functions and includes the DRIVE-CLiQ cable used for the control connection within the SINAMICS S120 arrangement.

The order code 6SL3120-1TE15-0AA4 identifies the discontinued AA4 version; its complete suffix therefore remains necessary when matching the electrical rating, mechanical width and control-cable scope of the installed module.
Alternative Names
6SL31201TE150AA4 6SL3120 1TE15 0AA4 6SL 3120-1TE15-0AA4 Siemens 6SL3120-1TE15-0AA4 SINAMICS S120 6SL3120-1TE15-0AA4 6SL3120-1TE15-0AA4 Motor Module S120 Single Motor Module 5 A 6SL3120-1TE15-0AAx
Technical notes
The 6SL3120-1TE15-0AA4 module combines a 510–720 V DC link input, 5 A motor output and internal-air-cooled booksize construction.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which supply must be present at the power terminals of 6SL3120-1TE15-0AA4?
The 6SL3120-1TE15-0AA4 power section requires a 510–720 V DC link; its 600 V DC designation is not a three-phase mains input.
Why should the 50 mm width be checked before fitting 6SL3120-1TE15-0AA4?
The 6SL3120-1TE15-0AA4 uses the 50 mm booksize format, so the cabinet position and adjacent-module spacing must match that mechanical width.
Can 6SL3120-1TE15-0AA4 be run at 16 kHz without changing its usable output?
No. The 6SL3120-1TE15-0AA4 is rated without derating at 4 kHz; higher pulse frequencies up to 16 kHz require the documented derating.
What control-side item belongs with 6SL3120-1TE15-0AA4?
A DRIVE-CLiQ cable is included with 6SL3120-1TE15-0AA4 for the documented SINAMICS S120 control connection.
Which code detail separates the installed 6SL3120-1TE15-0AA4 from later variants?
The final AA4 suffix is part of the complete 6SL3120-1TE15-0AA4 identity and must be retained when comparing the installed hardware and lifecycle record.
What thermal condition changes the rating of 6SL3120-1TE15-0AA4?
The 6SL3120-1TE15-0AA4 can operate above 40 °C only within its specified derating curve, up to the documented 55 °C limit.
